ALTERNATORS

Phase type: Single-phase Maximum singlephase power: 4,0 KW Singlephase continuous use power: 3,2 KW Maximum singlephase power: 5,0 KVA Singlephase continuous use power: 4,5 KVA Frequency: 50 - 60 Hz Voltage: 230 V Degree of protection: IP21 Alternator speed: 3000 rpm Number of poles: 2 Acoustic pressure: 72 dBA (56 dBA at 7 m)<br...

Type of phase: Single-phase / Three-phase Maximum three-phase power: 735 KVA / 588 KW Continuous three-phase power: 680 KVA / 544 KW Maximum single-phase power: 360 KVA / 360 KW Continuous single-phase power: 335 KVA / 335 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Degree of protection: IP23 Revolutions of the 'alternator: 1500/1800 rpm Number...

Type of phase: Single-phase / Three-phase Maximum three-phase power: 601 KVA / 481 KW Continuous three-phase power: 550 KVA / 440 KW Maximum single-phase power: 315 KVA / 315 KW Continuous single-phase power: 292 KVA / 292 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Degree of protection: IP23 Revolutions of the 'alternator: 1500/1800 rpm Number...

Phase type: Single-phase Maximum singlephase power: 4,8 KW Singlephase continuous use power: 4,0 KW Maximum singlephase power: 5,7 KVA Singlephase continuous use power: 5,0 KVA Frequency: 50 - 60 Hz Voltage: 230 V Degree of protection: IP21 Alternator speed: 3000 rpm Number of poles: 2 Acoustic pressure: 72 dBA (56 dBA at 7 m)<br...

Phase Type: Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 10.5 KVA / 10.5 KW (60Hz) 12.5 KVA / 12.5 KW Continuous Single Phase Output: (50Hz) 9. 5 KVA / 9.5 KW (60Hz) 11 KVA / 11 KW Maximum three-phase output: (50Hz) 16 KVA / 12.8 KW (60Hz) 19.2 KVA / 15.4 KW Continuous three-phase output: (50Hz) 14. 5 KVA / 11.6 KW<br...

Phase Type:Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 54KVA / 54KW (60Hz) 65KVA / 65KW Continuous Single Phase Output: (50Hz) 48.8KVA / 48.8KW (60Hz) 58.5KVA / 58.5KW Maximum Three Phase Output: (50Hz) 82KVA / 65.6KW (60Hz) 98.5KVA / 78. 8KW Continuous three-phase output: (50Hz) 75KVA / 60KW (60Hz)...

Type of phase: Single / Three-phase Maximum threephase power: 440 KVA / 352 KW Continuous threephase power: 400 KVA / 320 KW Maximum singlephase power: 211 KVA / 211 KW Singlephase continuous use power: 196 KVA / 196 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Alternator type: Brushless Degree of protection : IP23 Alternator revolutions:...

Phase Type: Single Phase / Three Phase Maximum Single Phase Output: (50Hz) 12.5 KVA / 12.5 KW (60Hz) 15 KVA / 15 KW Single Phase Continuous Output: (50Hz) 11.2 KVA / 11.2 KW (60Hz) 13.4 KVA / 13.4 KW Maximum three-phase output: (50Hz) 20 KVA / 16 KW (60Hz) 24 KVA / 19.2 KW Three Phase Continuous Output: (50Hz) 18 KVA / 14.4...

Phase: Three phase Maximum three phase power: 813 KW Continuous three phase power: 744 KW Maximum three phase power: 1016 KVA Continuous three phase power: 930 KVA Frequency: 50 / 60 Hz Voltage: 400 V Protection: IP23 Rpm speed: 1500 / 1800 rpm Poles: 4 Efficiency: 95.4% Weight: 2140 Kg Constant speed alternator Brushless<br...

Phase type: Single-phase / Three-phase Maximum single-phase output: (50Hz) 5KVA / 5KW (60Hz) 6KVA / 6KW Single-phase continuous output: (50Hz) 4.6KVA / 4.6KW (60Hz) 5.5KVA / 5.5KW Maximum three-phase output: (50Hz) 7KVA / 5.6KW (60Hz) 8.4KVA / 6.7KW Three-phase continuous output: (50Hz) 6.5KVA / 5.2KW (60Hz) 7.8KVA / 6.2KW<br...

Type of phase: Single / Three-phase Maximum three-phase power: 825 KVA / 660 KW Continuous three-phase power: 750 KVA / 600 KW Maximum single-phase power: 470 KVA / 470 KW Continuous single-phase power: 435 KVA / 435 KW Frequency: 50/60 Hz Voltage: 230 V / 400 V Degree of protection: IP23 Revolutions of the 'alternator: 1500/1800 rpm Number of...

Phase: Single phase Maximum single phase power: 1.3 KW Continuous single phase power: 1.2 KW Maximum single phase power: 1.3 KVA Continuous single phase power: 1.2 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 68.7% Weight: 8.1 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 2 KW Continuous single phase power: 1.8 KW Maximum single phase power: 2 KVA Continuous single phase power: 1.8 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 70.2% Weight: 10.4 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 2.3 KW Continuous single phase power: 2.1 KW Maximum single phase power: 2.3 KVA Continuous single phase power: 2.1 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 71.4% Weight: 12.4 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 2.6 KW Continuous single phase power: 2.4 KW Maximum single phase power: 2.6 KVA Continuous single phase power: 2.4 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 71.8% Weight: 13.4 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 3.1 KW Continuous single phase power: 2.8 KW Maximum single phase power: 3.1 KVA Continuous single phase power: 2.8 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 72% Weight: 14.8 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 2.8 KW Continuous single phase power: 2.5 KW Maximum single phase power: 2.8 KVA Continuous single phase power: 2.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 74% Weight: 14.3 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 3.9 KW Continuous single phase power: 3.5 KW Maximum single phase power: 3.9 KVA Continuous single phase power: 3.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 75% Weight: 16.1 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 4.5 KW Continuous single phase power: 4.1 KW Maximum single phase power: 4.5 KVA Continuous single phase power: 4.1 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 76% Weight: 17.7 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 5.5 KW Continuous single phase power: 5 KW Maximum single phase power: 5.5 KVA Continuous single phase power: 5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 77% Weight: 21 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 6.3 KW Continuous single phase power: 5.7 KW Maximum single phase power: 6.3 KVA Continuous single phase power: 5.7 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 78% Weight: 23.7 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 6.6 KW Continuous single phase power: 6 KW Maximum single phase power: 6.6 KVA Continuous single phase power: 6 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 77.5% Weight: 27.4 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 7.7 KW Continuous single phase power: 7 KW Maximum single phase power: 7.7 KVA Continuous single phase power: 7 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 78.4% Weight: 30.5 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 6.1 KW Continuous single phase power: 5.5 KW Maximum single phase power: 6.1 KVA Continuous single phase power: 5.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79% Weight: 28 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 7.2 KW Continuous single phase power: 6.5 KW Maximum single phase power: 7.2 KVA Continuous single phase power: 6.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.5% Weight: 31 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 9.4 KW Continuous single phase power: 8.5 KW Maximum single phase power: 9.4 KVA Continuous single phase power: 8.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP21 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79% Weight: 34.9 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 9.4 KW Continuous single phase power: 8.5 KW Maximum single phase power: 9.4 KVA Continuous single phase power: 8.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79% Weight: 41.7 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 11 KW Continuous single phase power: 10 KW Maximum single phase power: 11 KVA Continuous single phase power: 10 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.2% Weight: 48.7 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 13.2 KW Continuous single phase power: 12 KW Maximum single phase power: 13.2 KVA Continuous single phase power: 12 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 80.3% Weight: 56.5 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 14.3 KW Continuous single phase power: 13 KW Maximum single phase power: 14.3 KVA Continuous single phase power: 13 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 82.1% Weight: 60 Kg Constant speed alternator Brushless Voltage...

Phase: Single phase Maximum single phase power: 5 KW Continuous single phase power: 4.5 KW Maximum single phase power: 5 KVA Continuous single phase power: 4.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.4% Weight: 25.8 Kg Constant speed alternator Brushes Voltage...

Phase: Single phase Maximum single phase power: 6.1 KW Continuous single phase power: 5.5 KW Maximum single phase power: 6.1 KVA Continuous single phase power: 5.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.8% Weight: 29.8 Kg Constant speed alternator Brushes Voltage...

Phase: Single phase Maximum single phase power: 8.8 KW Continuous single phase power: 8 KW Maximum single phase power: 8.8 KVA Continuous single phase power: 8 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.4% Weight: 41.2 Kg Constant speed alternator Brushes Voltage...

Phase: Single phase Maximum single phase power: 10.5 KW Continuous single phase power: 9.5 KW Maximum single phase power: 10.5 KVA Continuous single phase power: 9.5 KVA Frequency: 50 Hz Voltage: 230 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2 Efficiency: 79.6% Weight: 48.2 Kg Constant speed alternator Brushes Voltage...

Phase: Single phase / Three phase Maximum three phase power: 5.28 KW Continuous three phase power: 4.8 KW Maximum three phase power: 6.6 KVA Continuous three phase power: 6 KVA Continuous single phase power: 4 KW Continuous single phase power: 4 KVA Frequency: 50 Hz Voltage: 230 V / 400 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2<br...

Phase: Single phase / Three phase Maximum three phase power: 6.64 KW Continuous three phase power: 6 KW Maximum three phase power: 8.3 KVA Continuous three phase power: 7.5 KVA Continuous single phase power: 5 KW Continuous single phase power: 5 KVA Frequency: 50 Hz Voltage: 230 V / 400 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2<br...

Phase: Single phase / Three phase Maximum three phase power: 8.8 KW Continuous three phase power: 8 KW Maximum three phase power: 11 KVA Continuous three phase power: 10 KVA Continuous single phase power: 6.5 KW Continuous single phase power: 6.5 KVA Frequency: 50 Hz Voltage: 230 V / 400 V Protection: IP23 Rpm speed: 3000 rpm Poles: 2<br...

Phase: Single phase / Three phase Maximum three phase power: 11.04 KW Continuous three phase power: 10 KW Maximum three phase power: 13.8 KVA Continuous three phase power: 12.5 KVA Continuous single phase power: 8.5 KW Continuous single phase power: 8.5 KVA Frequency: 50 Hz Voltage: 230 V / 400 V Protection: IP23 Rpm speed: 3000 rpm<br...

Phase: Single phase / Three phase Maximum three phase power: 13.2 KW Continuous three phase power: 12 KW Maximum three phase power: 16.5 KVA Continuous three phase power: 15 KVA Continuous single phase power: 10 KW Continuous single phase power: 10 KVA Frequency: 50 Hz Voltage: 230 V / 400 V Protection: IP23 Rpm speed: 3000 rpm Poles:...
