GENSET MG5050DMi Vehicle Generator with Inverter StageV 6.3KVA

Reference MG 5050 DMi

Phase type: Single-phase
Maximum power Single-phase: 6.3 KVA / 5.04 KW
Engine: Kubota Z 482
Engine speed: 3000 rpm
Emissions standard: Stage V
No. Cylinders: 2
Cooling: Air
Displacement: 479 cm3
Power: 11.1 HP (8.3 kWm)
Starter: Electric
Fuel: Diesel
Voltage: 230 V
Frequency: 50 Hz
Fuel consumption 75%: 1.7 Lt/h
Acoustic pressure: 84 (59 dB at 7 m)
Length: 858 mm
Width: 560 mm
Height: 631 mm
Dry weight: 200 Kg

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MG 5050 DMi

Data sheet

Phase: Single phase
Maximum power single phase (KW): 5.04
Maximum power single phase (KVA): 6.3
Fuel: Diesel
Voltage (V): 230
Engine: KUBOTA Z482
Engine rpm (rpm): 3000
Starting system: Electric
Engine capacity (cm³): 479
Number cylinders: 2
Cooling: Air
Alternator: Synchronous
Consumption (L/h): 1.7 at 75% load
Acoustic power: 84 dB(A)
Acoustic pressure: 59 dB(A) at 7 m
Length (mm): 858
Width (mm): 560
Height (mm): 631
Dry weight (Kg): 200
Silenced: Yes
Super silenced: Yes
Engine manufacturer: Kubota

Specific References

Condition New

GENSET MG5050DMi VEHICLE GENERATOR WITH INVERTER STAGEV 6.3KVA

The GENSET MG5050DMi is a StageV Vehicular Generator with Inverter, characterized by
a compact, lightweight, and silent design. It is specifically designed for installation on
special vehicles such as workshop trucks, motorhomes, trucks, caravans, and
Civil Protection rescue vehicles. Thanks to its advanced technical features and
compliance with Stage V regulations, this GENSET MG5050DMi StageV provides an ideal
solution for those who need a reliable power source during mobile operations.

Main Technical Features of the GENSET MG5050DMi Stage V with Inverter:

Maximum Power: The GENSET MG5050DMi StageV with Inverter offers a single-phase
power output of 6.3 kVA with an integrated inverter, ensuring stable and precise electrical
supply for a wide range of vehicular applications.
Variable Speed Kubota Engine: Equipped with a Kubota engine compliant with StageV,
this generator ensures optimal energy efficiency and reduced environmental impact,
dynamically adapting to load requirements.
Quiet Operation: With an acoustic power level of 84 Lwa, the GENSET MG5050DMi with Inverter
is designed for extremely quiet operation, making it ideal for use in noise-sensitive
environments.
Dimensions and Weight: Measuring 858 x 560 x 631 mm and weighing 200 kg, this
generator is easily integrable into a wide range of vehicles without compromising stability
or performance.

The GENSET MG5050DMi StageV is equipped with a remote control panel that allows
monitoring of voltage, frequency, hour meter, and RPM via a multifunction display.
Additionally, this vehicular generator features an advanced safety system that automatically
shuts down in the event of low oil level, high water temperature, or engine malfunctions,
ensuring maximum safety during use.

Advantages of the GENSET MG5050DMi StageV with Inverter:

Reliability and Durability: Thanks to the robustness of the Kubota engine and inverter
technology, the GENSET MG5050DMi with Inverter delivers exceptional performance even in
the most demanding operating conditions.
Easy Installation: Its compact dimensions and reduced weight make the
GENSET MG5050DMi with Inverter easy to install on various types of vehicles.
Environmental Respect: Compliance with Stage V regulations ensures reduced emissions,
contributing to environmental protection.
Quiet Operation: The low noise level makes it ideal for operations in residential areas or in
contexts where silence is essential.

Are you looking for a vehicle-mounted generator with different technical specifications? HERE to explore the area dedicated to GENSET generators or other specialized brands.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
