WELDERS

Phase type: Three-phase Frequency: 50/60 Hz Voltage: 230 V / 400 V Power: 14.5 KVA @ 60% Welding Type: MIG No-load voltage: 18 ÷ 45 V Current regulation: 30 - 400 A Maximum current: 400 A Amp. 60974-1: 40% 400 A 60% 326 A 100% 255 A Welding positions: 28 Steel wire diameter: 0.6 - 1.6 mm Stainless steel wire diameter: 0.8 - 1.2 mm<br...

Power supply: 230V 50/60Hz MIG/MAG 40°C : 25 ÷ 180 A - 180 A @ 20% - 75 A @ 100% MMA 40°C: 20 ÷ 180 A - 180 A @ 20% - 75 A @ 100% TIG 40°C: 5 ÷ 180 A - 180 A @ 20% - 75 A @ 100%. Iron: Ø 0,6 ÷ 1,0 mm Stainless steel: Ø 0,8 ÷ 1,0 mm Flux-cored wire: Ø 0,9 mm Aluminium: Ø 0,8 ÷ 1,0 mm Electrode diameter: Ø 1,6 ÷ 4,0 mm Electrode type: 6013 - 7018 -...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 2.5 KW Welding type: MMA No-load voltage: 53 V Current regulation: 10 - 120 A Maximum current: 120 A Working cycle at 40°C: 120 A @ 20% - 70 A @ 50% - 55 A @ 100%. Duty cycle at 20°C: 120 A @ 30% - 85 A @ 60% - 65 A @ 100% Electrode diameter: 1,6 ÷ 3,2 mm Electrode...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 2.5 KW Welding type: MMA No load voltage: 70 V Current setting: 10 - 160 A Maximum current: 120 A Working cycle at 40°C: 160 A @ 15% - 80 A @ 60% - 65 A @ 100%. Working cycle at 20°C: 160 A @ 25% - 100 A @ 60% - 80 A @ 100% Electrode diameter: 1,6 ÷ 40 mm Electrode...

Supplied with the following accessories MIG welding torch length 3.0 m Ground cable. Length 2.0 m. Cable section 16mm2 Flux-cored wire reel diameter 0.9 mm - 0.5 kg Brush hammer. Power supply: 230V 50/60Hz Adjustment range: MIG - 25 -150 A - MMA - 25 - 150 A - TIG - 20 - 150 A MIG/MAG - Duty cycle 40°C: 150 A @ 25% - 95 A @ 60% - 75 A @...

Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power 60%: 3.2 KW Welding type: MMA No-load voltage: 70 V Current regulation: 10 - 200 A Maximum current: 120 A Working cycle at 40°C: 200 A @ 15% - 100 A @ 60% - 80 A @ 100%. Working cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100% Electrode diameter: 1,6 ÷ 5.0 mm<br...

Power supply: (1ph) 230V 50/60Hz Working range: TIG - 5 ÷ 200 A - MMA - 5 ÷ 170 A TIG - Duty cycle 40°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%. MMA - Duty cycle 40°C: 170 A @ 25% - 110 A @ 60% - 85 A @ 100%. Electrode diameter: Ø 1,6 ÷ 4,0 mm Electrode type: 6013 - 7018 Insulation class: H Degree of protection: IP23S Length: 400 mm Width: 140...

Power supply: 230V 50/60Hz Adjustment Range: 10-150A Working cycle at 40°C: 150A 20% 90A 60% 70A 100% Duty cycle at 20%C: 150A 30% 105A 60% 80A 100% Copper plated steel: Ø 0,8mm Flux-cored wire (NO GAS): Ø 0,9mm Insulation class: H Degree of protection: IP22S Length: 370 mm Width: 170 mm Height: 260 mm Weight: 8 Kg

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 W @ 60% Welding Type: MMA No-load voltage: 60 V Current regulation: 5 - 160 A Maximum current: 160 A Amp. 60974-1: 35% 160 A - 60% 120 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 W @ 60% Welding Type: MMA/TIG No-load voltage: 60 V Current regulation: 5 - 160 A Maximum current: 160 A Amp. 60974-1: 25% 160 A - 60% 100 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 4000 W @ 60% Welding Type: MMA/TIG No-load voltage: 60 V Current regulation: 5 - 200 A Maximum current: 200 A Amp. 60974-1: 35% 200 A - 60% 150 A Electrode diameter: 1.6 - 5 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3.5 kVA @ 60% Welding Type: MMA-MIG No-load voltage: 25 ÷ 39 V Current regulation: 25 - 170 A Maximum current: 170 A Amp. 60974-1: 25% 170 A - 60 % 110 A - 100% 85 A Electrode type: 6013 (rutile) Electrode Diameter: 1.6 - 3.25 mm Steel wire...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2500 W Type of welding: MMA No-load voltage: 70 V Current regulation: 10 - 120 A Duty cycle at 40°: 120 A at 25% - 80 A at 50% - 60 A at 100% Maximum current: 120 A Electrode diameter: 1.6 - 3.2 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2500 W Type of welding: MMA No-load voltage: 70 V Current regulation: 10 - 160 A Duty cycle at 40°: 160 A at 25% - 100 A at 60% - 80 A at 100%. Maximum current: 160 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3200 W Type of welding: MMA No-load voltage: 70 V Current regulation: 10 - 200 A Duty cycle at 40°: 200 A at 25% - 130 A at 60% - 100 A at 100%. Maximum current: 200 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 4800 W Type of welding: MMA / TIG Open-circuit voltage: 52 V Current regulation: 5 - 160 A Duty cycle at 40°: 160 A at 60% - 130 A at 100% Maximum current: 160 A Electrode diameter: 1.6 - 4 mm Electrode type: 6013 - 7018 Insulation: H Degree of protection: IP23S<br...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115 V / 230 V Power: 2700 W (115 V) / 2900 W (230 V) Type of welding: MMA / TIG Open-circuit voltage: 55 V Current regulation: 10 - 100 A (115 V) / 10 - 200 A (230 V) Duty cycle at 40°: 100 A at 30% - 80 A at 60% (115 V) / 200 A at 25% - 130 A at 60% (230 V) Max. current:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5300 W (MMA) / 4200 W (TIG) Type of welding: MMA / TIG Open-circuit voltage: 64 V Current regulation: 10 - 170 A (MMA) / 10 - 200 A (TIG) Duty cycle at 40°: 170 A at 25% - 110 A at 60% - 85 A at 100% (MMA) / 200 A at 25% - 130 A at 60% - 100 A at 100% (TIG) Maximum current: 170 A (MMA)...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2400 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 28 V Current regulation: 30 - 145 A Duty cycle at 40°: 130 A at 20% - 75 A at 60% Maximum current: 145 A Adjustment positions: 4 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3000 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 37 V Current regulation: 30 - 170 A Duty cycle at 40°: 165 A at 15% - 83 A at 60% Maximum current: 170 A Adjustment positions: 6 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3000 W Type of welding: MIG / MAG Open-circuit voltage: 23 - 42 V Current regulation: 30 - 180 A Duty cycle at 40°: 180 A at 15% - 93 A at 60% Maximum current: 180 A Adjustment positions: 6 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

PRODUCT OUT OF PRODUCTION AND HAS BEEN REPLACED BY: HELVI GALILEO 200 Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power: 6000 W Welding type: MMA / TIG No-load voltage: 48 V Current regulation: 5 -...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 4600 W Type of welding: MIG / MAG No-load voltage: 19 - 34 V Current regulation: 30 - 220 A Duty cycle at 40°: 200 A at 20% - 125 A at 60% Maximum current: 220 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding wire diameter: 0.8 - 1...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5500 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 200 A at 35% - 145 A at 60% Maximum current: 250 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding wire diameter:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 7400 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 46 V Current regulation: 30 - 280 A Duty cycle at 40°: 250 A at 30% - 180 A at 60% Maximum current: 280 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1.2 mm Stainless steel welding wire diameter:...

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 3500 W Type of welding: MIG / MAG Open-circuit voltage: 16.5 - 32 V Current regulation: 30 - 190 A Duty cycle at 40°: 190 A at 25% - 130 A at 60% Maximum current: 190 A Adjustment positions: 7 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 5900 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 38 V Current regulation: 30 - 240 A Duty cycle at 40°: 230 A at 35% - 175 A at 60% Maximum current: 240 A Adjustment positions: 7 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding...

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 6400 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 250 A at 30% - 185 A at 60% Maximum current: 250 A Adjustment positions: 10 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 6400 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 250 A at 30% - 185 A at 60% Maximum current: 250 A Adjustment positions: 10 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 9500 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 45 V Current regulation: 30 - 300 A Duty cycle at 40°: 300 A at 35% - 230 A at 60% - 180 A at 100% Maximum current: 300 A Adjustment positions: 14 Steel welding wire diameter: 0.6 - 1.2 mm<br...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 150 A (MMA) / 25 - 150 A (MIG) Duty cycle at 40°: 100 A at 40% - 65 A at 100% (MMA) / 150 A at 25% - 75 A at 100% (MIG) Maximum current: 150 A Steel welding wire diameter:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 180 A (MMA) / 25 - 180 A (MIG) Duty cycle at 40°: 180 A at 20% - 75 A at 100% Maximum current: 180 A Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 150 A (MMA) / 25 - 150 A (MIG) Duty cycle at 40°: 100 A at 40% - 65 A at 100% (MMA) / 150 A at 25% - 75 A at 100% (MMA) Maximum current: 150 A Steel welding wire diameter:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5500 VA Type of welding: Multiprocess Open-circuit voltage: 65 V (MMA) / 65 V (TIG) / 35 V (MIG) Current regulation: 5 - 200 A (MMA) / 5 - 200 A (TIG) / 20 - 200 A (MIG) Duty cycle at 40°: 200 A at 35% - 120 A at 100% (MMA) / 200 A at 35% - 120 A at 100% (TIG) / 200 A at 35% - 140 A at 100%...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115 V / 230 V Power: 2700 W (115 V) / 2900 W (230 V) Type of welding: MMA / TIG Open-circuit voltage: 55 V Current regulation: 10 - 100 A (115 V) / 10 - 160 A (230 V) Duty cycle at 40°: 100 A at 30% - 80 A at 60% (115 V) / 160 A at 25% - 105 A at 60% (230 V) Maximum current: 100 A (115 V) / 160 A...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2800 VA Type of welding: Multiprocess Open-circuit voltage: 55 V (MMA) / 55 V (TIG) / 27 V (MIG) Current regulation: 5 - 160 A (MMA) / 5 - 170 A (TIG) / 25 - 170 A (MIG) Duty cycle at 40°: 170 A at 25% - 110 A at 60% - 85 A at 100% (MMA) / 170 A at 25% - 110 A at 60% - 85 A at 100% (TIG) /...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power : 2500 VA Power peak: 13000 VA Delayed fuse: T16 A Type of welding: Spot welding No-load voltage: 8 V Output current: 2850 A Maximum output current: 3200 A Insulation: H Degree of protection: IP22S Length: 250 mm Width: 370 mm Height : 280 mm Weight:...

Discontinued Product Phase type: Three-phase Frequency: 50/60 Hz Voltage: 400 V Power: 6000 VA Power peak: 13000 VA Delayed fuse: T20 A Type of welding: Spot welding No-load voltage: 7.5 V Output current : 3600 A Maximum output current: 5000 A Insulation: H Degree of protection: IP22S Length: 370 mm<br...

Power supply: (1ph) 230V ± 10% - 50/60Hz Abs. power 60%: MIG: 5.6 KW / MMA: 5.6 KW / TIG: 5.6 KW Open circuit voltage: MIG: 30 V / MMA: 56 V / TIG: 10 V Regulation range: MIG: 30 ÷ 250 A / MMA: 20 ÷ 200 A / TIG: 10 ÷ 250 A Duty cycle 40°C: MIG: 250A @ 30%-190A @ 60%-170A @ 30% / MMA: 200A @ 30%-170A @ 60%-150A @ 100% / TIG: 250A @ 30%-190A @ 60%-170A @ 100% Iron: 0.8...

Power supply: (3ph) 400V ± 10% • 50/60H Continuous power at 60%: 4.8 kW No-load voltage: 30 V Regulation range: 30 ÷ 250A Duty cycle at 40°C: 250A @ 35% / 190A @ 60% / 150A @ 100% Iron: 0.8 ÷ 1.0 Ø mm Stainless steel: 0.8 ÷ 1.0 Ø mm Aluminum: 1.0 ÷ 1.2 Ø mm Stranded wire: 1.0 ÷ 1.2 Ø mm CuSi₃: 0.8 Ø mm Insulation: H Protection class:...
