RIELLO S3T CPT 10 SENTRYUM UPS 10000 VA
S3T10CPTS1
New product
VERSION WITH INTERNAL BATTERIES
AUTONOMY UP TO 10 MINUTES
INPUT
Rated Voltage: 380 / 400 / 415V three-phase + N
Rated frequency: 50/60 Hz
Frequency tolerance: 40 ÷ 72 Hz
Power factor at full load: 0.99
BY-PASS
Rated Voltage: 380 / 400 / 415V three-phase + N
Number of phases: 3 + N
Voltage tolerance: 180 ÷ 264 V (selectable)
Rated frequency: 50 or 60 Hz (selectable)
Frequency tolerance: ±5 (selectable)
EXIT
Rated power: 10 kVA
Active power: 10 kW
Number of phases: 3 + N
Static stability: ± 1%
Crest factor: 3 : 1 Ipeak/Irms
Voltage distortion: ≤ 1% with linear load / ≤ 3% with distorting load
Frequency: 50/60 Hz
Frequency stability in battery: 0.01%
Overload: 125% for 10 min - 150% for 1 min - 200% for 0.5 sec
BATTERIES
Type: VRLA AGM/GEL/NiCd/Li-ion/Supercaps
Depth: 840 mm
Width: 280 mm
Height: 700 mm
Weight (kg): 48
Technical features
- Phase
- Three phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 380-400-415 + N
- Protection degree
- IP20
- Power (VA)
- 10000
- Battery type
- AGM/GEL/NiCd/Li-ion/Supercaps
- Operating temperature (°C)
- 0 °C / +40 °C
- Running time (h)
- 11 min
- Acoustic pressure
- 40 dB(A) 1 mt.
- Length (mm)
- 840
- Width (mm)
- 280
- Height (mm)
- 700
- Dry weight (Kg)
- 48
- Colour
- Grey
Details
* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
Technical Sheet / Manuals
Technical features
- Phase
- Three phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 380-400-415 + N
- Protection degree
- IP20
- Power (VA)
- 10000
- Battery type
- AGM/GEL/NiCd/Li-ion/Supercaps
- Operating temperature (°C)
- 0 °C / +40 °C
- Running time (h)
- 11 min
- Acoustic pressure
- 40 dB(A) 1 mt.
- Length (mm)
- 840
- Width (mm)
- 280
- Height (mm)
- 700
- Dry weight (Kg)
- 48
- Colour
- Grey
Details
* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
Technical Sheet / Manuals
