TELWIN ADVANCE 227 MV/PFC TIG DC-LIFT VRD
816249
Phase: Single phase
Frequency: 50/60 Hz
Voltage: 100-120 / 200-240 V
Type of welding current: DC
Type of welding: MMA / TIG
No-load voltage: 81 V
Regulation current: 10 - 130(150) / 10 - 200 A
Current max: 130(150) / 200 A
Diameter electrodes: 1.6 - 4 mm
Length: 385 mm
Width: 150 mm
Height: 265 mm
Weight: 6.2 Kg
- Phase
- Single phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 100-120 / 200-240
- Efficiency (%)
- 84
- Protection degree
- IP23
- Maximum permissible current (A)
- 25(33) / 27
- No-load voltage (V)
- 81
- Regulation current (A)
- 10 - 130(150) / 10 - 200
- Diameter electrodes (mm)
- 1.6 - 4
- Type of welding current
- DC
- Type of welding
- MMA / MIG
- Current max (A)
- 130(150) / 200
- Length (mm)
- 385
- Width (mm)
- 150
- Height (mm)
- 265
- Voltage regulator
- Inverter
- Weight (Kg)
- EAN13
- 8004897809991
- Brand
-
TIG (LIFT striking) and MMA inverter welding machine in direct current (DC).
Use with a wide range of materials such as steel, stainless steel, titanium, copper, nickel and their alloys.
The MV/PFC device guarantees the use of a large range of variable power supply (100-240V), operations even when power supplies are fluctuating and unstable, use of long extensions and a 30% drop in absorptions compared to other welding machines of equal power.
The Voltage Reduction Device (VRD) is used to decrease the output voltage to a safe level when the welding machine is on but not in welding conditions. This grants the operator’s safety: he can come into contact with the electrode without risks, until welding operations are resumed. (for use in damp environment such as mines or shipyards, etc.).
Features:
- Compact and light
- Display to check welding current
- MMA regulations: arc force and hot start
- MMA electrodes: rutile, basic, stainless steel and cast iron
- Thermostatic, overcurrent, overvoltage, undervoltage, motorgenerator (+/-15%) protections.
Not binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
