CUMMINS ONAN

Phase type: Three-phase Continuous Power: 1125 KVA / 900 KW Maximum Power: 1250 KVA / 1000 KW Engine: Cummins KTA38-G9 Power supply: Diesel Engine RPM: 1500 rpm Starter: Electric Speed Governor: Electronic Voltage: 380-440 V Frequency: 50 Hz Consumption at 75 % load: 196 l/h Length: 7136.6 mm Width: 2174.6 mm Height: 2447 mm<br...

Phase Type: Single-phase Power supply: Diesel Single-phase power: 7 KW Single-phase power: 7 KVA Voltage: 115V/230V Amperes: 30.4A at 230 V, 60.9A at 115 V Frequency: 50 Hz Rpm: 1500 rpm. Cooling: Liquid Cylinders: 3 Bore x Stroke: 78x78.4 mm Cubic Capacity: 1123 c.c. Compression ratio: 24:1 Starting: Electric 12V Fuel...

Phase Type: Single Phase Maximum Power: 4.8 KVA / 4.8 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Kubota Z482 Emission standard: StageV / EPA Tier 4 Number of cylinders: 2 Engine RPM: 3000 rpm Acoustic power: 68 dBA Voltage regulator: AVR Length: 896 mm Depth: 581 mm Height: 514 mm Net Weight: 181 kg

Phase Type: Single Phase Single-phase Power: 13.5 KVA / 13.5 KW Voltage: 115V/230V Frequency: 50 Hz Motor: Kubota V2003 Rpm: 1500 rpm Emissions Standards: Stage III / EPA Power Supply: Diesel Cooling: Liquid Cylinders: 4 Bore x Stroke: 83 x 92.4 mm Starter: Electric 12V Fuel Consumption: 3.6 Lt/h at 75% load Voltage regulator:...

Phase type: Single-phase / Three-phase Continuous power: 20 KVA / 16 KW Maximum power: 22 KVA / 18 KW Engine: Cummins X2.5-G2 Fuel system: Diesel Engine speed: 1500 rpm Regulation of revolutions: Mechanical Alternator: Stamford S0L2-G1 Emissions standard: Stage ZERO Starter: Electric / Automatic Voltage regulator: Compound Voltage:...

Phase type: Single-phase / Three-phase Maximum three-phase power LTP: 66 KVA Maximum three-phase power LTP: 53 KW Three-phase continuous power PRP: 60 KVA Three-phase continuous power PRP: 48 KW Fuel: Diesel Frequency: 50 Hz Voltage: 230 / 400 V Engine: Cummins Engine speed: 1500 rpm Cooling: Water Length: 2270 mm Width: 975 mm<br...

Phase Type: Three Phase Continuous Power: 500 KVA / 400 KW Maximum Power: 550 KVA / 440 KW Engine: Cummins QSZ13-G10 Power Supply: Diesel Engine RPM: 1500 rpm RPM Adjustment: Mechanical Alternator: Stamford UC224F Emission standard: Stage Zero Starter: Electric / Automatic Voltage Regulator: Compound Voltage: 400 V Frequency: 50...

Phase Type: Single Phase Power supply: Diesel Single phase power: 27 KW Single Phase Power: 27 KVA Voltage: 110V/220V Frequency: 50 Hz Rpm: 1500 rpm Cooling: Liquid Cylinders: 4 Displacement: 3318 Starting: Electric Fuel Consumption: 6.2 Lt/h at 75% load Voltage regulator: AVR Insulation class: H Length: 1358 mm<br...

CUMMINS ONAN 155-2030 Silencer muffler for marine generators Diameter: In/Out 50 mm x 50 mm (2”) Suitable for MDKBH/J/L/M/N - MDKBDP/R/V series generators.

CUMMINS ONAN A029Z017 water / smoke separator  for marine generators Diameter: In/Out 50 mm x 50 mm (2”) Suitable for MDKBH/J/L/M/N - MDKBDP/R/V series generators.

CUMMINS ONAN 541-1270 Silencer muffler for marine generators Diameter: In/Out 76 mm x 76 mm (3”) Suitable for MDKDT/U/S series generators.

CUMMINS ONAN 541-1274 water / smoke separator  for marine generators Diameter: In/Out 50 mm x 76 mm (3”) Suitable for MDKDT/U/S series generators.

CUMMINS ONAN 541-0876-02 Siphon Break for marine generators Suitable for MDKBH series generators.

CUMMINS ONAN 541-0876-01 Siphon Break for marine generators Suitable for MDKBJ/L/M/N, MDKDP/R/V series generators.

CUMMINS ONAN 541-0877-01 Siphon Break for marine generators Suitable for MDKDT/U/S series generators.

CUMMINS ONAN 300-5725-02 Remote Control Panel for marine generators Start/stop button.

CUMMINS ONAN 541-1130 12V / 24V Digital Remote Panel. Suitable for all Cummins Onan marine gensets range.

CUMMINS ONAN 300-5725-01 12V Remote Control Panel. With start/stop button.

CUMMINS ONAN A052F591 Connection Cable Genset/Panel. Length: 7.6 Meters Suitable for all Cummins marine generators. With connectors

CUMMINS ONAN A052F587 Connection Cable Genset/Panel. Length: 13.7 Meters Suitable for all Cummins marine generators. With connectors

CUMMINS ONAN A052F585 Connection Cable Genset/Panel. Length: 22.8 Meters Suitable for all Cummins marine generators. With connectors

CUMMINS ONAN 338-4016 Harness Y Adapter for Remote Dual Stations. Suitable for all Cummins Onan marine generators. With Deutsch plug.

CUMMINS ONAN 0300-4686-01 Low coolant level safety shut-off switch. Suitable for all Cummins Onan marine generators.

CUMMINS ONAN 0541-1275-02 PTO Clutch Assembly 24 V. Suitable for Cummins Onan marine generators 24 VDC MDKBT/U. Net Available Power at 1500 rpm: 40 HP (29.8 KWm) Kit Includes: Clutch, instruction sheet, and brackets and hardware.

CUMMINS ONAN 0541-1275-01 PTO Clutch Assembly 12 V. Suitable for Cummins Onan marine generators 12 VDC MDKBT/U. Net Available Power at 1500 rpm: 40 HP (29.8 KWm) Kit Includes: Clutch, instruction sheet, and brackets and hardware.

CUMMINS ONAN 0541-1648-02 PTO Clutch Assembly 24V. Suitable for Cummins Onan marine generators 24 VDC MDKBP/R and 24 VDC MDKBV. Net Available Power at 1500 rpm: 26 HP (19.4 KWm) Kit Includes: Clutch, instruction sheet, and brackets and hardware.

CUMMINS ONAN 0541-1648-01 PTO Clutch Assembly 12 V. Suitable for Cummins Onan marine generators 12 VDC MDKBP/R and 12 VDC MDKBV. Net Available Power at 1500 rpm: 26 HP (19.4 KWm) Kit Includes: Clutch, instruction sheet, and brackets and hardware.

CUMMINS ONAN A026M935 Remote Fuel/Water Separator, 30 Micron. Suitable for all Cummins Onan marine generators.

CUMMINS ONAN 541-1195-03 SAE J1939 Network Interface Module. Suitable for Cummins Onan marine generators MDKBK/L/M/N/P/R/V/T/U.

CUMMINS ONAN 0541-1253-01 Front (Engine End) Exhaust Outlet Kit. Suitable for Cummins Onan marine generators MDKDL.

CUMMINS ONAN 541-1253-02 Front (Engine End) Exhaust Outlet Kit. Suitable for Cummins Onan marine generators MDKDM/N.

CUMMINS ONAN 541-1472-02 Front (Engine End) Exhaust Outlet Kit. Suitable for Cummins Onan marine generators MDKDP/R/V.

CUMMINS ONAN 541-1282 Front (Engine End) Exhaust Outlet Kit. Suitable for Cummins Onan marine generators MDKDT/U/V.

Phase Type: Single Phase Power supply: Diesel Single phase power: 11 KW Single phase power: 11 KVA Voltage: 115V/230V Ampere: 47.8A at 230V, 95.7A at 115V Frequency: 50 Hz Rpm: 1500 rpm Cooling: Liquid Cylinders: 4 Bore x Stroke: 78x78.4 mm Displacement: 1498 c.c. Compression ratio: 24:1 Starter: Electric 12V Fuel...

Phase Type: Single Phase Power supply: Diesel Single phase power: 6 KW Single phase power: 6 KVA Voltage: 115V/230V Ampere: 26.1A at 230V, 52.2A at 115V Frequency: 50 Hz Rpm: 2400 rpm Cooling: Liquid Cylinders: 3 Bore x Stroke: 67x68 mm Displacement: 719 c.c. Compression ratio: 23.5:1 Starter: Electric 12V Fuel...

CUMMINS ONAN 541-0877-01 Siphon Break for marine generators Suitable for MDKDT/U/S series generators.

CUMMINS ONAN Tubo di scarico umido (2 pollici (5,1 cm) di diametro interno x 10 piedi (3,1 m) di lunghezza).

CUMMINS ONAN Wet Exhaust Pipe (2.5" (6.35cm) ID x 10ft (3.1m) Long).

Phase type: Single phase Power supply: Diesel Single phase power: 17. 5 KW Single-Phase Power: 17.5 KVA Voltage: 115V/230V Amps: 76.1A at 230 V, 152.2A at 115 V Frequency: 50 Hz Rpm: 1500 rpm Cooling: Liquid Cylinders: 4 Bore x Stroke: 78x78. 4 mm Displacement: 1498 c.c Compression ratio: 24:1 Power supply: Electric 12V<br...

Phase Type: Single Phase Maximum Power: 22.5 KVA / 22.5 KW Voltage: 115V/230V Frequency: 50 Hz Power supply: Diesel Rpm: 1500 rpm Emission standard: Non-emission Cooling: Liquid Cylinders: 4 Starter: Electric Fuel consumption: 5.2 Lt/h at 75% load Voltage regulator: AVR Insulation class: H Length: 1358 mm Width: 622 mm<br...
