CLIMMA

Product type: Control panel

Discontinued product has been replaced by  CLIMMA COMPACT 3,5 RC Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 3500 BTU/h Duct size: 100...

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Cooling capacity: 3500 BTU/h / 1000 W Heating capacity: 3500 BTU/h / 1000 W Supply Voltage: 230V Frequency: 50Hz Operating current consumption: 1.6 / 5.2 A Fan Speed: 230 m3/h Refrigerant: R134a Width: 381 mm Depth: 204 mm Height:...

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Cooling rated capacity: 25000 BTU/h / 7500 W Nominal heating capacity: 27500 BTU/h / 8000 W Power supply: 230 / 400 V Frequency: 50 / 60 Hz Operating current consumption: 9.2 - 10.9 A Minimum cold water flow rate: 22 l/min Minimum seawater flow...

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 5000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 30 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 5000 BTU/h Capacity in heat: 4500 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 30 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 5000 BTU/h Capacity in heat: 4500 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 30 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 7000 BTU/h Capacity in heat: 7000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 315 mm Width: 425 mm Height: 316 mm Weight: 31 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 7000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 315 mm Width: 425 mm Height: 316 mm Weight: 31 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 7000 BTU/h Capacity in heat: 7000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 315 mm Width: 425 mm Height: 316 mm Weight: 31 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED IN THE PACKAGE. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 9000 BTU/h Heat capacity: 9000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 31...

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 10000 BTU/h Heat capacity: 10000 BTU/h Duct size: 125 mm Maximum air flow: 530 m³/h Length: 523 mm Width: 330 mm Height: 340 mm Weight: 35 Kg

OUT OF PRODUCTION The CLIMMA COMPACT 10 RC model has been replaced by the CLIMMA COMPACT 12RC model. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 10000 BTU/h Heat capacity: 10000...

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 9000 BTU/h Heat capacity: 9000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 31 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 9000 BTU/h Duct size: 100 mm Maximum air flow: 230 m³/h Length: 520 mm Width: 300 mm Height: 295 mm Weight: 31 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 10000 BTU/h Duct size: 125 mm Maximum air flow: 530 m³/h Length: 523 mm Width: 330 mm Height: 340 mm Weight: 35 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 12000 BTU/h Heat capacity: 12000 BTU/h Duct size: 125 mm Maximum air flow: 530 m³/h Length: 523 mm Width: 330 mm Height: 340 mm Weight: 37 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 12000 BTU/h Heat capacity: 12000 BTU/h Duct size: 125 mm Maximum air flow: 530 m³/h Length: 523 mm Width: 330 mm Height: 340 mm Weight: 37 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 12000 BTU/h Duct size: 125 mm Maximum air flow: 530 m³/h Length: 523 mm Width: 330 mm Height: 340 mm Weight: 37 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 16000 BTU/h Heat capacity: 7000 BTU/h Duct size: 150 mm Maximum air flow: 900 m³/h Length: 605 mm Width: 368 mm Height: 352 mm Weight: 46 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 16000 BTU/h Duct size: 150 mm Maximum air flow: 900 m³/h Length: 605 mm Width: 368 mm Height: 352 mm Weight: 46 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 115 / 230 V Frequency: 50 / 60 Hz Cold capacity: 16000 BTU/h Heat capacity: 16000 BTU/h Duct size: 150 mm Maximum air flow: 900 m³/h Length: 605 mm Width: 368 mm Height: 352 mm Weight: 46 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 17000 BTU/h Heat capacity: 17000 BTU/h Duct size: 2x100 mm Maximum air flow: 600 m³/h Length: 800 mm Width: 398 mm Height: 288 mm Weight: 48 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 17000 BTU/h Heat capacity: 17000 BTU/h Duct size: 2x100 mm Maximum air flow: 600 m³/h Length: 800 mm Width: 398 mm Height: 288 mm Weight: 48 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 17000 BTU/h Duct size: 2x100 mm Maximum air flow: 600 m³/h Length: 800 mm Width: 398 mm Height: 288 mm Weight: 48 Kg

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 Hz Cold capacity: 24000 BTU/h Heat capacity: 24000 BTU/h Duct size: 2x125 mm Maximum air flow: 2x540 m³/h Length: 800 mm Width: 398 mm Height: 415 mm

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 / 60 Hz Cold capacity: 24000 BTU/h Heat capacity: 24000 BTU/h Duct size: 2x125 mm Maximum air flow: 2x540 m³/h Length: 800 mm Width: 398 mm Height: 415 mm

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Single-phase Voltage: 230 V Frequency: 50 / 60 Hz Cold capacity: 24000 BTU/h Duct size: 2x125 mm Maximum air flow: 2x540 m³/h Length: 800 mm Width: 398 mm Height: 415 mm

ATTENTION: THE CONTROL PANEL IS NOT INCLUDED. IT IS AVAILABLE AS AN OPTIONAL ACCESSORY. Phase type: Three-phase Voltage: 400 V Frequency: 50 Hz Cold capacity: 27000 BTU/h Duct size: 2x150 mm Maximum air flow: 2x875 m³/h Length: 1010 mm Width: 420 mm Height: 516 mm Weight: 100 Kg

Voltage: 230 V Frequency: 50 Hz Flow rate: 1500 l/h Length: 144 mm Width: 151 mm Height: 284 mm Weight: 5 Kg

Control panel for Climma Compact and Split air conditioners ADJUSTMENTS: Temperature and fan speed adjustment with intuitive operation knobs, Single on/off button. DISPLAY: Large digital display with room temperature indication. The display indicates the fan speed and temperature setting at the touch of the knob. Automatic display brightness adjustment with an ambient...

Particularly quiet magnetic drive centrifugal pump. Pump body and impeller made of plastic material filled with glass resin. Ventilated motor suitable for operation at max 45°C ambient temperature. Stainless steel base with rubber vibration dampers. TECHNICAL CHARACTERISTICS. Rated capacity Btu/h 30,000 Consumption 135W Flow rate L/m' 25 Prevalence mt 5<br...

CLIMMA 1" AQUAMARINE FILTER WITH FITTINGS AND SUPPORT BRACKET

CLIMMA SEA SOCKET 1/2" BRASS

CLIMMA SEA WATER DRAIN 1/2" CHROME PLATED BRASS

CLIMMA FAUCET SPHERE BRASS 1/2"

CLIMMA GRILLE ANODIZED ALUMINUM INTAKE 252X252

CLIMMA ANODIZED ALUMINUM GRILLE 202X100

CLIMMA TRIANGULAR PLENUM 256 X 131 X 160 INSULATED
