HONDA GP160H QX3 Engine
GP160H QX3 /
OUT OF PRODUCTION
Net power (kW): 3.6
Net power (Hp): 4.8
Fuel: Petrol
Starter system: Recoil starter
Round per minute (rpm): 3600
Displacement (cm3): 163
Lenght (mm): 314
Width (mm): 363
Height (mm): 335
Dry weight (Kg): 15.1
- Fuel
- Gasoline
- Engine
- OHC ad albero orizzontale, 4 tempi, cilindro in ghisa
- Ignition
- A transistor contactless
- Starting system
- Manual
- Engine capacity (cm³)
- 163
- Number cylinders
- 1
- Cylinders' position
- Inclined to 25°
- Oil capacity (L)
- 0.6
- Cooling
- Forced air
- Bore x stroke (mm)
- 68 x 45
- Compression ratio
- 8.5 : 1
- Net power (kW)
- 3.6
- Nominal power continuous
- 2.5 KW (3.4 HP) / 3000 rpm - 2.9 KW (3.9 HP) / 3600 rpm
- Maximum torque
- 10.3 Nm / 1.05 kgfm / 2500 rpm
- Fuel tank capacity (L)
- 3.1
- Consumption (L/h)
- 1.4
- Running time (h)
- 2.21
- Length (mm)
- 314
- Width (mm)
- 363
- Height (mm)
- 335
- Dry weight (Kg)
- 15.1
- Engine manufacturer
- Honda
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
