ITALTOWER ASTRID PRO05 LIGHTING TOWER 6x320 W MULTILED WITH HOMOLOGATED TROLLEY AND GENERATOR
Number of lights: 6
Lamps power: 320 W LED
Lumen: 249200 lm
Illuminated area: 7800 sqm
Phase type: Single phase
Maximum power: 3. 5 KW
Sound Pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control Unit: DeepSea L401 MKII
Auxiliary Power: 1.3 kVA
Motor: Yanmar 3TNM68
RPM: 1500rpm
Coolant: Liquid
Emissions Standard: Stage V
Alternator: Linz Alumen
Tank capacity: 120 l
Fuel: Diesel
Fuel consumption: 0.55 l/h
Maximum height: 8.5m
Lifting system: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Stabilizers 4 + 1 (wheels)
Length (mm): 2370
Width (mm): 1470
Height (mm): 2400
Dry weight (Kg): 900
.
List price
tax incl.
tax excl.
Discounted Price
19,201.58 € tax incl.
15,739.00 € tax excl.
Calculate Shipping Cost
ASTRID_PRO05
Data sheet
- Phase
- Single phase
- Maximum power single phase (KW)
- 3.5
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine
- Yanmar 3TNM68
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Engine capacity (cm³)
- 686
- Number cylinders
- 2
- Cooling
- Coolant Liquid
- Alternator
- Linz Alumen SB
- Type of lamps
- MULTILED
- Lamps
- 6 x 320 W
- Telescopic pole
- Vertical
- Illuminated area (m²)
- 7800
- Total lumens (Lm)
- 249300
- Lifting System
- Hydraulic lifting system
- Maximum height (m)
- 8.5
- Mast rotation
- 350°
- Lenght closed (mm)
- 2350
- Width closed (mm)
- 1400
- Height closed (mm)
- 2400
- With generator / Without generator
- With generator
- Transportability
- Fast Trailer
- Stability to wind (Km/h)
- 110
- Fuel tank capacity (L)
- 120
- Consumption (L/h)
- 0.55
- Acoustic pressure
- 61 dB(A) at 7.5 m
- Weight (Kg)
- 900
Specific References
New
ITALTOWER ASTRID PRO05 LIGHT TOWER 6x320 W MULTILED WITH APPROVED TROLLEY AND GENERATOR
The ITALTOWER ASTRID PRO05 Light Tower is equipped with a Yanmar 3TNM68 Diesel powered engine, capable of delivering a power of 3.5KW to serve 6 LED lamps 320W.
The ITALTOWER ASTRID PRO05 MULTILED is equipped with a hydraulic lifting system, capable of raising the tower to a height of 8.5 m. Thanks to the 6 LED lamps ITALTOWER ASTRID PRO05 is able to illuminate an area of 7800 square meters with a maximum luminous intensity of 249200 lm.
The ITALTOWER ASTRID PRO03 is equipped with a Yanmar 3TNM68 Stage V engine, fully compliant with the latest European regulations on emissions. Moreover, the ITALTOWER ASTRID PRO05 has the possibility to be powered by an external network thanks to the 16 A 230 V socket and plug present on the machine. By means of an internal selector, the operator can decide whether to power the LEDs from the external power supply present in the work site or from the Stage V generator present in the tower.
The handling of the ITALTOWER ASTRID PRO05 is easier both during transport and storage thanks to the 6 forks for forklift available in the base of the light tower. In the upper part of the carpentry there are 3 eyebolts for an optimal lifting of the tower by means of a crane, in addition it is also equipped with a Ø 50mm ball towing hook.
TECHNICAL FEATURES OF ITALTOWER ASTRID PRO05
Number of lights: 6
Lamps power: 320 W LED
Lumen: 249200 lm
Illuminated area: 7800 sqm
Phase type: Single phase
Maximum power: 3. 5 KW
Sound Pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control Unit: DeepSea L401 MKII
Auxiliary Power: 1.2 kVA
Motor: Yanmar 3TNM68
RPM: 1500rpm
Coolant: Liquid
Emissions Standard: Stage V
Alternator: Linz Alumen
Tank capacity: 120 l
Fuel: Diesel
Fuel consumption: 0.55 l/h
Maximum height: 8.5m
Lifting system: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Stabilizers 4 + 1 (wheels)
Length (mm): 2370
Width (mm): 1470
Height (mm): 2400
Dry weight (Kg): 850
Looking for a light tower with different features? Here you can find the full range of towers ITALTOWER or other specialized brands.
Images and technical data are not binding and may be subject to revisions by the manufacturer
