CGM FX4-320L - TORRE FARO TOWERGEN

CGM AD4-1000JM - TORRE FARO TOWERGEN
search
  • CGM AD4-1000JM - TORRE FARO TOWERGEN
  • CGM AD4-1000JM - TORRE FARO TOWERGEN
CGM
CGM FX4-320L /
New product

OUT OF PRODUCTION

Technical features
Phase
Single phase
Continuous power single phase (KW)
4
Continuous power single phase (KVA)
5
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230
Sockets configuration
1 x 230V 16A
Engine
Kohler KDW702
Engine rpm (rpm)
1500
Starting system
Electric
Number cylinders
2
Cylinders' position
In line
Cooling
Water
Alternator
Linz
Poles
4
Tank capacity (L)
105
Type of lamps
LED
Lamps
4 x 350 W
Telescopic pole
Galvanized steel
Illuminated area (m²)
4500
Lifting System
Manual lifting system
Maximum height (m)
7.7
Mast rotation
358°
Open size (mm)
1700 x 1150 x 7700
Closed size (mm)
1700 x 1150 x 2500
Dry weight (Kg)
700
AVR
Yes
Details
Technical Sheet / Manuals

Technical data sheet FX4-350L

(691.43k)
Ask for availability
Add to wishlist
Download PDF
Ask a question
Product: CGM FX4-320L - TORRE FARO TOWERGEN
Offer on letterhead
Product: CGM FX4-320L - TORRE FARO TOWERGEN
Technical features
Phase
Single phase
Continuous power single phase (KW)
4
Continuous power single phase (KVA)
5
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230
Sockets configuration
1 x 230V 16A
Engine
Kohler KDW702
Engine rpm (rpm)
1500
Starting system
Electric
Number cylinders
2
Cylinders' position
In line
Cooling
Water
Alternator
Linz
Poles
4
Tank capacity (L)
105
Type of lamps
LED
Lamps
4 x 350 W
Telescopic pole
Galvanized steel
Illuminated area (m²)
4500
Lifting System
Manual lifting system
Maximum height (m)
7.7
Mast rotation
358°
Open size (mm)
1700 x 1150 x 7700
Closed size (mm)
1700 x 1150 x 2500
Dry weight (Kg)
700
AVR
Yes
Details
Technical Sheet / Manuals

Technical data sheet FX4-350L

(691.43k)

Related Products
