FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

Name: FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW
Brand: FISCHER PANDA
SKU: 0000374
Price: 18628 EUR
Availability: InStock

Single Phase Vehicular Generator
Rated Power: 7.5 kW
Continuous Power: 6.70 kW
Fuel: Diesel
Voltage: 120 V
Frequency: 60 Hz
Insulation Class: H
RPM: 3600 rpm
Permanent Magnets
Voltage Regulator: Capacitor
Power Factor Cos Pi: 1. 00
Engine KUBOTA Z482
Cylinders: 2
Displacement: 479 cm3
Power: Electric 12V (24V OPTIONAL)
Supersilenced: 52 dB(A) at 7 meters
Type of soundproofing cover: GFK (Glass fiber reinforced polyester)
Insulation material: 4DS
Length: 870 mm
Width: 580 mm
Height: 634 mm
Weight: 278 Kg

Prezzo

22,726.16 € tax incl.

18,628.00 € tax excl.

Shipping from 106.00 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Product: FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

Start of Rental

End of Rental

Where to collect / receive the Product

Do you need cables?

SÌNO

Additional Tank?

SÌNO

PERSONAL DATA

Name

Surname

Phone

Company

City

State

Postal Code

Country

VAT or CF

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Ask a question

Product: FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

Full Name

Company

Phone

City

Country

Postal code

Message

reCAPTCHA

Offer on letterhead

Product: FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

Name

Surname

Company

VAT

Phone

City

Country

Postal code

Shipping address

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference 0000374

Data sheet

Phase: Single phase
Maximum power single phase (KW): 7.5
Continuous power single phase (KW): 6.7
Fuel: Diesel
Frequency (Hz): 60
Voltage (V): 120
Engine: KUBOTA Z482, 4 stroke
Engine rpm (rpm): 3600
Starting system: Electric 12 Vcc
Engine capacity (cm³): 479
Number cylinders: 2
Cooling: Water
Motor insulation class: H
Acoustic pressure: 52 dB(A) at 7 m
Length (mm): 870
Width (mm): 580
Height (mm): 635
Dry weight (Kg): 278
Silenced: Yes
Super silenced: Yes
PMG: Yes
Product type: Generator
Voltage regulator: Inverter
Engine manufacturer: Kubota

Specific References

Condition New

FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW

The generator FISCHER PANDA 8 MINI PVMV-N/PVM-NE VEHICLE GENERATOR 7.5KW single-phase is equipped with a KUBOTA Z482 engine with Diesel power supply, capable of delivering a maximum power of 7,5KW.

Veicular Generator is equipped with a silencer system completely integrated in the soundproof capsule. This solves most of the installation problems inside the vehicle, since the exhaust is already mounted.

The FISCHER PANDA generator must be installed with an external radiator. It is recommended to mount it on the roof or any other suitable location on the outside of the vehicle.

Equipment

Roof radiator rd3.3 tropical 120.1.50-60
Passatetto Dia 25 mm
Set 4 vibration dampers FPB 4 x BRB 70 A40 M12 SH 40
Exhaust elbow INOX with silicone joint
Diesel filter with water softener WS180

TECHNICAL FEATURES FISCHER PANDA PVMV-N AGT-DC

Are you looking for a generator with different characteristics? Here you can find the whole range of FISCHER PANDA generators or other specialized brands

Images and technical data are not binding and may be subject to revisions by the manufacturer.
