HELVI MAKER211 PORTABLE WELDING MACHINE
Phase type: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Power 60%: 3.2 KW
Welding type: MMA
No-load voltage: 70 V
Current regulation: 10 - 200 A
Maximum current: 120 A
Working cycle at 40°C: 200 A @ 15% - 100 A @ 60% - 80 A @ 100%.
Working cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%
Electrode diameter: 1,6 ÷ 5.0 mm
Electrode type: 6013 - 7018
Insulation: H
Degree of protection: IP22S
Length: 285 mm
Width: 120 mm
Height: 255 mm
Weight: 3.2 Kg
List price
tax incl.
tax excl.
Discounted Price
268.40 € tax incl.
220.00 € tax excl.
Shipping Free to Italy buy it today.
Calculate Shipping Cost
99805999
Data sheet
- Phase
- Single phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 230
- Cooling
- Air
- Protection degree
- IP22S
- Motor insulation class
- H
- No-load voltage (V)
- 70
- Regulation current (A)
- 10 ÷ 200 A
- Welding current (A)
- 200
- Amp. 60974-1 (40°)
- 200 A @15% • 100 A @ 60% • 80 A @ 100%
- Diameter electrodes (mm)
- 1,6 ÷ 5.0
- Maximum diameter electrodes (mm)
- 5.0
- Type of welding current
- DC
- Type of welding
- MMA / MIG
- Current max (A)
- Power consumption (W)
- 3200
- Length (mm)
- 285
- Width (mm)
- 120
- Height (mm)
- 255
- Voltage regulator
- Inverter
- Weight (Kg)
- 3.2
Specific References
New
HELVI MAKER211
HELVI MAKER211 is a portable welder with inverter technology for electrode welding, ideal electrode diameter of 4.0 mm.
With HELVI MAKER211 you can weld with all commercial electrodes, the output is safe thanks to the internal protection systems, it protects itself in case of overvoltage and overcurrent.
The HELVI MAKER211 welder comes in a case complete with a 3.0-meter-long, 16mm2-section electrode cable, ground cable, and a plastic welding mask.
The HELVI MAKER211 is equipped with various devices to enhance welding, including:
The hot start device facilitates electrode initiation.
The arc force device automatically increases the welding current in case the arc is too short.
The Anti-sticking device that prevents the electrode from sticking to the workpiece.
The HELVI MAKER211 is suitable for use with any motor generator.
TECHNICAL FEATURES HELVI MAKER211
Phase type: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Power 60%: 3. 2 KW
Welding type: MMA
No-load voltage: 70 V
Current setting: 10 - 200 A
Maximum current: 120 A
Work cycle at 40°C: 200 A @15% - 100 A @ 60% - 80 A @ 100%
Work cycle at 20°C: 200 A @ 25% - 130 A @ 60% - 100 A @ 100%
Electrode diameter: 1.6 ÷ 5. 0 mm
Electrode type: 6013 - 7018
Isolation: H
Protection class: IP22S
Length: 285 mm
Width: 120 mm
Height: 255 mm
Weight: 3.2 kg
Looking for a portable welding machine with different features? Here you can find the full range of HELVI or other specialized brands
Images and technical data are not binding and may be subject to revision by the supplier
