TELWIN MAXIMA 190 SYNERGIC 230V

TELWIN MAXIMA 190 SYNERGIC 230V
search
  • TELWIN MAXIMA 190 SYNERGIC 230V
TELWIN
816085
Out Of Production

DISCONTINUED PRODUCT

Technical features
Phase
Single phase
Frequency (Hz)
50 / 60
Voltage (V)
230
Efficiency (%)
86
Protection degree
IP23
Maximum permissible current (A)
18
No-load voltage (V)
44
Regulation current (A)
20 - 150
Ø steel welding wire (mm)
0.6 - 0.8
Ø inox welding wire (mm)
0.8
Ø aluminium welding wire (mm)
0.8 - 1
Ø flux cored welding wire (mm)
0.8 - 1.2
Ø brazing wire (mm)
0.8
Current max (A)
115
Length (mm)
450
Width (mm)
235
Height (mm)
370
Weight (Kg)
9.29
Details
Technical Sheet / Manuals

Scheda tecnica MAXIMA 160

(217.48k)

Manuale MAXIMA 160

(17.2M)
Ask for availability
Add to wishlist
Download PDF
Ask a question
Product: TELWIN MAXIMA 190 SYNERGIC 230V
Offer on letterhead
Product: TELWIN MAXIMA 190 SYNERGIC 230V
Technical features
Phase
Single phase
Frequency (Hz)
50 / 60
Voltage (V)
230
Efficiency (%)
86
Protection degree
IP23
Maximum permissible current (A)
18
No-load voltage (V)
44
Regulation current (A)
20 - 150
Ø steel welding wire (mm)
0.6 - 0.8
Ø inox welding wire (mm)
0.8
Ø aluminium welding wire (mm)
0.8 - 1
Ø flux cored welding wire (mm)
0.8 - 1.2
Ø brazing wire (mm)
0.8
Current max (A)
115
Length (mm)
450
Width (mm)
235
Height (mm)
370
Weight (Kg)
9.29
Details
Technical Sheet / Manuals

Scheda tecnica MAXIMA 160

(217.48k)

Manuale MAXIMA 160

(17.2M)
