CGM 10DW - BOXED WITH AUTOMATIC CONTROL UNIT
CGM 10DW COFANATO AUTOMATICO /
PRODUCT DISCONTINUED
Three-phase maximum power: 8.8 KW
Three-phase continuous power: 8 KW
Three-phase maximum power: 11 KVA
Three-phase continuous power: 10 KVA
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Electrical protection: IP44
Engine: LOMBARDINI LDW 702
Displacement: 686 cc
Engine speed: 3000 rpm
Bore x stroke: 75 x 77.6 mm
Aspiration: Natural
Speed governor: Mechanical
Number and arrangement of cylinders: 2 in-line
Cooling system: Water
Starting system: Electric
Alternator: Linz, with brushes
Poles: 2
Voltage regulator system: Compound
Fuel consumption: 2.9 L/h at 75% load
Tank capacity: 50 L
Autonomy: 17.2 h at 75% load
Sound pressure level: 70 dB(A) at 7 m
Length: 1600 mm
Width: 700 mm
Height: 1050 mm
Weight: 290 Kg
- Phase
- Single phase / Three phase
- Maximum power three phase (KW)
- 8.8
- Continuous power three phase (KW)
- 8
- Maximum power three phase (KVA)
- 11
- Continuous power three phase (KVA)
- 10
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Engine
- Lombardini LDW702
- Engine rpm (rpm)
- 3000
- Starting system
- Electric
- Engine capacity (cm³)
- 686
- Number cylinders
- 2
- Cylinders' position
- In line
- Cooling
- Water
- Alternator
- With brushes
- Poles
- 2
- Bore x stroke (mm)
- 75 x 77.6
- Fuel tank capacity (L)
- 50
- Consumption (L/h)
- 2.9 at 75% of the load
- Running time (h)
- 17.2
- Length (mm)
- 1600
- Width (mm)
- 700
- Height (mm)
- 1050
- Dry weight (Kg)
- 290
- Silenced
- Yes
- Super silenced
- Yes
- ATS Switch device
- Optional ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Lombardini
- Brand
-
These generator sets are equipped with Lombardini/Kohler diesel engines with electric start (key and battery).
Alternator with 400 Volt three-phase output with accessible neutral or 230 Volt single-phase – 50 Hz, mounted on a base frame. Manual control panel mounted on the unit.
Main applications: isolated houses, campsites, alpine shelters, small construction sites, restaurants, farms, artisan industries, sports centers, service stations, etc.
The 3000 rpm sets are suitable for emergency, non-continuous use; operation for more than 6 consecutive hours and more than 500 hours/year is not recommended.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
