MOSA TS 200 DES/CF MMA Arc Welder Engine STAGE 5
C0HP5060
Fuel: Diesel
Phase Type: Single / ThreePhase
Voltage: 48 V / 230 V / 400 V
Single-phase power 230 V (kVA): 5
Three-phase power 400 V (kVA): 6
Duty Cycle (A): 190 A al 35% - 160 A al 60% - 120 A al 100%
Welding output: CC
Type of welding: MMA STICK
Electrodes: any kind up to 4 mm
Silenced: NO
Lenght (mm): 900
Width (mm): 550
Height (mm): 620
Dry weight (Kg): 150
Electric Starter
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 4
- Maximum power single phase (KVA)
- 5
- Maximum power three phase (KW)
- 4.8
- Maximum power three phase (KVA)
- 6
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A 3P+N+T CEE - 1 x 230V 16A 2P+T CEE - 1 x 48V 32A 2P CEE
- Engine
- YANMAR L100V STAGE 5
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 3000
- Starting system
- Elettrico
- Engine capacity (cm³)
- 435
- Number cylinders
- 1
- Cooling
- Air
- Inyección
- Direct
- Alternator
- Asynchronous three-phase, self-excited, self-regulated, brushless
- Regulation current (A)
- 20 - 190
- Welding current (A)
- 190 at 35% - 160 at 60% - 120 at 100%
- Open circuit voltage (V)
- 98
- Maximum diameter electrodes (mm)
- 4
- Type of welding current
- DC
- Type of welding
- MMA
- Fuel tank capacity (L)
- 5.5
- Consumption (L/h)
- 1
- Running time (h)
- 5.5
- Acoustic power
- 99 dB(A)
- Acoustic pressure
- 74 dB(A) at 7 m
- Length (mm)
- Width (mm)
- 550
- Height (mm)
- 620
- Dry weight (Kg)
- Silenced
- No
- Super silenced
- No
- Engine manufacturer
- Yanmar
- Brand
-
The engine-driven welder TS-200 DES/CF is a lightweight machine without electronics: the welding current is adjusted by changing the rpm of the engine.
Equipped with a YANMAR L100N diesel engine with electrical start-up and an asynchronous alternator, it can be used as a welder or as a three-phase and single-phase electrical generator up to 6 kVA.
The welding current is continuous and has two welding scales (20-100A / 90-190A) that are selectable by connecting to two different welding sockets. You can weld with electrodes up to 4 mm in diameter.
An engine-driven welder suitable for a wide range of uses from maintenance to site welding and pipe fabrication.
In according with CE regulation
WELDING
Current range, continuous: 20 ÷ 100A / 90 ÷ 190A
Duty cycle: 190 A 35% - 160 A 60% - 120 A 100%
Open circuit voltage: 98 V
Arc welding source in D.C. welding
Welds any type of electrode, including cellulosic
Double welding scale 20-100A / 90-190A
A.C. generator, single-phase and three-phase
GENERAL
Sockets: 1x400V 16A 3P+N+T CEE - 1x230V 16A 2P+T CEE - 1x48V 32A 2P CEE
Protective frame
Dry weight TS 200 DES/CF: 150 kg
Dimensions: 900x550x620 mm
Acoustic power LwA (pressure LpA): 99 dB(A) (74 dB(A) @ 7 m)
Non-binding images and technical data.
Equipped with a YANMAR L100N diesel engine with electrical start-up and an asynchronous alternator, it can be used as a welder or as a three-phase and single-phase electrical generator up to 6 kVA.
The welding current is continuous and has two welding scales (20-100A / 90-190A) that are selectable by connecting to two different welding sockets. You can weld with electrodes up to 4 mm in diameter.
An engine-driven welder suitable for a wide range of uses from maintenance to site welding and pipe fabrication.
In according with CE regulation
WELDING
Current range, continuous: 20 ÷ 100A / 90 ÷ 190A
Duty cycle: 190 A 35% - 160 A 60% - 120 A 100%
Open circuit voltage: 98 V
Arc welding source in D.C. welding
Welds any type of electrode, including cellulosic
Double welding scale 20-100A / 90-190A
A.C. generator, single-phase and three-phase
GENERAL
Sockets: 1x400V 16A 3P+N+T CEE - 1x230V 16A 2P+T CEE - 1x48V 32A 2P CEE
Protective frame
Dry weight TS 200 DES/CF: 150 kg
Dimensions: 900x550x620 mm
Acoustic power LwA (pressure LpA): 99 dB(A) (74 dB(A) @ 7 m)
Non-binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
