GENERATORS FOR CAMPERS / TRUCKS

OUT OF PRODUCTION

OUT OF PRODUCTION

OUT OF STOCK Maximum single-phase power: 5 KW Continuous single-phase power: 4.2 KW Fuel: Diesel Voltage: 230 V Engine: Yanmar L100AE Length: 700 mm Width: 535 mm Height: 530 mm Weight: 145 Kg

Frequency [Hz] 50 Generator manufacturer Fischer Panda GmbH Isolation class of windings H Nominal Speed [rpm] 3000 rpm Voltage Regulation xControl Voltage Tolerance ±3% Power rating factor Cos Pi 0.85 Engine Speed [rpm] 3000 Nominal Voltage in Volt 230 Nominal Performance in kW)1) 8 Nominal Performance in kVA1) 9.4 Continuous...

Phase Type: Single Phase Maximum Single Phase Power: 6.2KVA Fuel: Gasoline Voltage: 230 V Motor: Honda GX 390 OHV Motor Rotation: 3000 rpm Acoustic Power: 58 dB at 7 m Power Factor: 0.8 Protection class: IP23 Isolation class: H Fuel consumption 75% of load: 2.9 l/h Fuel tank: 17 l Length: 810 mm Width: 505 mm Height: 420...

The standard panel includes the in-cab panel with a cable of approximately 20 meters. Phase type: Single-phase Maximum power Single-phase: 6.2 KVA / 4.96 KW Motor: GX 390 OHV Motor speed: 3000 rpm Emission standard: Stage V No. Cylinders: 1 Cooling: Air Displacement: 390 cm3 Power: 11 hp (8.2 kWm) Starter: Electric<br...

Maximum power Single-phase: 6.2 KVA Fuel: petrol Voltage: 230 V Frequency: 50 Hz Engine: Honda GX 390 OHV Start: Electric Consumption: 3.3 Lt/h at 75% of load Length: 831 mm Width: 513 mm Height: 465 mm Weight: 140 Kg

PRODUCT OUT OF PRODUCTION . Single Phase Vehicle Generator Fuel: Diesel Voltage: 400 V Nominal Power: 6.40 kW Continuous power: 6.40 kW Frequency: 50 Hz Insulation class: H RPM: Variable speed 2200 - 2600 rpm Permanent Magnets Voltage regulator: Capacitor Power factor Cos Pi: 0.85 Engine KUBOTA D722 Cylinders:...

OUT OF PRODUCTION Phase Type: Single Phase Maximum Power: 2.5 KW Voltage: 230 V Frequency: 50 Hz Motor: YAMAHA MZ 175 Motor RPM: 2700 / 3900 rpm Fuel: Gasoline Voltage Regulator: Inverter Start: Electric Fuel Consumption: 1. 2 lt/h Acoustic pressure: 58 dBA @ 7m Width: 275 mm Length: 515 mm Height: 390 mm Weight:...

Phase Type: Single Phase Maximum Power: 5.8 KW Continuous Use Power: 5 KW Voltage: 230 V Frequency: 50 Hz Engine: Yamaha MZ300 Displacement: 296 cm3 Starting: electric Power Supply: LPG Oil Capacity: 1l Engine RPM: 2500 - 3600 rpm Sound Pressure: 54 - 68 dB(A) @ 7m Width: 723. 5 mm Depth: 467 mm Height: 339...

Single-phase continuous use power: 16 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Lombardini LDW1404 Starting: Electric Consumption: 0.35 Lt/KW/h Length: 1070 mm Width: 580 mm Height: 650 mm Weight: 290 Kg

Phase Type: Single-phase Continuous Output: 3.5 KVA Continuous Output: 3 KW Frequency: 50 Hz Voltage: 230 V Engine rpm: 2499-3000 rpm Dispacement: 309 cc Cooling: Air Sound pressure: 54 dB(A) at 7 m Length: 492 mm Width: 465 mm Height: 515 mm Dry weight: 68 Kg

Phase type: Single phase / Three phase Maximum Single Phase Power: 3.3KVA / 2.7 KW Maximum Three Phase Power: 10 KVA / 8 KW Fuel: Diesel Voltage: 230 / 400V Frequency: 50Hz Starting: Electric Cooling: Water Engine: Yanmar 3TNV80F Emissions regulations: STAGEV Mechanical power: 13 Hp Number of cylinders: 3 ...

Phase type: Single-phase / Three-phase Maximum single-phase power: 6,3KVA / 5 KW Maximum three-phase power: 19,1 KVA / 15.3 KW Fuel: Diesel Voltage : 230 / 400V Frequency: 50 Hz Starting: Electric Cooling: Water Engine: Yanmar 4TNV88 Emissions standard: STAGEV Mechanical power: 24.1 Hp Number of cylinders: 4 Displacement: 2190 cc<br...

Maximum single-phase power: 15.3 KW Continuous single-phase power: 13.9 KW Fuel: Diesel Voltage: 230 V Engine: Yanmar 4TNV88 Length: 1570 mm Width: 650 mm Height: 810 mm Weight: 550 Kg

Single Phase Vehicular Generator Rated Power: 7.5 kW Continuous Power: 6.70 kW Fuel: Diesel Voltage: 120 V Frequency: 60 Hz Insulation Class: H RPM: 3600 rpm Permanent Magnets Voltage Regulator: Capacitor Power Factor Cos Pi: 1. 00 Engine KUBOTA Z482 Cylinders: 2 Displacement: 479 cm3 Power: Electric 12V (24V OPTIONAL)<br...

Maximum three-phase power: 10 KVA Maximum three-phase power: 8 KW Maximum power Single-phase: 3.3 KVA Single-phase maximum power: 2.64 KW Fuel: Diesel Voltage: 230/400 V Frequency: 50 Hz Engine: Yanmar 3TNV80F (STAGE V) Starter: Electric Consumption: 2.2 Lt/h Length: 1070 mm Width: 560 mm Height: 660 mm Weight: 320 Kg

Fuel: Petrol Phase type: Single-phase Maximum single phase power (KW): 7 Continuous single-phase power (kW): 6.2 Voltage (V): 230 Output current: 26.90 A Frequency (Hz): 50 Engine: Honda GX390 Inverter Consumption (Kg/h): 3.7 Length (mm): 626 Width (mm): 446 Height (mm): 547 Dry weight (Kg): 112

Maximum single-phase power: 6.2 KVA Fuel: Gasoline Voltage: 230 V Engine: Honda GX 390 OHV Length: 810 mm Width: 505 mm Height: 420 mm Weight: 140 Kg

Phase type: Single-phase Maximum Power: 10 KVA / 8 KW Continuous Power: 9 KVA / 7.2 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Yanmar 3TNV80F Mechanical power: 13 Hp Number of cylinders: 3 Displacement: 1267 cc Engine rpm: 1500 rpm Emissions standard: StageV Consumption: 2.2 l / h at 75% load Acoustic power: 58 dBA...

Intermittent power kW at 25°C (77°F) 12.5 kW Continuous power kVA at 25°C (77°F) 15 kVA Rated voltage / Frequency 1 Phase | 230 VAC | 50 Hz Phase / Wires 1 Phase, 3 Wires Inverter module PMG frame 3 (1 Phase) Sound level 54 dB(A) at 7 m, 65 dB(A) at 1 m RPM range 2200 ... 3200 rpm, adjustable Alternator technology Permanent magnet Generator cooling...

Phase type: Single-phase Maximum power Single-phase: 6.3 KVA / 5.04 KW Engine: Kubota Z 482 Engine speed: 3000 rpm Emissions standard: Stage V No. Cylinders: 2 Cooling: Air Displacement: 479 cm3 Power: 11.1 HP (8.3 kWm) Starter: Electric Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Fuel consumption 75%: 1.7 Lt/h Acoustic...

Phase type: Single-phase Maximum single-phase power: 7.5 KVA / 6 KW Engine: Kubota Z 482 Engine speed: 3000 rpm Emissions standard: Stage V No. Cylinders: 2 Cooling: Air Displacement: 479 cm3 Power: 11.1 HP (8.3 kWm) Starter: Electric Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Fuel consumption 75%: 2 Lt/h Acoustic...

Phase type: Single-phase Maximum single-phase power: 8.8 KVA / 7.04 KW Engine: Kubota D 602 Emission standard: Stage V No. Cylinders: 2 Cooling: Air Displacement: 599 cm3 Power: 14.5 HP (10.8 kWm) Starter: Electric Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Fuel consumption 75%: 2.2 Lt/h Acoustic pressure: 84 (59 dB at 7...

Phase type: Single-phase Maximum single-phase power: 10 KVA / 8 KW Engine: Kubota D 602 Emission standard: Stage V Engine speed: Variable No. Cylinders: 2 Cooling: Air Displacement: 599 cm3 Power: 14.5 HP (10.8 kWm) Starter: Electric Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Fuel consumption 75%: 2.2 Lt/h Acoustic...
