SINCRO SK500 MC Three Phase Synchronous AC Alternator 2300 kVA PMG D-AVR
      SINCRO SK500 MC Three Phase Synchronous AC Alternator 2300 kVA PMG D-AVR
      SINCRO SK500 MC Three Phase Synchronous AC Alternator 2300 kVA PMG D-AVR

      SINCRO SK500 MC Three Phase Synchronous AC Alternator 2300 kVA PMG D-AVR

      SK500 MC SAE0 d18

      Phase: Three Phase
      Poles: 4
      Voltage (V): 400
      Frequency (Hz): 50
      Rpm Speed: 1500
      Single Phase Output (kVA): ----
      Three Phase Output (kVA): 2300
      Constant Speed Alternator
      D-AVR
      Brushless
      PMG
      Weight (Kg): 3885
      Protection: IP23

      Choose the type of coupling :
      Download PDF
      Custom Quote

      PERSONAL DATA


      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      SINCRO
      SK500 MC SAE0 d18

      Data sheet

      Phase
      Three phase
      Frequency (Hz)
      50
      Voltage (V)
      400
      Engine rpm (rpm)
      1500
      Poles
      4
      Three-phase power (KW)
      1840
      Three-phase power (KVA)
      2300
      Efficiency (%)
      96.3
      Protection degree
      IP23
      Dry weight (Kg)
      3885
      Brushes
      No
      PMG
      Yes
      Type of alternator
      Constant Speed
      Voltage regulator
      Digital AVR

      Specific References

      New

      Three phase brushless alternator - AVR.

      - Insulation class H
      - IP23
      - Standard voltage 400 V - 50 Hz
      - Leads 4
      - Excitation PMG: standard
      - Bearings: Bearings are dimensioned for heavy duty
      - Transient features: Transient voltage drop for rated step load at 0.8 power factor is less than 18%
      - Tropicalizzation: standard

      The images are purely indicative.

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
      APD Advanced Parallel Device + Transformer for SK500 models.
          APD Advanced Parallel Device + Transformer (parallel operation) for  SK500 models.
          720.00 €Price
          Potentiometer (voltage remote control) for SK500 models.
              Potentiometer (voltage remote control) for SK500 models.
              132.00 €Price
              230V Anticondensation heaters for SK500 models.
                  230V Anticondensation heaters for SK500 models.
                  433.00 €Price
