Phase type: Three-phase Frequency: 50/60 Hz Voltage: 230 V / 400 V Power: 14.5 KVA @ 60% Welding Type: MIG No-load voltage: 18 ÷ 45 V Current regulation: 30 - 400 A Maximum current: 400 A Amp. 60974-1: 40% 400 A 60% 326 A 100% 255 A Welding positions: 28 Steel wire diameter: 0.6 - 1.6 mm Stainless steel wire diameter: 0.8 - 1.2 mm<br...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2500/3000 VA Type of cut: Plasma cutter Open-circuit voltage: 310 V Current regulation: 10 - 25 A / 10 - 30 A Duty cycle at 40°: 25 A at 40% - 12 A at 100% / 30 A at 30% - 12 A at 100% Maximum current: 25 A / 30 A Separation cut: 8 mm / 10 mm Air pressure: 4.5 bar Air...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2300 W Maximum power: 13000 W Delayed fuse: 25 A Spot current: 6300 A Open-circuit voltage: 2.5 V Maximum electrode force (at 6 bar): 2 + 2 / Ø 6 + 6 mm Points / Thickness: 300 / 1 + 1 N°/mm Length: 100 mm Width: 440 mm Height: 185 mm Weight: 11.1 Kg

Power supply: 230V 50/60Hz MIG/MAG 40°C : 25 ÷ 180 A - 180 A @ 20% - 75 A @ 100% MMA 40°C: 20 ÷ 180 A - 180 A @ 20% - 75 A @ 100% TIG 40°C: 5 ÷ 180 A - 180 A @ 20% - 75 A @ 100%. Iron: Ø 0,6 ÷ 1,0 mm Stainless steel: Ø 0,8 ÷ 1,0 mm Flux-cored wire: Ø 0,9 mm Aluminium: Ø 0,8 ÷ 1,0 mm Electrode diameter: Ø 1,6 ÷ 4,0 mm Electrode type: 6013 - 7018 -...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1200 W Maximum power: 6000 W Delayed fuse: 16 A Spot current: 3800 A Open-circuit voltage: 2 V Maximum electrode force (at 6 bar): 1 + 1 / Ø 6 + 6 mm Points / Thickness: 300 / 1 + 1 N°/mm Length: 100 mm Width: 440 mm Height: 185 mm Weight: 10.6 Kg

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 VA Type of cut: Plasma cutter Open-circuit voltage: 350 V Current regulation: 10 - 40 A Duty cycle at 40°: 20 A at 40% - 25 A at 60% - 20 A at 100% Maximum current: 40 A Separation cut: 15 mm Quality cut 25 cm/min: 13 mm Air pressure: 4 - 5.5 bar Air capacity:...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 2.5 KW Welding type: MMA No-load voltage: 53 V Current regulation: 10 - 120 A Maximum current: 120 A Working cycle at 40°C: 120 A @ 20% - 70 A @ 50% - 55 A @ 100%. Duty cycle at 20°C: 120 A @ 30% - 85 A @ 60% - 65 A @ 100% Electrode diameter: 1,6 ÷ 3,2 mm Electrode...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2800 VA Type of cut: Plasma cutter Open-circuit voltage: 310 V Current regulation: 10 - 30 A Duty cycle at 40°: 30 A at 30% - 12 A at 100% Maximum current: 30 A Separation cut: 10 mm Air pressure: 4 - 5 bar Air capacity: 100 Lt/min Insulation: H Degree of...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 2.5 KW Welding type: MMA No load voltage: 70 V Current setting: 10 - 160 A Maximum current: 120 A Working cycle at 40°C: 160 A @ 15% - 80 A @ 60% - 65 A @ 100%. Working cycle at 20°C: 160 A @ 25% - 100 A @ 60% - 80 A @ 100% Electrode diameter: 1,6 ÷ 40 mm Electrode...

Supplied with the following accessories MIG welding torch length 3.0 m Ground cable. Length 2.0 m. Cable section 16mm2 Flux-cored wire reel diameter 0.9 mm - 0.5 kg Brush hammer. Power supply: 230V 50/60Hz Adjustment range: MIG - 25 -150 A - MMA - 25 - 150 A - TIG - 20 - 150 A MIG/MAG - Duty cycle 40°C: 150 A @ 25% - 95 A @ 60% - 75 A @...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 3.2 KW Welding type: MMA No-load voltage: 70 V Current regulation: 10 - 200 A Maximum current: 120 A Working cycle at 40°C: 200 A @ 15% - 100 A @ 60% - 80 A @ 100%. Working cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100% Electrode diameter: 1,6 ÷ 5.0 mm<br...

Power supply: (1ph) 230V 50/60Hz Working range: TIG - 5 ÷ 200 A - MMA - 5 ÷ 170 A TIG - Duty cycle 40°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%. MMA - Duty cycle 40°C: 170 A @ 25% - 110 A @ 60% - 85 A @ 100%. Electrode diameter: Ø 1,6 ÷ 4,0 mm Electrode type: 6013 - 7018 Insulation class: H Degree of protection: IP23S Length: 400 mm Width: 140...

Power supply: 230V 50/60Hz Adjustment Range: 10-150A Working cycle at 40°C: 150A 20% 90A 60% 70A 100% Duty cycle at 20%C: 150A 30% 105A 60% 80A 100% Copper plated steel: Ø 0,8mm Flux-cored wire (NO GAS): Ø 0,9mm Insulation class: H Degree of protection: IP22S Length: 370 mm Width: 170 mm Height: 260 mm Weight: 8 Kg

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115/230 V Power: 2300 VA (115 V) / 3300 VA (230 V) Type of cut: Plasma cutter Open-circuit voltage: 480 V Current regulation: 20 - 30 A (115 V) / 20 - 40 A (230 V) Duty cycle at 40°: 30 A at 35% - 20 A at 100% (115 V) / 40 A at 40% - 25 A at 100% (230 V) Maximum current:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5 KVA Type of cut: Plasma cutter Open-circuit voltage: 270 V Current regulation: 20 - 45 A Duty cycle at 40°: 45 A al 50% - 32 A al 100% Maximum current: 45 A Separation cut: 22 mm Quality cut 25 cm/min: 15 mm Air pressure: 5 bar Air capacity: 220 Lt/min<br...

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 65 W Battery voltage: 6/12 V Charging current: 4 A Charging capacity: 120 Ah 15h Charging positions: 4 Length: 225 mm Width: 80 mm Height: 50 mm Weight: 0.65 Kg

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 W @ 60% Welding Type: MMA No-load voltage: 60 V Current regulation: 5 - 160 A Maximum current: 160 A Amp. 60974-1: 35% 160 A - 60% 120 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 W @ 60% Welding Type: MMA/TIG No-load voltage: 60 V Current regulation: 5 - 160 A Maximum current: 160 A Amp. 60974-1: 25% 160 A - 60% 100 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 4000 W @ 60% Welding Type: MMA/TIG No-load voltage: 60 V Current regulation: 5 - 200 A Maximum current: 200 A Amp. 60974-1: 35% 200 A - 60% 150 A Electrode diameter: 1.6 - 5 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3.5 kVA @ 60% Welding Type: MMA-MIG No-load voltage: 25 ÷ 39 V Current regulation: 25 - 170 A Maximum current: 170 A Amp. 60974-1: 25% 170 A - 60 % 110 A - 100% 85 A Electrode type: 6013 (rutile) Electrode Diameter: 1.6 - 3.25 mm Steel wire...

OUT OF PRODUCTION Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 144 W Battery voltage: 12 V Maximum current: 12 A Charging current: 8 A Charging capacity: 120 Ah 15h Charging positions: 2 Length: 130 mm Width: 173 mm Height: 240 mm Weight: 2.1 Kg

OUT OF PRODUCTION Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 180 W Battery voltage: 12 V Maximum current: 15-100 A (Boost) Charging current: 10-60 A (Boost) Charging capacity: 150 Ah 15h Charging positions: 2 Length: 130 mm Width: 173 mm Height: 240 mm Weight: 3.3 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 140 W Battery voltage: 6/12 V Maximum current: 11 A Charging current: 7.5 A Charging capacity: 112 Ah 15h Charging positions: 2 Length: 200 mm Width: 260 mm Height: 175 mm Weight: 3.1 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 300 W Battery voltage: 12/24 V Maximum current: 12.5 A Charging current: 8.5 A Charging capacity: 128 Ah 15h Charging positions: 2 Length: 200 mm Width: 260 mm Height: 175 mm Weight: 4.1 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 390 W Battery voltage: 12/24 V Maximum current: 16 A Charging current: 11 A Charging capacity: 165 Ah 15h Charging positions: 2 Length: 200 mm Width: 260 mm Height: 175 mm Weight: 6.1 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 430 W Battery voltage: 12/24 V Maximum current: 18 A Charging current: 12 A Charging capacity: 180 Ah 15h Charging positions: 4 Length: 235 mm Width: 220 mm Height: 335 mm Weight: 7.8 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 600 W Battery voltage: 12/24 V Maximum current: 25 A Charging current: 17 A Charging capacity: 255 Ah 15h Charging positions: 4 Length: 235 mm Width: 220 mm Height: 335 mm Weight: 8.9 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 620 W Battery voltage: 6/12/24 V Maximum current: 25 A Charging current: 17 A Charging capacity: 255 Ah 15h Charging positions: 6 Length: 245 mm Width: 250 mm Height: 435 mm Weight: 12.2 Kg

Phase type: Single phase Voltage: 230 V Frequency: 50/60 Hz Power: 920 W Battery voltage: 6/12/24 V Maximum current: 38 A Charging current: 25 A Charging capacity: 375 Ah 15h Charging positions: 12 Length: 245 mm Width: 250 mm Height: 435 mm Weight: 17.4 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 1830 W Battery voltage: 6/12/24/36/48 V Maximum current: 38 A Charging current: 25 A Charging capacity: 375 Ah 15h Charging positions: 12 Length: 245 mm Width: 250 mm Height: 435 mm Weight: 22.2 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 720 W Battery voltage: 12/24 V Maximum current: 30 A Charging current: 20 A Charging capacity: 300 Ah 15h Charging positions: ∞ Length: 235 mm Width: 220 mm Height: 335 mm Weight: 10.1 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 21 W Battery voltage: 12 V Charging current: 1.5 A Charging capacity: 9/20 Ah 15h Length: 108 mm Width: 56 mm Height: 48 mm Weight: 0.3 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 135 W Battery voltage: 12/24 V Charging current: 7.6 A (12 V) - 3.8 A (24 V) Charging capacity: 180 Ah 15h Charging positions: 9 Length: 235 mm Width: 100 mm Height: 60 mm Weight: 0.85 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 300 W Battery voltage: 12/24 V Charging current: 16 A (12 V) - 8 A (24 V) Charging capacity: 250 Ah 15h Charging positions: 9 Length: 295 mm Width: 125 mm Height: 75 mm Weight: 1.2 Kg

OUT OF PRODUCTION Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 350 W Battery voltage: 12/24 V Charging current: 25 A / 12.5 A Charging capacity: 380 Ah 15h Charging positions: ∞ Length: 315 mm Width: 115 mm Height: 225 mm Weight: 3.5 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 1600 W Battery voltage: 12 V Charging current: 100 A Charging capacity: 1200 Ah 15h Charging positions: ∞ Length: 320 mm Width: 105 mm Height: 292 mm Weight: 4.7 Kg The package is complete with battery charger and power cord

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 190 W Battery voltage: 12 V Maximum current: 16 A Charging current: 11 A Maximum surge current: 140 Acc Charging capacity: 165 Ah 15h Charging positions: 2 + Boost Length: 200 mm Width: 260 mm Height: 175 mm Weight: 6.6 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 650 W Battery voltage: 12/24 V Maximum current: 27 A Charging current: 18 A Maximum surge current: 220 Acc Charging capacity: 270 Ah 15h Charging positions: 2 + Boost Length: 235 mm Width: 220 mm Height: 335 mm Weight: 10.7 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 1000 W Battery voltage: 12/24 V Maximum current: 42 A Charging current: 28 A Maximum surge current: 380 Acc Charging capacity: 420 Ah 15h Charging positions: 3 + Boost Length: 245 mm Width: 250 mm Height: 435 mm Weight: 16.2 Kg

Phase type: Single-phase Voltage: 230 V Frequency: 50/60 Hz Power: 460 W Battery voltage: 12 V Maximum current: 38 A Charging current: 25 A Maximum surge current: 240 Acc Charging capacity: 375 Ah 15h Charging positions: 2 + Boost Length: 235 mm Width: 220 mm Height: 335 mm Weight: 12.9 Kg
