Rated power at 50 Hz (kVA): 6.5 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 2.6 at 50 Hz<br...

Rated power at 50 Hz (kVA): 1250 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP23 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 94 at 50 Hz<br...

Power supply voltage input: a) 110 Vac ±15% b) 220 Vac -25%/+15%. Max field current: 10 Adc Permanent field current: 7 Adc Single-phase reference voltage input: 90 Vac ÷ 440 Vac Alternator output voltage calibration with multi-turn trimmer Stability control calibration with multi-turn trimmer Calibration of the intervention threshold of the low...

Rated power (kVA): 8 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Suppression standard R.F.F.I. EN55011

Rated power at 60 Hz (kVA): 360 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP23 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Suppression standard R.F.F.I. EN55011

Rated power at 50Hz (kVA): 2.2 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 3.80 at 50Hz<br...

Rated power at 60 Hz (kVA): 30 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP23 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Suppression standard R.F.F.I. EN55011

Rated power at 50 Hz (kVA): 20 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: with brushes Type of regulation: Compound Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.6 at 50 Hz<br...

Rated power at 50 Hz (kVA): 15 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP23 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 5.2 at 50 Hz<br...

Rated power at 50 Hz (kVA): 1500 Rated power factor: 0.8 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: AVR Insulation class: H Protection: IP23 Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 105 at 50 Hz<br...

Rated power at 50 Hz (kVA): 8 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 1500 rpm Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 5.1 at...

Input voltage: 160-280V AC Output voltage: 230V AC +/- 2% Output frequency: 50Hz +/- 0.5Hz Maximum output current : 30A Efficiency: &gt;98% Operating temperature: -20°C to +50°C Protection class: IP21

The Linz DR11 digital regulator, the heart of the PRO-DG series alternators, will allow you to monitor all the alternator parameters, giving the machine a high starting capacity, particularly suitable for the use of heavy loads.

Rated power at 60 Hz (kVA): 8 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 1500 rpm Maximum excess travel speed (rpm): 2250 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 6.4 at...

Supply voltage: 80 Vac ÷ 280 Vac - Maximum exciter field current: 10 Adc - Permanent exciter field current: 8 Adc - Detection voltage: 80 Vac ÷ 480 Vac - Gross adjustment of the output voltage via integrated Dip Switch -...

Phase Type: Single-phase / Three-phase Continuous Power Single-phase: 8.33 KVA / 8.33 KW Continuous Power Three-phase: 25 KVA / 25 KW Voltage: 230 / 400 V Frequency: 50 Hz PTO Power output (rpm required 540): 40. 5 HP Tractor power required: 70 HP PTO speed: 430 rpm Alternator: PRO18S B/4 Voltage regulator: AVR Length: 1152 mm Width: 960...

Phase Type: Single Phase / Three Phase Continuous Power: 10 KVA Continuous Power: 10 KW Voltage: 230 / 400 V Frequency: 50 Hz PTO Power i output (rpm required 540): 17.6 HP Tractor power required: 32 HP PTO RPM: 430 rpm Alternator: E1S13S B/4 Voltage regulator: Compound Length: 1152 mm Width: 960 mm Height: 1025 mm Weight: 165...

Phase type: Single phase / Three phase Continuous power: 16 KVA Continuous power: 16 KW Voltage: 230 / 400 V Frequency: 50 Hz PTO Power output (rpm required 540): 27.2HP Tractor power required: 50 HP PTO revs: 430 rpm Alternator: E1S13S E/4 Voltage regulator: Compound Length: 1152 mm Width: 960 mm Height: 1025 mm Weight: 191...

Rated Power at 50Hz (kVA): 1,7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,85 at 50Hz<br...

Rated Power at 60Hz (kVA): 2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,85 at 60Hz R.F.I....

Rated Power at 50Hz (kVA): 2.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,80 at 50Hz<br...

Rated Power at 60Hz (kVA): 2.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,80 at 60Hz<br...

Rated Power at 50Hz (kVA): 2.6 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,80 at 50Hz<br...

2x SCHUKO plugs and 1x breaker fixed on top panel. Not binding images and data.

Rated Power at 60Hz (kVA): 3.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,80 at 60Hz<br...

Rated Power at 50Hz (kVA): 3 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,75 at 50Hz R.F.I....

1x CEE 16A 230V plug,1x SCHUKO plug and 1x breaker fixed on rear cover. Not binding images and data.

Rated Power at 60Hz (kVA): 3.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,7 at 60Hz R.F.I....

1x CEE 16A 230V plug,1x SCHUKO plug and 1x breaker fixed on top panel. Not binding images and data.

Rated Power at 50Hz (kVA): 3.5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,75 at 50Hz<br...

2x SCHUKO plugs and 1x breaker fixed on rear cover. Not binding images and data.

Rated Power at 60Hz (kVA): 3.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,7 at 60Hz R.F.I....

1x SCHUKO plug, 1x breaker and 1x earth leakage breaker (with IP65 cover) fixed on top panel. Not binding images and data.

Rated Power at 50Hz (kVA): 4.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,7 at 50Hz R.F.I....

LINZ 12 Vdc Battery Charger Kit (winding with fuse, fuseholder and terminal posts) for RAK rear cover. Not binding images and data.

Rated Power at 60Hz (kVA): 5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,6 at 60Hz R.F.I....

LINZ 12 Vdc Battery Charger Kit (winding with fuse, fuseholder and terminal posts) for TAK top panel. Not binding images and data.

Rated Power at 50Hz (kVA): 5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,7 at 50Hz R.F.I....
