HONDA GX630RH VXF Engine
GX630RH VXF /
OUT OF PRODUCTION
Net power (kW): 15.5
Net power (Hp): 20.8
Fuel: Petrol
Starter system: Electric
Round per minute (rpm): 3600
Displacement (cm3): 688
Lenght (mm): 405
Width: 410
Height (mm): 438
Dry weight (Kg): 44.4
Compression ratio: 9.3 : 1
- Fuel
- Gasoline
- Engine
- OHC ad albero orizzontale, 4 tempi, cilindro in ghisa
- Ignition
- Digital CDI with variable ignition advance
- Starting system
- Electric
- Engine capacity (cm³)
- 688
- Number cylinders
- 2
- Cylinders' position
- V to 90°
- Oil capacity (L)
- 1.9
- Cooling
- Forced air
- Bore x stroke (mm)
- 2 / 78 x 72
- Compression ratio
- 9.3 : 1
- Net power (kW)
- 15.5
- Nominal power continuous
- 10.5 KW (14.1 HP) / 3000 rpm - 12.0 KW (16.1 HP) / 3600 rpm
- Maximum torque
- 48.3 Nm / 4.93 kgfm / 2500 rpm
- Lubrication
- Forced
- Carburetor
- Double body, solenoid fuel supply interruption
- Consumption (L/h)
- 6
- Length (mm)
- 405
- Width (mm)
- 410
- Height (mm)
- 438
- Dry weight (Kg)
- 44.4
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
