UPC

OUT OF PRODUCTION Type of phase: Single-phase Continuous Power: 5 KVA / 5 KW Maximum Power (5s): 10 KVA / 10 KW Voltage VAC: 230 Frequency (Hz ): 50 Battery type: Li-Ion NMC Input socket: 1 x 32A 230V IEC 60309 Socket panel: 2 x 16A 230V IEC 60309 Battery nominal capacity: 12, 5 KWh Usable energy (@ 80% DoD): 10 KWh <br...

OUT OF PRODUCTION Type of phase: Single-phase Continuous Power: 3 KVA / 3 KW Maximum Power (5s): 6 KVA / 6 KW Voltage VAC: 230 Frequency (Hz ): 50 Battery Type: Li-Ion NMC Input socket: 1 x 32A 230V IEC 60309 Socket panel: 2 x 16A 230V IEC 60309 Battery nominal capacity: 7.5 KWh Usable energy (@ 80% DoD): 6 KWh ...

OUT OF PRODUCTION Type of phase: Single-phase Continuous power: 10 KVA / 10 KW Maximum power (5s): 20 KVA / 20 KW VAC voltage: 230 Frequency (Hz ): 50 Battery type: Li-Ion NMC Input socket: 1 x 32A 230V IEC 60309 Socket panel: 1 x 32A 230V IEC 60309/1 x 16A 230V IEC 60309 Nominal battery capacity: 15 KWh Usable energy (@ 80% DoD): 12...

DISCONTINUED PRODUCT Type of phase: Single-phase / Three-phase Continuous power: 60 KVA / 48 KW Maximum power (5s): 150 KVA / 120 KW VAC voltage: 230/400 Frequency (Hz): 50 Battery type: Li-Ion NMC Input socket: 2 x 125A 400 / 230V IEC 60309 Socket panel: 1 x 32A 230V / 2 x 32A 400 / 230 V / 1 x 63A 400 / 230V / 1 x 125A 400 /...

INPUT Rated voltage: 380-400-415 Vac three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3% BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V (selectable) Rated frequency: 50 or 60 Hz (selectable)<br...

Version with internal batteries Running time: 15 min INPUT Rated voltage: 380-400-415 Vac three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3% BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V...

INPUT Nominal power: 30KVA Voltage: 380/400/415 VAC three-phase + N + ground Input voltage variation: ± 20% Frequency: 40 / 72 Hz Power factor: 0.99 Maximum input current phase/neutral: 45 A Harmonic distortion:&lt; 3% BY - PASS Rated voltage: 380/400/415 VAC three-phase + N + earth Voltage variation: ± 15% (selectable from ± 5% to ± 25%)<br...

Version with internal batteries Running time: 30 min INPUT Rated voltage: 380-400-415 Vac three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3% BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V...

Version with internal batteries Running time: 31 min INPUT Rated voltage: 380-400-415 Vac three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3% BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V...

Version with internal batteries Running time: 25 min INPUT Rated voltage: 380-400-415 Vac three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3% BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V...

VERSION WITH INTERNAL BATTERIES AUTONOMY UP TO 10 MINUTES INPUT Rated Voltage: 380 / 400 / 415V three-phase + N Rated frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 BY-PASS Rated Voltage: 380 / 400 / 415V three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264...

INPUT Voltage (V): 380 / 400 / 415 three-phase + N Frequency: 50 / 60 hZ Current Distortion: THDI ≤3% BYPASS Voltage (V): 380 / 400 / 415 three-phase + N Phase type: Three-phase Frequency: 50 or 60 Hz (selectable) Bypass overload: 110% infinite, 125% for 60 min, 150% for 10 min. OUTPUT Phase type: three-phase Power: 10...

Voltage 380 / 400 / 415 V three-phase + N Voltage tolerance 240 to 480 Frequency tolerance 40-72 Hz Power factor 0. 99 Nominal voltage 380 / 400 / 415 V three-phase + N Voltage tolerance From 180 (adjustable 180-200) to 264 (adjustable 250-264) referring to neutral Nominal frequency 50 or 60 Hz Frequency tolerance ±5% Number of phases 3 + N<br...

VERSION WITH SEPARATE BATTERY BOX ENTRANCE Rated voltage: 380-400-415 Vac three-phase + N Nominal frequency: 50/60 Hz Frequency tolerance: 40 ÷ 72 Hz Power factor at full load: 0.99 Current distortion: THDI ≤ 3%. BY-PASS Rated voltage: 380-400-415 Vac three-phase + N Number of phases: 3 + N Voltage tolerance: 180 ÷ 264 V...

Phase type: Single-phase Rated power: 30000 VA Voltage: 380/400/415 Vac single phase + N Voltage tolerance: ± 20% Frequency tolerance: 40/72 Hz Power factor: 0,99 BY PASS Rated voltage: 380/400/415 Vac three-phase + N Voltage tolerance: ± 15% (selectable from ± 5% to ± 25%) Nominal frequency: 50/60 Hz Frequency tolerance: ± 5% (selectable...

PRODUCT TYPE: UPS POWER: 600VA/360W ENTRANCE Rated voltage 220-230-240 Vac Voltage Tolerance input 230 Vac (±25%) Frequency 50/60 Hz with automatic selection EXIT Operating voltage from 230 Vac mains (-8%, +10%) Operating voltage by 230 Vac battery (+/- 5%) Frequency in operation from 50 or 60 Hz battery (+/- 0.5%) Pseudo...

Product Type: UPS Nominal voltage (V): 220 / 230 / 240 Voltage tolerance (V): 230 ±20%. Minimum voltage (V): 184 Frequency (Hz): 50 / 60 ±5 Voltage tolerance (V): 180 / 264 (selectable in ECO or SMART ACTIVE mode) Overload times: &lt;110% continuous, 130% for 1 hour, 150% for 10 min., over 150% for 3 seconds Rated power (VA): 4000 Active power (W):...

Rated power: 2200 VA Voltage: 220 / 230 / 240 V Voltage tolerance: 230 V ±20%. Frequency. 50 / 60 Hz Frequency tolerance: 50 Hz ±5% / 60 Hz ±5% Power factor: &gt;0.99 Current distortion: ≤7% Voltage tolerance: 180 / 264 V Frequency tolerance: Frequency selected (±1.5 Hz to ±5 Hz configurable) Rated power: 2200 VA Active power: 1980 W<br...

Rated power: 2200 VA Voltage: 220 / 230 / 240 V Frequency. 50 / 60 Hz Frequency tolerance: 50 Hz ±5% / 60 Hz ±5% Power factor: &gt;0.98 Current distortion: ≤7% Rated power: 2200 VA Active power: 1980 W Crest factor (Ipicco/Irms): 2.5 : 1 Battery waveform: Sinusoidal Frequency in battery operation: Selectable: 50 Hz or 60 Hz or...

INPUT Rated Voltage (V): 380 / 400 / 415 three-phase + N Rated Frequency: 50 / 60 hZ Current Distortion: THDI ≤3% BYPASS Rated voltage (V): 380 / 400 / 415 three-phase + N Phase type: Three-phase Rated frequency: 50 or 60 Hz (selectable) Bypass overload: 110% infinite, 125% for 60 min, 150% for 10 min. OUTPUT Phase type:...

INPUT Rated Voltage (V): 380 / 400 / 415 three-phase + N Rated Frequency: 50 / 60 hZ Current Distortion: THDI ≤3% BYPASS Rated voltage (V): 380 / 400 / 415 three-phase + N Phase type: Three-phase Rated frequency: 50 or 60 Hz (selectable) Bypass overload: 110% infinite, 125% for 60 min, 150% for 10 min. OUTPUT Phase type:...

Pure sine wave AC output, 3600W (7200W flux), 120V, 50/60Hz. DC output 13.6V / 70A, 1000W max; 26.4V / 60A, 1600W max; AC input X-Stream fast charging 3000W max, 15A max. AC input voltage 220-240V, 50/60Hz&lt; br /&gt;Solar charging inputs 15-150V 30A, 1600W max. Alternator charging inputs 13-60V 60A, 1600W max. Operating temperature -25°C - 60°C Storage...

Pure sine wave AC output, 3600W (7200W flux), 120V, 50/60Hz. DC output 13.6V / 70A, 1000W max; 26.4V / 60A, 1600W max; AC input X-Stream fast charging 3000W max, 15A max. AC input voltage 220-240V, 50/60Hz Solar charging inputs 15-150V 30A, 1600W max. Alternator charging inputs 13-60V 60A, 1600W max. Operating temperature -25°C - 60°C Storage temperature...

Conveniently control your entire power system from your mobile or small home. Keep an eye on your power consumption, adjust settings, and view power input on the handy screen. Package contents: EcoFlow power kit console x 1, CAN RJ45 bus cable (6 m)

Protection level: IP21 Tests and Certifications: UL Standard, FCC, PSE Operating temperature (C ): -25℃-60℃ Main AC input: 30A max 120V, 3600W Main DC input: 70A max AC output: 6 position AC, 20A max each DC output: 12 position DC fused (6 position controllable via console of the power kit and the Ecoflow Application) Width: 211 mm Length: 353 mm<br...

Rated capacity: 2048Wh (40Ah) Rated voltage: 51.2V Configuration: 16S2P Charge voltage: 57.6V Discharge voltage: 40V Maximum continuous charge current: 32A Maximum continuous discharge current: 80A Battery chemistry: LiFePO4 Cycle life: 3,000 cycles up to 80% capacity IP protection degree: IP54 Width: 348 mm Length: 198 mm Height:...

Power output (continuous): 60 kVA Peak power (5s): 120 kW Voltage: 400/230 V Frequency: 50 Hz Phases: 3 Battery specifications Battery (type): Li-Ion LFP Nominal battery voltage: 48 V Battery life (at 90% DoD): 6000 cycles Nominal battery capacity (size): 96 kWh AC-side usable energy (@90% DoD): 82 kWh System throughput: 125 A<br...

Rated power: 3000 VA Voltage: 220 / 230 / 240 V Voltage tolerance: 230 V ±20%. Frequency. 50 / 60 Hz Frequency tolerance: 50 Hz ±5% / 60 Hz ±5%. Power factor: &gt;0.99 Current distortion: ≤7%. Voltage tolerance: 180 / 264 V Frequency tolerance: Frequency selected (±1.5 Hz to ±5 Hz configurable) Rated power: 3000 VA Active...

Rated capacity: 5120 Wh (100 Ah) Rated voltage: 51.2 V Configuration: 16S2P Charging voltage: 57.6 V Discharge voltage: 40 V Maximum continuous charging current: 80A Maximum continuous discharge current: 100A Battery chemistry: LiFePO4 Cycle life: 3500 cycles up to 80% capacity IP degree of protection: IP54 Width: 500mm Length: 260 mm<br...
