HELVI MAKER171

HELVI MAKER171 is a portable welding machine with inverter technology for electrode welding, ideal electrode diameter of 2.5 mm.

The hot start device facilitates electrode ignition.

The arc force device automatically increases the welding current in case the arc is too short.

The Anti-sticking device that prevents the electrode from sticking to the workpiece.

The HELVI MAKER171 is suitable for use with any motor generator.

TECHNICAL FEATURES HELVI MAKER171

Phase type: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Power 60%: 2. 5 KW
Welding type: MMA
No-load voltage: 70 V
Current setting: 10 - 160 A
Maximum current: 120 A
Work cycle at 40°C: 160 A @ 15% - 80 A @ 60% - 65 A @ 100%
Work cycle at 20°C: 160 A @ 25% - 100 A @ 60% - 80 A @ 100%
Electrode diameter: 1.6 ÷ 40 mm
Electrode type: 6013 - 7018
Isolation: H
Protection class: IP22S
Length: 285 mm
Width: 120 mm
Height: 255 mm
Weight: 2. 8 Kg

Looking for a portable welding machine with different features? Here you can find the full range of HELVI or other specialized brands

Images and technical data are not binding and may be subject to revision by the supplier
