Phase type: Single-phase Maximum singlephase power: 4,0 KW Singlephase continuous use power: 3,2 KW Maximum singlephase power: 5,0 KVA Singlephase continuous use power: 4,5 KVA Frequency: 50 - 60 Hz Voltage: 230 V Degree of protection: IP21 Alternator speed: 3000 rpm Number of poles: 2 Acoustic pressure: 72 dBA (56 dBA at 7 m)<br...

Type of phase: Single-phase / Three-phase Maximum three-phase power: 735 KVA / 588 KW Continuous three-phase power: 680 KVA / 544 KW Maximum single-phase power: 360 KVA / 360 KW Continuous single-phase power: 335 KVA / 335 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Degree of protection: IP23 Revolutions of the 'alternator: 1500/1800 rpm Number...

Type of phase: Single-phase / Three-phase Maximum three-phase power: 601 KVA / 481 KW Continuous three-phase power: 550 KVA / 440 KW Maximum single-phase power: 315 KVA / 315 KW Continuous single-phase power: 292 KVA / 292 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Degree of protection: IP23 Revolutions of the 'alternator: 1500/1800 rpm Number...

Phase type: Single-phase Maximum singlephase power: 4,8 KW Singlephase continuous use power: 4,0 KW Maximum singlephase power: 5,7 KVA Singlephase continuous use power: 5,0 KVA Frequency: 50 - 60 Hz Voltage: 230 V Degree of protection: IP21 Alternator speed: 3000 rpm Number of poles: 2 Acoustic pressure: 72 dBA (56 dBA at 7 m)<br...

Input power supply: 180 to 280 Vac Regulation accuracy: ± 2.5% Maximum output current: 6 A Working temperature: -20°C ÷ +70°C Standard regulation: 100 ÷ 280 Vac

Power supply: 40 ÷ 270 Vac Frequency operating range: 15 Hz ÷ 72 Hz Regulation accuracy: ± 1% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Regulation True RMS or average value measurement: 70÷280 Vac Transient voltage drop and overvoltage: within ± 15% Voltage recovery time: within ± 3% of the set value in less than 300...

Supply voltage: 40 ÷ 270 VaC Frequency operating range: 12 Hz ÷ 72 Hz Voltage regulation accuracy: ± 1% Voltage regulation accuracy (stabilized conditions): ± 0,5% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Voltage adjustment range: 75 ÷ 300 Vac Transient voltage drop and overvoltage: within ± 15% Voltage recovery time:...

Power supply: 40 to 270 Vac Frequency operating range: 12 Hz to 72 Hz Regulation accuracy: ± 1% Regulation accuracy (stabilized conditions): ± 0.5% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Voltage regulation range: 75 ÷ 300 Vac Transient voltage drop and overvoltage: within ± 15% Recovery time: within ± 3% of set...

Sensing input: 80~350 VAC single phase Power supply input: voltage 50~270 VAC, frequency 50/60 Hz Magnetic field output: max. Input 63 VDC @ 220 VAC, continuous 6A Regulation accuracy: &lt; ±1% (with 4% motor regulation) Voltage storage: residual voltage greater than 5 VAC 25 Hz External voltage regulation: 100 K ohm 1/2 watt ±7% Unit power dissipation: max....

Frequency: 50/60 Hz Low speed protection Reference: Single-phase or Three-phase

Phase Type: Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 10.5 KVA / 10.5 KW (60Hz) 12.5 KVA / 12.5 KW Continuous Single Phase Output: (50Hz) 9. 5 KVA / 9.5 KW (60Hz) 11 KVA / 11 KW Maximum three-phase output: (50Hz) 16 KVA / 12.8 KW (60Hz) 19.2 KVA / 15.4 KW Continuous three-phase output: (50Hz) 14. 5 KVA / 11.6 KW<br...

Phase Type:Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 54KVA / 54KW (60Hz) 65KVA / 65KW Continuous Single Phase Output: (50Hz) 48.8KVA / 48.8KW (60Hz) 58.5KVA / 58.5KW Maximum Three Phase Output: (50Hz) 82KVA / 65.6KW (60Hz) 98.5KVA / 78. 8KW Continuous three-phase output: (50Hz) 75KVA / 60KW (60Hz)...

Type of phase: Single / Three-phase Maximum threephase power: 440 KVA / 352 KW Continuous threephase power: 400 KVA / 320 KW Maximum singlephase power: 211 KVA / 211 KW Singlephase continuous use power: 196 KVA / 196 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Alternator type: Brushless Degree of protection : IP23 Alternator revolutions:...

Phase Type: Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 12.5 KVA / 12.5 KW (60Hz) 15 KVA / 15 KW Single Phase Continuous Output: (50Hz) 11.2 KVA / 11.2 KW (60Hz) 13.4 KVA / 13.4 KW Maximum three-phase output: (50Hz) 20 KVA / 16 KW (60Hz) 24 KVA / 19.2 KW Three Phase Continuous Output: (50Hz) 18 KVA / 14.4...

Automatic voltage regulator RCM (loose) for T20F/ET20F alternators.

Automatic voltage regulator RCM (loose) for T16F/ET16F alternators.

Phase: Three phase Maximum three phase power: 813 KW Continuous three phase power: 744 KW Maximum three phase power: 1016 KVA Continuous three phase power: 930 KVA Frequency: 50 / 60 Hz Voltage: 400 V Protection: IP23 Rpm speed: 1500 / 1800 rpm Poles: 4 Efficiency: 95.4% Weight: 2140 Kg Constant speed alternator Brushless<br...

Automatic voltage regulator RCM (loose) for S20F/ES20F alternators.

Phase type: Single-phase / Three-phase Maximum single-phase output: (50Hz) 5KVA / 5KW (60Hz) 6KVA / 6KW Single-phase continuous output: (50Hz) 4.6KVA / 4.6KW (60Hz) 5.5KVA / 5.5KW Maximum three-phase output: (50Hz) 7KVA / 5.6KW (60Hz) 8.4KVA / 6.7KW Three-phase continuous output: (50Hz) 6.5KVA / 5.2KW (60Hz) 7.8KVA / 6.2KW<br...

Automatic voltage regulator RCM (loose) for S16F alternators.

Supply voltage: 50÷150Vac Accuracy: 1% Thermal stability: 2% Max Cadd capacitor current: 8 Amp Peak volt. between 5 and 6: 650V Ext. pot. voltage regul. range: ±5% Load application transient: 200ms ΔV &lt; -10% Load removal transient: 400ms ΔV &lt;+10%

Automatic voltage regulator RCM (loose) for S16W alternators.

Automatic voltage regulator RCM (loose) for S15W alternators.

Kit IP23 (assembled) for S15W alternators.

High blind terminal box for S15W alternators.

Insulated battery charger winding 12V 10A for S15W alternators.

Terminals for battery charger and fuse for S15W alternators.

Terminal box with N.2 230V 16A SCHUKO and N.1 breaker for S15W alternators.

Terminal box with N.2 16A CEE and N.1 breaker (single voltage) for S15W alternators.

Top box with N.1 16A CEE, N.1 230V 16A SCHUKO and N.1 breaker for S15W alternators.

Top box with N.1 115V 16A, N.1 230V 16A CEE, N.2 breakers and N.1 c/o switch for S15W alternators.

Kit B14 (loose) for S15W alternators.

Kit IP23 (assembled) for S16W alternators.

High blind terminal box for S16W alternators.

Insulated battery charger winding 12V 10A for S16W alternators.

Terminals for battery charger and fuse for S16W alternators.

Terminal box with N.2 230V 16A SCHUKO and N.1 breaker for S16W alternators.

Terminal box with N.2 16A CEE and N.1 breaker (single voltage) for S16W alternators.

Top box with N.1 16A CEE, N.1 230V 16A SCHUKO and N.1 breaker for S16W alternators.

Kit B14 (loose) for S16W alternators.
