LIGHTING TOWER 6x320 W MULTILED WITH HOMOLOGATED TROLLEY AND GENERATOR 5KW
Torre Faro 5KW
Number of headlights: 6
cylinders: 3
Lamp wattage: 320 W LED
Lumen: 249000 lm
Illuminated area: 7800 sqm
Phase type: Single phase
Maximum power: 5 KW
Acoustic pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control unit: DeepSea L401 MKII
Auxiliary power supply: 1.3 kVA
Motor: Yanmar 3TNM68
Revs: 1500rpm
Coolant: Liquid
Emissions standard: Stage V
Alternator: Linz Alumen
Tank capacity: 110 l
Fuel: Diesel
Consumption: 0.55 l/h
Maximum height: 8.5m
Lifting system: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Autonomy: 183 h
Stabilisers 4 + 1 (wheels)
Length (mm): 2350
Width (mm): 147
Height (mm): 2400
Weight (kg): 900
List price
tax incl.
tax excl.
Discounted Price
19,201.58 € tax incl.
15,739.00 € tax excl.
Calculate Shipping Cost
Torre Faro 5KW
Data sheet
- Phase
- Single phase
- Maximum power single phase (KW)
- 5
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine
- Yanmar 3TNM68
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Number cylinders
- 3
- Cooling
- Coolant Liquid
- Alternator
- Linz Alumen SB
- Type of lamps
- MULTILED
- Lamps
- 6 x 320 W
- Telescopic pole
- Vertical
- Illuminated area (m²)
- 7800
- Total lumens (Lm)
- 249000
- Lifting System
- Hydraulic lifting system
- Maximum height (m)
- 8.5
- Mast rotation
- 350°
- Lenght closed (mm)
- 2350
- Width closed (mm)
- 1470
- Height closed (mm)
- 2400
- With generator / Without generator
- With generator
- Transportability
- Fast Trailer
- Stability to wind (Km/h)
- 110
- Fuel tank capacity (L)
- 110
- Consumption (L/h)
- 0.55
- Acoustic pressure
- 61 dB(A) at 7 m
- Weight (Kg)
- 900
Specific References
New
LIGHT TOWER 6x320 W MULTILED WITH APPROVED TROLLEY AND GENERATOR
The light tower is equipped with a Yanmar 3TNM68 diesel-powered engine, capable of delivering a power of 5KW to serve 6 LED 320W lamps.
The tower is equipped with a hydraulic lifting system, capable of raising the tower to a height of 8.5m. Thanks to the 6 LED lamps, it can illuminate an area of 7800 square metres with a maximum luminous intensity of 249000 lm.
The tower is equipped with a Yanmar 3TNM68 Stage V engine, fully compliant with the latest European emission regulations. In addition, the light tower has the possibility of being powered by an external mains supply thanks to the 16 A 230 V socket and plug on the machine. By means of an internal selector switch the operator will decide whether to power the LEDs from the external mains at the work site or via the Stage V generator in the tower.
TECHNICAL FEATURES OF Light Tower:
Number of headlights: 6
cylinders: 3
Lamp wattage: 320 W LED
Lumen: 249000 lm
Illuminated area: 7800 sqm
Phase type: Single phase
Maximum power: 5 KW
Acoustic pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control unit: DeepSea L401 MKII
Auxiliary power supply: 1.3 kVA
Motor: Yanmar 3TNM68
Revs: 1500rpm
Coolant: Liquid
Emissions standard: Stage V
Alternator: Linz Alumen
Tank capacity: 110 l
Fuel: Diesel
Consumption: 0.55 l/h
Maximum height: 8.5m
Lifting system: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Autonomy: 183 h
Stabilisers 4 + 1 (wheels)
Length (mm): 2350
Width (mm): 147
Height (mm): 2400
Weight (kg): 900
Looking for a light tower with different features? Here you can find the full range of towers or other specialized brands.
Images and technical data are not binding and may be subject to revisions by the manufacturer
