CHARGERS AND UPS

Phase type: Single-phase Voltage: 230 V Frequency: 50 / 60 Hz Power absorbed in charge: 0.8 KW Charging voltage: 12 / 24 V Effective charge current: 30 A Charging current EN60335-2-29: 20 A Nom.ref.min capacity: 15 A Nom.ref.max capacity: 400 Ah Adjustment positions: 3 Length: 22.5 cm Width: 29 cm Height: 20.5 cm Weight: 8.6...

Phase type: Single-phase Voltage: 230 V Frequency: 50 / 60 Hz Power consumption in charge: 1 KW Charging voltage: 12 / 24 V Effective charge current: 45 A Charging current EN60335-2-29: 30 A Nom.ref.min capacity: 20 A Nom.ref.max capacity: 500 Ah Adjustment positions: 4 Length: 26.5 cm Width: 34.5 cm Height: 23 cm Weight: 9.9...

Phase type: Single-phase Mains voltage Three-phase: 230 V Frequency: 50 / 60 Hz Charging power: 600 W Charging voltage: 6 V /12 V / 24 V Effective charging current: 45 / 45 / 23 A Charging current EN60335-2-29: 40 / 40 / 20 A Current rating 1v/c EN60335-2-29: 40 (Boost)/70 (Start) A Maximum starting current: 1000 A Nom.ref.min. capacity: 10 Ah<br...

Phase Type: Single-phase Single-phase mains voltage: 230 V Frequency: 50 / 60 Hz Charging power: 1 KW Starting power: 10 KW Charging voltage: 12 / 24 V Effective charging current: 45 A Charging current EN60335-2-29: 30 A Current approx. 1v/c EN60335-2-29: 180 A Maximum starting current: 300 A Max. nominal ref. capacity: 450 Ah Length:...

Dry weight: 23.4 Kg Phase Type: Single-phase Single-phase mains voltage: 230 V Frequency: 50 / 60 Hz Charging power: 2 KW Starting power: 10 KW Charging voltage: 12 / 24 V Effective charging current: 90 A Charging current EN60335-2-29: 70 A Current approx. 1v/c EN60335-2-29: 360 A Maximum starting current: 570 A Nom.ref.min. capacity: 10...

DISCONTINUED PRODUCT Phase Type: Single-phase Mains voltage Single-phase: 230 V Frequency: 50 / 60 Hz Charging power: 1.6 KW Starting power: 10 KW Charging voltage: 12 / 24 V Effective charging current: 75 A Charging current EN60335-2-29: 50 A Current approx. 1v/c EN60335-2-29: 300 A Maximum starting current: 400 A<br...

Phase Type: Single-phase Mains voltage Single-phase: 230 V Frequency: 50 / 60 Hz Charging power: 2 KW Starting power: 10 KW Charging voltage: 12 / 24 V Effective charging current: 90 A Charging current EN60335-2-29: 70 A Current approx. 1v/c EN60335-2-29: 360 A Maximum starting current: 570 A Nom.ref.min. capacity: 20 Ah Max. nominal...

Phase Type: Single/Triphase Mains voltage Three-phase: 230 V/ 400V Frequency: 50 / 60 Hz Charging power: 2.5 KW Starting power: 20 KW Charging voltage: 12 / 24 V Effective charging current: 100 A Charging current EN60335-2-29: 80 A Current rating 1v/c EN60335-2-29: 640 A Maximum starting current: 1000 A Nom.ref.min. capacity: 20 Ah<br...

Phase Type: Single Phase/Three Phase Three phase mains voltage: 230V/ 400V Frequency: 50 / 60 Hz Charging power: 7 KW Starting power: 44 KW Charging voltage: 12 / 24 V Effective charging current: 150 A /250 A Charging current EN60335-2-29: 130 A / 220 A Starting current 1v/c EN60335-2-29: 1000 A / 1300 A Maximum starting current: 1700 A / 2000...

Phase Type: Single-phase/Three-phase Single-phase mains voltage: 230 V/ 400 V Frequency: 50 / 60 Hz Charging power: 2.5 KW Starting power: 20 KW Charging voltage: 12 / 24 V Effective charging current: 100 A Charging current EN60335-2-29: 80 A Current approx. 1v/c EN60335-2-29: 640 A Maximum starting current: 1000 A Nom.ref.min. capacity: 20...
