CGM 220SBET - MOTOSALDATRICE A STRAPPO

Name: CGM 220SBET - MOTOSALDATRICE A STRAPPO
Brand: CGM
SKU: CGM 220SBET /
Price: 2288.72 EUR
Availability: InStock

Reference CGM 220SBET /

OUT OF STOCK

Phase type : Three-phase
Maximum three-phase power: 5.2 KW / 6.5 KVA
Maximum single-phase power: 2.8 KW / 3. 5 KVA
Engine : Briggs & Stratton 16
Fuel : Gasoline
Cylinders : 2
Displacement : 389 cm3
Max Engine Power : 16 HP
Max Welding Current : 200-170 A at 35%/60%
Tank : 8. 5 Lt
Sockets : 1 CEE 3-pole 230V socket, 1 CEE 5-pole 400V socket
Power supply : Electric with battery
Acoustic power : 70 dB(A) at 7 m
Voltage : 230 V / 400 V
Frequency : 50 Hz
Power factor : 0. 8
Welding current : 40-220 A
Number of turns : 3000 rpm
Cooling : Air
Autonomy : 2.2 h
Consumption at 3/4 load : 3.8 L/h
Oil capacity : 1. 7 Lt
Alternator : SINCRO, with brushes
Number of Poles : 2
Number of Phases : 3
Welding voltage : 21.5 - 28.8 V
Power consumption : 11. 5 hp / 8.5 KW
Voltage regulation : Compound
Width : 860 mm
Length : 550 mm
Height : 650 mm
Weight : 130 Kg

List price

3,330.60 € tax incl.

2,730.00 € tax excl.

Discounted Price

2,288.72 € tax incl.

1,876.00 € tax excl.

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference CGM 220SBET /

Data sheet

Phase: Three phase
Maximum power single phase (KW): 2.8
Maximum power single phase (KVA): 3.5
Maximum power three phase (KW): 5.2
Maximum power three phase (KVA): 6.5
Fuel: Gasoline
Frequency (Hz): 50
Voltage (V): 230 / 400
Sockets configuration: 1 x 230V 3P CEE + 1 x 400V 5P CEE
Engine: Briggs&Stratton
Engine rpm (rpm): 3000
Starting system: Electric
Engine capacity (cm³): 389
Number cylinders: 2
Oil capacity (L): 1.7
Cooling: Air
Alternator: With brushes
Poles: 2
Welding current (A): 200 at 35% / 170 at 60%
Welding voltage min/max (V): 21.5 / 28.8
Fuel tank capacity (L): 8.5
Consumption (L/h): 3.8 al 75% del carico
Running time (h): 2.2
Acoustic pressure: 70 dB(A) at 7 m
Length (mm): 550
Width (mm): 860
Height (mm): 650
Dry weight (Kg): 130
Compound: Yes
Silenced: Yes
Super silenced: No

Specific References

Condition New

CGM 220SBET - THREEPHASE MOTORWELDING

CGM 220SBET is a lightweight and versatile three-phase motorwelder equipped with a Honda GX270 gasoline engine capable of delivering a maximum output of 6.5KVA.

The CGM 220SBET motorwelder features Honda gasoline engines with recoil start. Mounted on a fixed base and operating at 3000 rpm, they are suitable for welding and three-phase 400V power supply.

TECHNICAL CHARACTERISTICS CGM 220SBET

Phase type : Threephase
Maximum threephase output: 5.2 KW / 6.5 KVA
Maximum singlephase output: 2.8 KW / 3. 5 KVA
Engine : Briggs & Stratton 16
Fuel : Gasoline
Cylinders : 2
Displacement : 389 cm3
Max Engine Output: 16 HP
Max Welding Current : 200-170 A at 35%/60%
Tank : 8. 5 Lt
Sockets : 1 CEE 3-pole 230V socket, 1 CEE 5-pole 400V socket
Power supply : Electric with battery
Acoustic power : 70 dB(A) at 7 m
Voltage : 230 V / 400 V
Frequency : 50 Hz
Power factor : 0. 8
Welding current : 40-220 A
Number of turns : 3000 rpm
Cooling : Air
Autonomy : 2.2 h
Consumption at 3/4 load : 3.8 L/h
Oil capacity : 1. 7 Lt
Alternator : SINCRO, with brushes
Number of Poles : 2
Number of Phases : 3
Welding voltage : 21.5 - 28.8 V
Output consumption : 11. 5 hp / 8.5 KW
Voltage regulation : Compound
Width : 860 mm
Length : 550 mm
Height : 650 mm
Weight : 130 Kg

Are you looking for a welding machine with different technical characteristics? Here you can find the full range of CGM or other specialized brands

Images and technical data are not binding and may be subject to revision by the supplier.
