CGM 10B

CGM 10B
CGM 10B
CGM 12BET APERTO MANUALE /

OUT OF PRODUCTION

Download Technical data sheet CGM 12BET

Phase
Single phase / Three phase
Protection degree
IP55
Height (mm)
650
Length (mm)
860
Starting system
Electric
Width (mm)
550
Engine manufacturer
Briggs&Stratton
Engine
Briggs&Stratton
Poles
2
Cooling
Air
Maximum power three phase (KW)
10.5
Continuous power three phase (KW)
9.6
Maximum power three phase (KVA)
13.2
Continuous power three phase (KVA)
12
Fuel
Gasoline
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine rpm (rpm)
3000
Engine capacity (cm³)
570
Number cylinders
2
Oil capacity (L)
1.7
Alternator
With brushes
Fuel tank capacity (L)
8.5
Consumption (L/h)
4.3
Running time (h)
2 al 75% del carico
Acoustic pressure
73 dB(A) at 7 m
Dry weight (Kg)
135
Silenced
No
Super silenced
No
ATS Switch device
No ATS
Voltage regulator
Compound
Brand

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
