GENSET MHS 6200 H/SA WITHOUT TANK INTERNAL MUFFLER

Name: GENSET MHS 6200 H/SA WITHOUT TANK INTERNAL MUFFLER
Brand: GENSET
SKU: 10809
Price: 6874.7 EUR
Availability: InStock

Reference MHS 6200 H/SA Senza Serbatoio

The standard panel includes the in-cab panel with a cable of approximately 20 meters.

Phase type: Single-phase
Maximum power Single-phase: 6.2 KVA / 4.96 KW
Motor: GX 390 OHV
Motor speed: 3000 rpm
Emission standard: Stage V
No. Cylinders: 1
Cooling: Air
Displacement: 390 cm3
Power: 11 hp (8.2 kWm)
Starter: Electric
Fuel: Petrol
Voltage: 230 V
Frequency: 50 Hz
Tank capacity: 17 litres (version with integrated tank)
Fuel consumption 75%: 3.3 Lt/h
Acoustic pressure: 83 (58 dB at 7 m)
Length: 831 mm
Width: 513 mm
Height: 465 mm - 558 mm (version with integrated tank)
Dry weight: 140 kg - 150 kg (version with integrated tank)

List price

11,651.00 € tax incl.

9,550.00 € tax excl.

Discounted Price

6,874.70 € tax incl.

5,635.00 € tax excl.

Shipping from 61.00 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MHS 6200 H/SA Senza Serbatoio

Data sheet

Phase: Single phase
Maximum power single phase (KW): 4.96
Maximum power single phase (KVA): 6.2
Fuel: Gasoline
Voltage (V): 230
Engine: Honda GX390, OHV
Engine rpm (rpm): 3000
Starting system: Elettrico
Engine capacity (cm³): 390
Number cylinders: 1
Cooling: Air
Alternator: Sincrono
Consumption (L/h): 3.3 al 75% del carico
Acoustic power: 83 dB(A)
Acoustic pressure: 58 dB(A) at 7 m
Length (mm): 831
Width (mm): 515
Height (mm): 465 - 558 (Soundproof Version)
Dry weight (Kg)
Silenced: Yes
Super silenced: Yes
ATS Switch device: Optional
Voltage regulator: No
Engine manufacturer: Honda

Specific References

Condition New

GENSET MHS 6200 H/SA INTERNAL MUFFLER

The GENSET MHS 6200 H/SA Internal Muffler is a high-quality vehicle-mounted generator designed
to provide reliable and continuous power in mobile and industrial applications.
This GENSET MHS 6200 H/SA, known for its efficiency and versatility, stands out due to several key
technical features that make it ideal for a wide range of professional uses.

One of the most distinctive aspects of the GENSET MHS 6200 H/SA Internal Muffler is its without tank
configuration, which offers greater flexibility in installation and integration with existing
fuel systems. This feature allows for optimized use of available space and customization of the
power system according to the user's specific needs.

The GENSET MHS 6200 H/SA is equipped with an internal muffler, which significantly reduces noise
levels during operation. With a sound pressure level of 83 dB (58 dB at 7 meters), it is particularly
suitable for use in noise-sensitive environments, while ensuring maximum comfort for the operator.

As a vehicle-mounted generator, the GENSET MHS 6200 H/SA Internal Muffler is designed to be
installed on commercial vehicles, trucks, and other mobile platforms. Its robustness and reliability
make it the ideal choice for those who need continuous and safe power during transport or at
temporary work sites.

Main Technical Specifications of GENSET MHS 6200 H/SA Internal Muffler:

Phase Type: Single-Phase
Maximum Single-Phase Power: 6.2 KVA / 4.96 KW
Engine: GX 390 OHV
Engine Speed: 3000 rpm
Emission Standard: Stage V
Number of Cylinders: 1
Cooling: Air
Displacement: 390 cm³
Engine Power: 11 hp (8.2 kWm)
Starting System: Electric
Fuel Type: Gasoline
Voltage: 230 V
Frequency: 50 Hz
Fuel Consumption at 75% Load: 3.3 Lt/h

The version With an integrated tank offers a capacity of 17 liters and a total weight ranging between
140 kg and 150 kg, depending on the configuration. The compact dimensions of the generator, with
a length of 831 mm, a width of 513 mm, and a height of 465 mm, make it easy to install on
various types of vehicles and mobile structures.

Are you looking for a vehicle-mounted generator with different technical specifications? HERE to explore the area dedicated to GENSET generators or other specialized brands.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
