PRAMAC TG42/15 IP23

PRAMAC PTO Generator TG42/15 IP23 Single-phase/Three-phase 42 KVA AVR

PRAMAC PTO generator TG42/15 IP23 single-phase with 14.7 KVA and three-phase with 42 KVA with 1500 rpm tractor connection. The PRAMAC PTO generator TG42/15 IP23 has a voltage of 230 V / 400 V and a frequency of 50 Hz. The alternator of the PRAMAC PTO generator TG42/15 IP23 has an AVR voltage regulator. The TG42/15 IP23 AVR PTO generator is very reliable as it has been built and designed using high-quality materials.
Easy to transport, install and position thanks to its compact size, this PTO generator model is ideal for mounting on a tractor unit. The PRAMAC PTO generator TG42/15 IP23 has a required tractor power of 74 KW / 100 HP and a PTO speed of 395 rpm.

Technical characteristics of the PRAMAC PTO generator TG42/15 IP23 AVR Single-phase/Three-phase:
Continuous single-phase power: 14.7 KW
Continuous three-phase power: 33.6 KW
Voltage: 230 V / 400 V
Frequency: 50 Hz
PTO speed: 395 rpm
Tractor power required: 74 KW / 100 HP
Length: 1110 mm
Width: 720 mm
Height: 1322 mm
Weight: 355 Kg
AVR

Outlets:
N.1 SCHUKO 230V 16A IP54
N.1 2P+T CEE 230V 32A IP44
N.1 3P+N+T CEE 400V 63A

The PRAMAC PTO generator TG42/15 IP23 is a professional tractor unit developed by Pramac, making it one of the best choices compared to its competitors. The PRAMAC PTO generator TG42/15 IP23 has a robust structure with a protective tubular frame.
The TG42/15 IP23 PTO generator is equipped with magnetothermal protection, differential protection, voltmeter and frequency meter.

If you are looking for a PTO generator like the PRAMAC TG42/15 IP23 AVR single-phase/three-phase tractor unit, then we recommend browsing our catalog of PTO generators to find the one that best suits your needs.

Images and technical data are not binding. Always refer to the technical data sheet issued by the manufacturer. Manel service does not assume responsibility for any changes made by the manufacturer.
