VOLTAGE REGULATORS

Triangle connection Nominal voltage: 100÷260 V at 50/60 Hz Star connection Nominal voltage: 300÷490 V at 50/60 Hz Excitation: Ie=5 A Ve<=100 V Overall length: 110 mm Overall width: 58 mm Overall height: 55 mm Weight: 0.29 Kg

Power supply voltage input: a) 110 Vac ±15% b) 220 Vac -25%/+15%. Max field current: 10 Adc Permanent field current: 7 Adc Single-phase reference voltage input: 90 Vac ÷ 440 Vac Alternator output voltage calibration with multi-turn trimmer Stability control calibration with multi-turn trimmer Calibration of the intervention threshold of the low...

Input power supply: 180 to 280 Vac Regulation accuracy: ± 2.5% Maximum output current: 6 A Working temperature: -20°C ÷ +70°C Standard regulation: 100 ÷ 280 Vac

Power supply: 40 ÷ 270 Vac Frequency operating range: 15 Hz ÷ 72 Hz Regulation accuracy: ± 1% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Regulation True RMS or average value measurement: 70÷280 Vac Transient voltage drop and overvoltage: within ± 15% Voltage recovery time: within ± 3% of the set value in less than 300...

Supply voltage: 40 ÷ 270 VaC Frequency operating range: 12 Hz ÷ 72 Hz Voltage regulation accuracy: ± 1% Voltage regulation accuracy (stabilized conditions): ± 0,5% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Voltage adjustment range: 75 ÷ 300 Vac Transient voltage drop and overvoltage: within ± 15% Voltage recovery time:...

Power supply: 40 to 270 Vac Frequency operating range: 12 Hz to 72 Hz Regulation accuracy: ± 1% Regulation accuracy (stabilized conditions): ± 0.5% Maximum continuous output current: 5 Adc Ambient temperature: -25°C ÷ +70°C Voltage regulation range: 75 ÷ 300 Vac Transient voltage drop and overvoltage: within ± 15% Recovery time: within ± 3% of set...

Sensing input: 80~350 VAC single phase Power supply input: voltage 50~270 VAC, frequency 50/60 Hz Magnetic field output: max. Input 63 VDC @ 220 VAC, continuous 6A Regulation accuracy: < ±1% (with 4% motor regulation) Voltage storage: residual voltage greater than 5 VAC 25 Hz External voltage regulation: 100 K ohm 1/2 watt ±7% Unit power dissipation: max....

Frequency: 50/60 Hz Low speed protection Reference: Single-phase or Three-phase

SYNCHRO AVR BL4-U 115V/230V/400V Depth: 75.5 mm Height: 45.6 mm Width: 125.5 mm Weight: 0.5kg Operating voltage: 115V / 230 V / 400 V Frequency of used: 50Hz / 60Hz

SINCRO AVR BL4 115V/230V Depth: 75.5 mm Height: 45.6 mm Width: 125.5 mm Weight: 0.5kg Operating voltage: 115V / 230V Frequency of used: 50Hz / 60Hz

SYNCRO AVR DBC1 12V/24V/48V/72V Depth: 75.5mm Height: 45.6 mm Width: 125.5 mm Weight: 0.5kg Operating voltage: 12V/24V/48V/72V Frequency of used: 50Hz / 60Hz

SINCRO AVR DBC1 12V/24V/48V/72V Depth: 75.5mm Height: 45.6 mm Width: 125.5 mm Weight: 0.5kg Operating voltage: 12V/24V/48V/72V Frequency of used: 50Hz / 60Hz

SYNCHRO AVR RD1 115 V/230 V/400 V/480 V Depth: 75.5 mm Height: 45.6 mm Width: 125.5 mm Weight: 0.5kg Operating voltage: 115V / 230V / 400 V / 480 V Frequency of used: 50Hz / 60Hz

Max. output current for continuous service: 10 A Max. output current for 10 seconds: 20 A Aux input frequency range: 0÷500 Hz Alternator nominal frequency: 50/60 Hz Temperature drop during operation: -40°C÷60°C Storage temperature range: -40°C÷80°C Overall length: 200 mm Overall width: 110 mm Overall height: 72 mm Weight: 1406 gr <br...

Max output current for continuous service: 8 A Max output current for 10 seconds: 16 A Aux input frequency range: 40÷500 Hz Alternator nominal frequency: 50/60 Hz Storage temperature range: 0°C÷55°C Storage temperature range: -20°C÷80°C Overall length: 138 mm Overall width: 58 mm Overall height: 60 mm Weight: 0. 55 Kg Saleable with...

Delta connection Rated voltage: 100÷260 V at 50/60 Hz Star connection Rated voltage: 300÷490 V at 50/60 Hz Excitation: Ie=4 A Ve&lt;=100 V Total length: 97 mm <p...

Delta connection Nominal voltage: 100÷260 V at 50/60 Hz Star connection Nominal voltage: 300÷490 V at 50/60 Hz Excitation: Ie=10 A Ve&lt;=100 V Precision in permanent regime: +- 1% Rated continuous service current: 10 A Rated excitation voltage: &lt;=100 Vdc Operating temperature range: -20 / +65°C Object length: 137 mm Object width: 108...

Nominal voltage: 100/220/400 V at 50/60 Hz Object length: 97 mm Object width: 57 mm Object height: 38 mm Weight: 0.224 Kg

Delta connection Nominal voltage: 100÷260 V at 50/60 Hz Star connection Nominal voltage: 300÷490 V at 50/60 Hz Excitation: Ie=25 A Ve&lt;=100 V Overall length: 137 mm Overall width: 108 mm Overall height: 55 mm Weight: 0.83 Kg

Delta connection Rated voltage: 100÷260 V at 50/60 Hz Star connection Rated voltage: 300÷490 V at 50/60 Hz Excitation: Ie=10 A Ve&lt;=100 V Length: 137 mm Width: 108 mm Height: 55 mm Weight: 0. 8 Kg

Triangle connection Nominal voltage: 100÷260 V at 50/60 Hz Star connection Nominal voltage: 300÷490 V at 50/60 Hz Excitation: Ie=5 A Ve&lt;=100 V Overall length: 110 mm Overall width: 58 mm Overall height: 55 mm Weight: 0.29 Kg

Input voltage: 160-280V AC Output voltage: 230V AC +/- 2% Output frequency: 50Hz +/- 0.5Hz Maximum output current : 30A Efficiency: &gt;98% Operating temperature: -20°C to +50°C Protection class: IP21

The Linz DR11 digital regulator, the heart of the PRO-DG series alternators, will allow you to monitor all the alternator parameters, giving the machine a high starting capacity, particularly suitable for the use of heavy loads.

Automatic voltage regulator RCM (loose) for T20F/ET20F alternators.

Automatic voltage regulator RCM (loose) for T16F/ET16F alternators.

Automatic voltage regulator RCM (loose) for S20F/ES20F alternators.

Automatic voltage regulator RCM (loose) for S16F alternators.

Supply voltage: 50÷150Vac Accuracy: 1% Thermal stability: 2% Max Cadd capacitor current: 8 Amp Peak volt. between 5 and 6: 650V Ext. pot. voltage regul. range: ±5% Load application transient: 200ms ΔV &lt; -10% Load removal transient: 400ms ΔV &lt;+10%

Automatic voltage regulator RCM (loose) for S16W alternators.

Automatic voltage regulator RCM (loose) for S15W alternators.

Power supply voltage: 170 ÷ 277 Vac @ 50/60 Hz Power supply source: Auxiliary windings, mains Voltage build-up: 5 Vac Voltage sensing type: 1-phase Voltage sensing range: 170 ÷ 277 Vac Maximum continuative field current: 0 ÷ 5 Adc Maximum forcing field current: 0 ÷ 8 Adc Maximum field voltage: 100 Vdc Field resistance: 8 Ω ÷ 20 Ω Regulation...

AVR VOLTAGE REGULATOR FOR RBXGND7900E

Supply voltage: 80 Vac ÷ 280 Vac - Maximum exciter field current: 10 Adc - Permanent exciter field current: 8 Adc - Detection voltage: 80 Vac ÷ 480 Vac - Gross adjustment of the output voltage via integrated Dip Switch -...
