CGM

Technical data EP45/48: Rated power: 45 KVA Storage capacity: 48 KWh Frequency: 50 Hz Voltage: 400 volts Weight: 1150 kg Dimensions: 1650x1180x1900 mm Battery type: LINMC Quantity: 2 Cycles @ 90%=6000 Recharge Time: 20-90%=1.1Hr/20-100%=1.25Hr

Technical data ECO POWER EPH242418 HYBRID: Rated power: 24 KVA Storage capacity: 24 KWh Generator capacity: 18 KVA PRP Generator model: YANMAR 4TNV88 Frequency: 50 Hz Voltage: 400 volts Weight: 1550 kg Dimensions: TDB Battery type: LINMC Quantity: 1 Cycles @ 90%=6000 Recharge Time: 20-90%=1.20Hr/20-100%=1.30Hr

Phase type: Single phase Continuous power: 10 KVA Continuous power: 8 KW Emergency power: 11 KVA Emergency power: 8.8 KW Voltage: 230 V Frequency: 50 Hz Engine revs: 3000 rpm Tractor power requirement: 20 hp PTO revs: 435 rpm Gearbox ratio: 1:6.9 Gearbox oil capacity: 0.5 Lt Alternator: Linz, self-excited, with...

Technical data Eco Power EP24/96: Rated power: 24 KVA Storage capacity: 48 KWh Frequency: 50 Hz Voltage: 400 volt Weight: 1460 Kg Dimensions: 1650x1180x1900 mm Battery Type: LINMC Quantity: 4 Cycles @ 90%=6000 Recharge Time: 20-90%=4.30Hr/20-100%=5Hr

Technical data ECO POWER EPH24/48/18 HYBRID: Rated power: 24 KVA Storage capacity: 48 KWh Generator capacity: 18 KVA PRP Generator model: YANMAR 4TNV88 Frequency: 50 Hz Voltage: 400 volts Weight: 1700 kg Dimensions: TDB Battery type: LINMC Quantity: 2 Cycles @ 90%=6000 Recharge Time: 20-90%=2.30Hr/20-100%=2.50Hr

Maximum power Singlephase: 2 KW Maximum power Singlephase: 2.2 KVA Fuel: Petrol Voltage: 230 V Frequency: 50 Hz Engine: CGM Start: Manual Consumption: 1 Lt/h Length: 560 mm Width: 270 mm Height: 455 mm Weight: 22 Kg Super silenced Inverter

Phase type: Three-phase Continuous power: 10 KVA Continuous power: 8 KW Emergency power: 11 KVA Emergency power: 8.8 KW Voltage: 400 V Frequency: 50 Hz Engine revs: 1500 rpm Tractor power required: 20 hp PTO rpm: 430 rpm Multiplier ratio: 1:3.5 Oil capacity multiplier: 0.4 Lt Alternator: Linz, self-excited, with brushes Voltage...

Rated power: 24 KVA Storage capacity: 96 KWh Generator capacity: 18 KVA PRP Generator model: YANMAR 4TNV88 Frequency: 50 Hz Voltage: 400 volts Weight: 2100 kg Dimensions: TDB Battery type: LINMC Quantity: 4 Cycles @ 90%=6000 Recharge Time: 20-90%=5Hr/20-100%=5.45Hr

Rated power: 45 KVA Storage capacity: 96 KWh Frequency: 50 Hz Voltage: 400 volts Weight: 1550 kg Dimensions: 1650x1180x1900 mm Battery type: LINMC Quantity: 4 Cycles @ 90%=6000 Recharge Time: 20-90%=2.45Hr/20-100%=3.10Hr

Rated power: 45 KVA Storage capacity: 48 KWh Generator capacity: 43 KVA PRP Generator model: YANMAR 4TNV88CT Frequency: 50 Hz Voltage: 400 volts Weight: 2200 kg Dimensions: TDB Battery type: LINMC Quantity: 2 Cycles @ 90%=6000 Recharge Time: 20-90%=1.10Hr/20-100%=1.20Hr

Phase type: Three-phase Continuous power: 10 KVA Continuous power: 8 KW Emergency power: 11 KVA Emergency power: 8. 8 KW Voltage: 400 V Frequency: 50 Hz Motor RPM: 3000 rpm Tractor power required: 20 hp PTO RPM: 435 rpm Multiplier ratio: 1:6.9 Multiplier oil capacity: 0. 5 Lt Alternator: Linz, self-excited, with brushes Voltage...

Rated power: 45 KVA Storage capacity: 96 KWh Generator capacity: 43 KVA PRP Generator model: YANMAR 4TNV88CT Frequency: 50 Hz Voltage: 400 volts Weight: 2700 kg Dimensions: TDB Battery type: LINMC Quantity: 4 Cycles @ 90%=6000 Recharge Time: 20-90%=2.15Hr/20-100%=2.40Hr

Technical data EP24/24: Rated power: 24 KVA Storage capacity: 24 KWh Frequency: 50 Hz Voltage: 400 volt Weight: 875 Kg Dimensions: 1650x1180x1900 mm Battery Type: LINMC Quantity: 1 Cycles @ 90%=6000 Recharge Time: 20-90%=1.10Hr/20-100%=1.25Hr

Phase type: Single-phase / Three-phase Continuous power: 15 KVA Continuous power: 12 KW Emergency power: 16.5 KVA Emergency power: 13.2 KW Voltage: 230 / 400 V Frequency: 50 Hz Engine speed: 1500 rpm Tractor power required: 30 hp PTO revs: 430 rpm Gearbox ratio: 1:3.5 Gearbox oil capacity: 0.5 Lt Alternator: Linz,...

Maximum power Single-phase: 3 KW Maximum power Single-phase: 3.3 KVA Fuel: Petrol Voltage: 230 V Frequency: 50 Hz Engine: CGM Start: Manual / Electric Consumption: 1.2 Lt/h Length: 560 mm Width: 310 mm Height: 490 mm Weight: 33 Kg Super silenced Inverter

Phase type: Single phase Continuous power: 16 KVA Continuous power: 12.8 KW Emergency power: 17. 5 KVA Emergency power: 14 KW Voltage: 230 V Frequency: 50 Hz Motor speed: 3000 rpm Tractor power required: 30 hp Power take-off speed: 435 rpm Multiplier ratio: 1:6.9 Multiplier oil capacity: 0. 7 Lt Alternator: Linz, self-excited, with...

Phase type: Three phase Continuous power: 16 KVA Continuous power: 12.8 KW Emergency power: 17.5 KVA Emergency power: 14 KW Voltage: 400 V Frequency: 50 Hz Engine revs: 3000 rpm Tractor power requirement: 30 hp PTO revs: 435 rpm Gearbox ratio: 1:6.9 Gearbox oil capacity: 0.7 Lt Alternator: Linz, self-excited, with brushes<br...

Phase type: Single-phase / Three-phase Continuous power: 20 KVA Continuous power: 16 KW Emergency power: 22 KVA Emergency power: 17.6 KW Voltage: 230/400 V Frequency: 50 Hz Engine rpm: 1500 rpm Necessary tractor power: 45 hp PTO speed: 430 rpm / min Multiplier ratio: 1: 3.5 Multiplier oil capacity: 0.5 Lt Alternator: Linz,...

Phase type: Single phase Maximum power: 8 KVA / 7.2 KW Fuel: Petrol Voltage: 230 V Frequency: 50 Hz Motor : CGM 460 BE Engine rpm: Variable Emissions standard: StageV Starter: Electric Voltage regulator: Inverter Capacity: tank: 25 Lt Consumption: 2.9 Lt/h at 75% of the load Autonomy: 8.5 h at 75% of the load Length: 730 mm<br...

Phase type: Single-phase Continuous power: 22 KVA / 17.6 KW Emergency power: 24.2 KVA / 19.3 KW Voltage: 230/400 V Frequency: 50 Hz Engine speed: 3000 rpm Necessary tractor power: 45 hp PTO speed: 440 rpm Multiplier ratio: 1: 6.9 Multiplier oil capacity: 0.5 Lt Alternator: Linz, self-excited, with brushes Voltage regulator: AVR<br...

Phase type: Single-phase / Three-phase Continuous power: 22 KVA Continuous power: 17.6 KW Emergency power: 24.2 KVA Emergency power: 19.3 KW Voltage: 230/400 V Frequency: 50 Hz Engine speed: 3000 rpm Necessary tractor power: 45 hp PTO speed: 440 rpm Multiplier ratio: 1: 6.9 Multiplier oil capacity: 0.5 Lt Alternator: Linz,...

Phase type: Three-phase Continuous three-phase power: 19.2 kW Continuous three-phase power: 24 kVA Fuel: Battery Frequency: 50 Hz Length: 1650 mm Width: 1180 mm Height: 2050 mm Super silenced: Yes Weight: 1066 Kg Battery type: LINMCT Charging times: 2.45 hours (20-90%), 3.10 hours (20-100%) Voltage: 400...

Phase type: Single-phase / Three-phase Continuous power: 27 KVA Continuous power: 21.6 KW Emergency power: 29.7 KVA Emergency power: 23.7 KW  Voltage: 230/400 V Frequency: 50 Hz Engine speed: 3000 rpm Necessary tractor power: 45 hp PTO speed: 440 rpm / min Multiplier ratio: 1: 6.9 Multiplier oil capacity: 0.5 Lt Alternator: Linz,...

Phase type: Single phase Maximum power: 10.9 KW Continuous power: 9.9 KW Maximum power: 12.1 KVA Continuous power: 11 KVA Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Motor: KOHLER KD425 Engine speed: 3000 rpm Starting: Electric Voltage regulator system: AVR Consumption: 2.8 Lt/h at 75% of the load Tank capacity: 30 Lt<br...

Nominal Power: 120 kVA / 96 kW Storage Capacity: 207.2 kWh Voltage: 400 V (3P+N) Frequency: 50 Hz Power Factor: 0.8 Continuous Power Amperage: 174 A Batteries Technology: LiNMC (Lithium Nickel Manganese Cobalt) Quantity: 8 modules Power: 120kVA/207.2kWh Cycles @90%: 6000  Inverter Type: three-phase bidirectional inverter<br...

Phase type: Single-phase / Three-phase Continuous power: 30 KVA Continuous power: 24 KW Emergency power: 33 KVA Emergency power: 26.4 KW Voltage: 230/400 V Frequency: 50 Hz Engine rpm: 3000 rpm Necessary tractor power: 60 hp PTO speed: 435 rpm / min Multiplier ratio: 1: 6.9 Multiplier oil capacity: 0.5 Lt Alternator: Zanardi,...

Phase type: Single-phase / Three-phase Continuous power: 30 KVA Continuous power: 24 KW Emergency power: 33 KVA Emergency power: 26.4 KW Voltage: 230/400 V Frequency: 50 Hz Engine rpm: 1500 rpm Necessary tractor power: 60 hp PTO speed: 430 rpm / min Multiplier ratio: 1: 3.5 Multiplier oil capacity: 0.5 Lt Alternator: Zanardi, with...

Phase Type: Single-Three Phase Singlephase Continuous power: 9 KW ThreePhase Maximum Power: 15.3 KW ThreePhase Continuous Power: 14 KW ThreePhase Maximum Power: 19.2 KVA Threephase Continuous power: 17.5 KVA Fuel: Gasoline Voltage: 230 / 400 V Frequency: 50 Hz Engine: BRIGGS &amp; STRATTON 31HP Cooling: Air Number of cylinders: 2<br...

Phase type: Single-phase / Three-phase Continuous power: 40 KVA / 32 KW Emergency power: 44 KVA / 35.2 KW Voltage: 230/400 V Frequency : 50 Hz Engine rpm: 3000 rpm Necessary tractor power: 75 hp PTO speed: 435 rpm Multiplier ratio: 1: 6.9 Oil multiplier capacity: 0.5 Lt Alternator: Zanardi, self-excited, with brushes Voltage regulator:...

Phase type: Single-phase / Three-phase Maximum power: 12 KVA / 9.6 KW Continuous power: 10.5 KVA / 8.4 KW Fuel: Diesel Voltage: 230/400 V Frequency: 50 Hz Engine: LOMBARDINI LDW 1404 Emissions standard: Not emission-free Number of cylinders: 4 Displacement: 1372 cc Engine rpm: 1500 rpm Fuel consumption: 2.6 l/h at 75% load Acoustic...

Phase type: Single phase / Three phase Continuous power: 60 KVA Continuous power: 48 KW Emergency power: 66 KVA Emergency power: 52.8 KW Voltage: 230 / 400 V Frequency: 50 Hz Engine revs: 1500 rpm Tractor power requirement: 120 hp PTO revs: 420 rpm Gearbox ratio: 1:3.6 Gearbox oil capacity: 1 Lt Alternator: Linz, self-excited,...

Phase type: Single-phase / Three-phase Maximum power: 22 KVA / 17.6 KW Continuous power: 20 KVA / 16 KW Fuel: Diesel Voltage: 230/400 V Frequency: 50 Hz Engine: LOMBARDINI LDW 2204 Emissions standard: Not emission-free Number of cylinders: 4 Displacement: 2199 cc Engine rpm: 1500 rpm Fuel consumption: 4.5 l/h at 75% load Acoustic...

Phase type: Single-phase / Three-phase Continuous power: 75 KVA Continuous power: 60 KW Emergency power: 82.5 KVA Emergency power: 66 KW Voltage: 230 / 400 V Frequency: 50 Hz Engine revs: 1500 rpm Tractor power required: 130 hp PTO rpm: 395 rpm Multiplier ratio: 1:3.8 Oil capacity multiplier: 1 Lt Alternator: Linz, self-excited,...

Phase type: Single-Phase / Three-phase Continuous power: 85 KVA Continuous power: 68 KW Emergency power: 93.5 KVA Emergency power: 74.8 KW Voltage: 230 / 400 V Frequency: 50 Hz Engine revs: 1500 rpm Tractor power required: 130 hp PTO rpm: 395 rpm Multiplier ratio: 1:3.8 Oil capacity multiplier: 1 Lt Alternator: Linz, self-excited,...

Phase type: Single-phase / Three-phase Continuous power: 100 KVA Continuous power: 80 KW Emergency power: 110 KVA Emergency power: 88 KW Voltage: 230 / 400 V Frequency: 50 Hz Motor speed: 1500 rpm Tractor power required: 160 hp Power take-off revs: 500 rpm Multiplier ratio: 1:3 Multiplier oil capacity: 4 Lt Alternator: Linz,...

Phase type: Single-phase / Three-phase Continuous power: 143 KVA Continuous power: 114. 4 KW Emergency Power: 130 KVA Emergency Power: 104 KW Voltage: 230 / 400 V Frequency: 50 Hz Motor RPM: 1500 rpm Tractor Power Required: 160 hp Power Take-Off RPM: 500 rpm Multiplier Ratio: 1: 3 Multiplier oil capacity: 4 Lt Alternator: Linz,...

OUT OF PRODUCTION Floodlights: 4 LED 160W Illuminated Area: 2600 Mq Max Height: 7 Mt Lift: manual Telescopic pole: galvanized steel Wind stability: nr 4 stabilizers Guides for forklift forks: n.6 Lumen per light: 20350 lm Rotation: 360 degrees Voltage: 230V Frequency: 50Hz Outlet socket: 16A 3P Input socket: 16A 3P<br...

OUT OF STOCK Type of phase : 230V single phase. Phase type : Singlephase Maximum singlephase output : 2.4 KW / 3 KVA Engine : Honda GX270 Fuel : Gasoline  Cylinders : 1 Displacement : 270 cm3 Maximum engine power : 9 HP / 6.6 Welding at 50%: 170 Tank : 6 Lt Socket : N.2 x 230V SCHUKO Starting : Manual...

OUT OF STOCK Phase type : Single-phase Maximum single-phase power : 2.4 KW / 3 KVA Engine: Honda GX270 Fuel: Gasoline  Cylinders : 1 Displacement : 270 cm3 Maximum engine power : 9 HP / 6.6 Welding capacity at 50%: 170 Tank : 6 Lt Socket : N.2 x 230V SCHUKO Starting : Electric with battery Acoustic power : 70...
