LIGHTING TOWER 4X160

  • New
    LIGHTING TOWER 4X160
    LIGHTING TOWER 4X160
    LIGHTING TOWER 4X160
    LIGHTING TOWER 4X160
    4x160gp


    Projectors: 4 x 160W LEDs
    Illuminated Area: 2800 m2
    Total Lumens: 81400 lm
    Max Height: 7 m
    Lifting: Manual
    Extra sockets: 1 x 16A CEE / 230 V
    Mast sections: 4
    Manual stabilizers: 4
    Lifting hooks: 4 + 2
    Max wind resistance: 100 km/h
    Fork passage guides: STD
    Transport: Stationary
    Voltage: 230V
    Frequency: 50 Hz
    Closed tower dimensions: 940x797x2118 mm
    Open tower dimensions: 1809x1666x7000 mm
    Dry weight: 235 kg

    List price
    7,905.60 € tax incl.
    6,480.00 € tax excl.
    Discounted Price
    4,665.28 € tax incl.
    3,824.00 € tax excl.
    Quantity :
    Shipping from 97.60 € to Italy buy it today. tax incl.
    Calculate Shipping Cost
    Ask a question
    Offer on letterhead
    Download PDF
    Ask a question

    I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

    Offer on letterhead
    NO BRAND
    4x160gp

    Data sheet

    Frequency (Hz)
    50
    Voltage (V)
    230
    Starting system
    Elettrico
    Type of lamps
    LED
    Telescopic pole
    Galvanized steel
    Illuminated area (m²)
    Total lumens (Lm)
    81400
    Lifting System
    Hydraulic lifting system
    Mast rotation
    359°
    With generator / Without generator
    Without generator
    Transportability
    Stationary
    Dry weight (Kg)
    235

    Specific References

    4X160 LIGHTING TOWER

    The 4X160 is a hydraulically-lifted lighting tower equipped with four floodlights, each delivering 160W of light output.

    The 4X160 is equipped with a galvanized steel lifting tower that can extend up to a maximum height of 7 meters, including four stabilizing feet to secure the lighting tower once opened.

    The 4X160 has an input plug and a 16A 230V output socket, allowing it to be combined with other units.
    The 4X160 is designed to be paired with a generator and can be connected in series to use a single generator for multiple lighting units.

    The light tower's lenses feature highly specialized optics specifically designed for the civil engineering and construction sectors. This innovative, fully directional LED lens design maximizes light diffusion and minimizes waste.

    4X160 is characterized by extremely compact dimensions and a square shape that optimize and facilitate its positioning and transport on mobile vehicles.

    The base, with 4 adjustable and removable anti-tipping stabilizers, guarantees stability in winds of 100 km/h.

    TECHNICAL CHARACTERISTICS 4X160

    Projectors: 4 x 160W LEDs
    Illuminated Area: 2800 m2
    Total Lumens: 81,400 lm
    Max Height: 7 m
    Erection: Manual
    Extra sockets: 1 x 16A CEE / 230 V
    Pole sections: 4
    Manual stabilizers: 4
    Locking hooks Lifting capacity: 4 + 2
    Max. wind resistance: 100 km/h
    Fork passage guides: STD
    Transport: Stationary
    Voltage: 230 V
    Frequency: 50 Hz
    Closed tower dimensions: 940 x 797 x 2118 mm
    Open tower dimensions: 1809 x 1666 x 7000 mm
    Dry weight: 235 kg

    Looking for a product with different features? HERE You can find the entire range.

    * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
