HONDA GXV390T1 DN5 Engine
GXV390T1 DN5
Fuel: Gasoline
Engine: OHV vertical shaft, 4-stroke, cast iron cylinder
Starting system: Recoil (electric optional)
Displacement: 389 cm³
Net power: 7.6 kW (10.2 HP)
Fuel tank capacity: 2.1 L
Length: 430 mm
Width: 385 mm
Height: 410 mm
Weight: 33 Kg
- Fuel
- Gasoline
- Engine
- OHV vertical shaft, 4 stroke, cast iron cylinder
- Ignition
- A transistor contactless
- Starting system
- Manual
- Engine capacity (cm³)
- 389
- Number cylinders
- 1
- Oil capacity (L)
- 1.1
- Cooling
- Forced air
- Bore x stroke (mm)
- 88 x 64
- Compression ratio
- 7.7 : 1
- Net power (kW)
- 7.6
- Nominal power continuous
- 5.2 KW (7.0 HP) / 3000 rpm
- Maximum torque
- 24.2 Nm / 2.47 kgfm / 2500 rpm
- Fuel tank capacity (L)
- 2.1
- Consumption (L/h)
- 2.5
- Running time (h)
- 0.84
- Length (mm)
- 430
- Width (mm)
- 385
- Height (mm)
- 410
- Dry weight (Kg)
- 33
- Engine manufacturer
- Honda
- Brand
-
HONDA GXV390T1 DN5 Engine
The GXV390 engines are recommended for a wide range of professional machines such as ride-on lawn mowers, construction equipment, and other industrial applications.
Features of the HONDA GXV390T1 DN5 Engine:
- The OHV configuration ensures very efficient combustion.
- A high power-to-displacement ratio.
- Easy and light starting, thanks also to an efficient decompression system and an ergonomic recoil starter handle.
- High-quality materials, designed and built to last a very long time.
- The engines comply with all the strictest regulations in force in Europe.
- Very low fuel consumption.
- Reduced vibrations and noise.
Color: Black
Muffler: Standard
Air filter: Dual element
Fuel tank: Standard
Synchro-balanced engine
Technical specifications HONDA GXV390T1 DN5 Engine:
Fuel: Gasoline
Engine: OHV vertical shaft, 4-stroke, cast iron cylinder
Starting system: Recoil (electric optional)
Displacement: 389 cm³
Net power: 7.6 kW (10.2 HP)
Fuel tank capacity: 2.1 L
Length: 430 mm
Width: 385 mm
Height: 410 mm
Weight: 33 Kg
Are you looking for an engine similar to the HONDA GXV390T1 DN5 but with different features? CLICK HERE and discover our full range.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
