MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR
      MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR
      MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR

      MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR

      NPE 31-B/2 SAE3 d6.5

      Phase: Single phase / Three phase
      Maximum three phase power: 10.5 KVA
      Maximum single phase power: 7 KVA
      Frequency: 50 Hz
      Voltage: 230 V / 400 V
      Protection: IP21
      Rpm speed: 3000 rpm
      Poles: 2
      Efficiency: 78.5%
      Weight: 81 Kg
      Constant speed alternator
      Brushless
      Voltage regulator: AVR

      Ask a question
      Offer on letterhead
      Choose the type of coupling :
      Ask for availability
      Download PDF
      Custom Quote
      Product: MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR

      PERSONAL DATA

      Ask a question
      Product: MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR
      Offer on letterhead
      Product: MECC ALTE NPE 31-B2 THREE PHASE ALTERNATOR 10.5 KVA AVR
      MECC ALTE
      NPE 31-B/2 SAE3 d6.5

      Data sheet

      Phase
      Single phase / Three phase
      Maximum power single phase (KVA)
      7
      Maximum power three phase (KVA)
      10.5
      Frequency (Hz)
      50
      Voltage (V)
      230 / 400
      Engine rpm (rpm)
      3000
      Poles
      2
      Single-phase power (KVA)
      7
      Three-phase power (KVA)
      10.5
      Efficiency (%)
      82.2
      Protection degree
      IP21
      Acoustic pressure
      75 dB(A) at 7 m
      Brushes
      No
      PMG
      No
      Type of alternator
      Constant Speed
      Voltage regulator
      AVR
      Weight (Kg)
      83
      Precision of voltage regulation
      ± 1%

      Specific References

      New

      NPE31 2 pole generator

      MECC ALTE NPE 31-B/2 THREE PHASE ALTERNATOR 10.5 KVA AVR

      The NPE31 range has many product features designed into the alternator.
      Self-regulation is obtained through a digital electronic regulator that is fed by an auxiliary winding.
      We guarantee an almost constant supply from the generator – under any possible operating condition.
      A rotating inductor is fitted with a damper cage.
      The windings have a 2/3 pitch in order to reduce the harmonic content of voltage.
      The entire series is manufactured according to, and complies with, the most common specifications such as CEI 2-3, IEC 34-1, EN 60034-1, VDE 0530, BS 4999-5000, CAN/ CSA-C22.2 No14-95- No100-95.



      Not binding images and technical data.
