GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA
      GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA
      GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA

      GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA

      Power Supply: Gasoline
      Starting: Manual
      Phase Type: Single Phase / Three Phase
      Maximum Single Phase Power: 2.4KVA / 1.9KW
      Maximum Three Phase Power: 7.2KVA / 5. 7KW
      Welding Current: 40 - 200 A
      Maximum Welding Current: 220 A ac
      Service (A): 200 - 35% / 170 - 60%
      Welding Type: Electrode
      Voltage: 230 / 400 V
      Frequency: 50 Hz
      Motor: Honda GX 390
      Emission Standard: Stage V
      Socket panel: 1 x Schuko 16A 230V / 1 x 32A 400 V
      3000 rpm
      Tank: 19 Lt.
      Autonomy @ 75%: 9 h fixed rpm
      Length (mm): 810
      Width (mm): 550
      Height (mm): 680
      Dry weight (Kg): 99

      Custom Quote
      Product: GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA

      PERSONAL DATA


      Ask a question
      Product: GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA
      Offer on letterhead
      Product: GENMAC Combiflash G221HO-M5 MOTOSALDATOR 7,2KVA
      GENMAC
      Combiflash G221HO-M5

      Data sheet

      Phase
      Single phase / Three phase
      Maximum power single phase (KW)
      1.9
      Maximum power single phase (KVA)
      2.4
      Maximum power three phase (KW)
      5.7
      Maximum power three phase (KVA)
      7.2
      Fuel
      Gasoline
      Frequency (Hz)
      50
      Voltage (V)
      230 / 400
      Engine
      Honda GX390
      Emissions Regulations
      Stage 5
      Engine rpm (rpm)
      3000
      Starting system
      Pull starter
      Cooling
      Air
      Poles
      2
      Welding current (A)
      200 - 35% / 170 - 60%
      Type of welding
      MMA
      Current max (A)
      220
      Fuel tank capacity (L)
      19
      Running time (h)
      9
      Length (mm)
      810
      Width (mm)
      550
      Height (mm)
      680
      Dry weight (Kg)
      99
      Silenced
      Yes
      Super silenced
      No
      Voltage regulator
      No
      Engine manufacturer
      Honda

      Specific References

      New

      GENMAC Combiflash G221HO-M5 THREE-PHASE MOTOR WELDER 7,2KVA

      Genmac Combiflash G221HO-M5 is a motorwelder is equipped with a Honda GX390 Stage V gasoline engine capable of delivering a power of 7,2KVA with capacitor voltage regulator (AVR optional).

      The Genmac Combiflash G221HO-M5 is ideal for having electrical power always at hand in any place and environment (construction sites, markets, beaches, camping or for first aid in uncomfortable areas), combined with a powerful electrode welder.

      The small size and moderate weight of the threephase 7,2KVA Genmac Combiflash G221HO-M5 motorwelder make it one of the most popular professional products in the Genmac line.

      Equipped with a Honda GX390 engine capable of delivering a output of 7.2KVA with gasoline supply and an "air" cooling system by means of a fan, it guarantees maximum efficiency and durability even for long and continuous work as both a motorwelder and a welding machine. The motorwelder generates a maximum output of 7,2KVA in just 3000 rpm.

      Start-up of the 7.2KVA Genmac Combiflash G221HO-M5 three-phase motorwelder is via an Manual start module.

      TECHNICAL CHARACTERISTICS OF GENMAC Combiflash G221HO-M5 7,2KVA

      Power Supply: Gasoline
      Starting: Manual
      Phase Type: SinglePhase / ThreePhase
      Maximum SinglePhase Power: 2.4KVA / 1.9KW
      Maximum ThreePhase Power: 7.2KVA / 5. 7KW
      Welding Current: 40 - 200 A
      Maximum Welding Current: 220 A ac
      Service (A): 200 - 35% / 170 - 60%
      Welding Type: Electrode
      Voltage: 230 / 400 V
      Frequency: 50 Hz
      Motor: Honda GX 390
      Emission Standard: Stage V
      Socket panel: 1 x Schuko 16A 230V / 1 x 32A 400 V
      3000 rpm
      Tank: 19 Lt.
      Autonomy @ 75%: 9 h fixed rpm
      Length (mm): 810
      Width (mm): 550
      Height (mm): 680
      Dry weight (Kg): 99

      If you are looking for another product then you can consult other motorwelder in our catalog.

      Images and technical data are not binding.
