RIELLO S3T CPT 10 SENTRYUM UPS 10000 VA

Reference RIEDS3TK10CS100R

Voltage 380 / 400 / 415 V three-phase + N
Voltage tolerance 240 to 480
Frequency tolerance 40-72 Hz
Power factor 0. 99
Nominal voltage 380 / 400 / 415 V three-phase + N
Voltage tolerance From 180 (adjustable 180-200) to 264 (adjustable 250-264) referring to neutral
Nominal frequency 50 or 60 Hz
Frequency tolerance ±5%
Number of phases 3 + N
Nominal power 10000 VA
Active power 10000 W
Output current 16. 5 A
Number of phases 3 + N
Sinewaveform
Frequency 50 or 60 Hz
Voltage distortion with distorting load _ 1. 5%
Voltage distortion with linear load < 1%
Communication UPS status led bar - Graphic touch screen diplay - 2 slots for communications interface USB -
RS232 - Contact interface with 5x opto insulated Input and 4x Output relays
Signaling remote voltage free contacts
Operating temperature 0 °C - +40 °C
Relative humidity 5%-95% non-condensing
DATA
Weight 48 kg
Dimensions (h l d) 700x280x840 mm

Download Scheda Tecnica S3T CPT 10

Product Details
Description

Phase: Three phase
Frequency (Hz): 50 / 60
Voltage (V): 380-400-415 + N
Protection degree: IP20
Power (VA): 10000
Battery type: AGM/GEL/NiCd/Li-ion/Supercaps
Operating temperature (°C): 0 °C / +40 °C
Running time (h): 20 min
Acoustic pressure: 40 dB(A) 1 mt.
Length (mm): 840
Width (mm): 280
Height (mm): 700
Dry weight (Kg): 48
Colour: Grey

^* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.

Unavailable

This product is not available for order, please contact us and we will provide you a quotation for similar product based on your needs.
