TELWIN ADVANCE 227MV/PFC TIG DC-LIFT 100-240V
852060
Phase: Single phase
Frequency: 50/60 Hz
Voltage: 100 - 120 / 200 - 240 V
Type of welding: TIG/MMA
No-load voltage: 81 V
Regulation current: 10 - 130 (150) / 10 - 200 A
Current max: 130 (150) / 200 A
Diameter electrodes: 1.6 - 4 mm
Length: 385 mm
Width: 150 mm
Height: 265 mm
Weight: 9.2 Kg
- Phase
- Single phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 100-120 / 200-240
- Efficiency (%)
- 84
- Protection degree
- IP23
- No-load voltage (V)
- 81
- Regulation current (A)
- 10 - 130(150) / 10 - 200
- Diameter electrodes (mm)
- 1.6 - 4
- Type of welding
- MMA / MIG
- Current max (A)
- 130(150) / 200
- Length (mm)
- 385
- Width (mm)
- 150
- Height (mm)
- 265
- Voltage regulator
- Inverter
- Weight (Kg)
- 9.2
- EAN13
- 8004897905099
- Brand
-
TIG (LIFT striking) and MMA inverter welding machine in direct current (DC).
Use with a wide range of materials such as steel, stainless steel, titanium, copper, nickel and their alloys.
The MV/PFC device guarantees the use of a large range of variable power supply (100-240V), operations even when power supplies are fluctuating and unstable, use of long extensions and a 30% drop in absorptions compared to other welding machines of equal power.
The Voltage Reduction Device (VRD) is used to decrease the output voltage to a safe level when the welding machine is on but not in welding conditions. This grants the operator’s safety: he can come into contact with the electrode without risks, until welding operations are resumed (for use in damp environment such as mines or shipyards, etc.).
Features:
- compact and light
- display to check welding current
- MMA regulations: arc force and hot start
- MMA electrodes: rutile, basic, stainless steel and cast iron
- thermostatic, overcurrent, overvoltage, undervoltage, motorgenerator (+/-15%) protections.
Complete with TIG welding accessories.
Not binding images and technical data.
