UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8
      UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8
      UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8

      UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8

      INPUT
      Nominal power: 30KVA
      Voltage: 380/400/415 VAC three-phase + N + ground
      Input voltage variation: ± 20%
      Frequency: 40 / 72 Hz
      Power factor: 0.99
      Maximum input current phase/neutral: 45 A
      Harmonic distortion:< 3%
      BY - PASS
      Rated voltage: 380/400/415 VAC three-phase + N + earth
      Voltage variation: ± 15% (selectable from ± 5% to ± 25%)
      Frequency: 50/60 Hz
      Rated current: 200% In
      Number of phases: 3+N
      Protection: short circuit - over load - over temperature
      OUTPUT
      Nominal power: 30 KVA
      Active power: 24 KW
      Number of phases: 3+N
      Crest factor:3:1
      Waveform: sinusoidal
      Static stability: ±1%
      Dynamic stability: ± 1%
      Phase/neutral output current: 38 A
      Frequency: 50/60 Hz selectable and/or automatic
      Distortion on linear load: 1%
      Non-linear load distortion: 3%

      Dimensions mm: 500 x 800 x1100 h
      Weight without batteries in Kg: 115
      Weight of metal cabinet in Kg: 150

      Custom Quote
      Product: UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8

      PERSONAL DATA


      Ask a question
      Product: UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8
      Offer on letterhead
      Product: UPS300 Three-phase - Nominal power 30 KVA P.F. 0.8
      UPS 300

      Data sheet

      Phase
      Three phase
      Frequency (Hz)
      50 / 60
      Voltage (V)
      380/400/415 trifase + N + terra
      Protection degree
      IP21
      Power (VA)
      30000
      Full charge time in network (h)
      6
      Battery type
      Maintenance-free hermetic lead
      Length (mm)
      800
      Width (mm)
      500
      Height (mm)
      1100
      Sound level at driver's ear
      ≤ 50 dBA
      Input voltage (V)
      380/400/415 trifase + N + terra
      Kind of wave
      Sinusoidal
      Colour
      Black
      Nominal input voltage (V)
      380/400/415 VAC trifase + N + terra
      Display/read-out
      LCD display
      Approvals
      EN 62040 - 2 Lev. A and Directive 73/23 EEC, 93/68 EEC, 89/336 EEC
      Power factor control
      0.99
      Protections
      Over temperature, over load, short circuit, high/low battery voltage
      MasterBus compatible
      Yes
      Weight (Kg)
      150

      Specific References

      New
      BATTERY BOX for UPS300
          Battery type: Maintenance-free hermetic lead Autonomy at full load: 60 minutes Battery quantity: 6 // 60 x 12VDC - 9 Ah (360 blocs) Cabinet size: 500x800x1100 Number of battery boxes: 3 Total net weight: 1100 Kg
          6,950.00 €Price
