TELWIN TECHNOLOGY TIG 185 DC 230V
852030
DISCONTINUED PRODUCT
Phase: Single phase
Frequency: 50/60 Hz
Voltage: 230 V
Type of welding: TIG/MMA
No-load voltage: 91 V
Regulation current: 5 - 160 A
Current max: 160 A
Diameter electrodes: 1.6 - 3.2 mm
Length: 375 mm
Width: 190 mm
Height: 505 mm
Weight: 12.9 Kg
- Phase
- Single phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 230
- Efficiency (%)
- 82
- Protection degree
- IP23
- No-load voltage (V)
- 91
- Regulation current (A)
- 5 - 160
- Diameter electrodes (mm)
- 1.6 - 3.2
- Type of welding
- MMA / MIG
- Current max (A)
- 160
- Length (mm)
- 375
- Width (mm)
- 190
- Height (mm)
- 505
- Voltage regulator
- Inverter
- Weight (Kg)
- 12.9
- EAN13
- 8004897723747
- Brand
-
TIG (high frequency HF or LIFT striking) and MMA inverter welding machine in direct current (DC).
Use with a wide range of materials such as steel, stainless steel, titanium, copper, nickel and their alloys.
Features:
- TIG regulations: current down slope, bi-level
- MMA regulations: arc force according to the type of electrode in use
- 2/4 strokes operation
- hot start and anti-stick devices
- remote control connector
- MMA electrodes: rutile, basic, stainless steel and cast iron
- thermostatic, overcurrent, overvoltage, undervoltage protections.
The optional TIG PULSE allows pulse welding.
Complete with TIG welding accessories and aluminium carry case.
Not binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
