GENSET MGF 33 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 33 KVA AVR
MGF 33 Y
Maximum power Three-phase: 33 KVA
Maximum power Three-phase: 26.4 KW
Maximum power Single-phase: 11 KVA
Maximum power Single-phase: 8.8 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98 (STAGE 0)
Starting: Electric
Consumption: 6.4 Lt/h
Length: 1640 mm
Width: 770 mm
Height: 1076 mm
Weight: 830 Kg
Super silenced
AVR
- Phase
- Three phase
- Maximum power three phase (KVA)
- 33
- Continuous power three phase (KVA)
- 30
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- Engine
- Yanmar 4TNV98, 4 stroke
- Emissions Regulations
- Stationary Use
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 3319
- Number cylinders
- 4
- Cooling
- Water
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 40
- Consumption (L/h)
- 6.4
- Running time (h)
- 6.25
- Acoustic power
- 97 dB(A)
- Acoustic pressure
- 72 dB(A) at 7 m
- Length (mm)
- 1640
- Width (mm)
- 770
- Height (mm)
- 1076
- Dry weight (Kg)
- 830
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Yanmar
- Brand
-
GENSET MGF 33 Y
The GENSET MGF 33 Y is a single-phase/three-phase 33 KVA diesel generator with electric start and AVR voltage regulator.
Thanks to its compact size and its very low weight, the GENSET MGF 33 Y is a light and easy to transport generator.
The GENSET MGF 33 Y also has a low fuel consumption: only 6.4 Lt/h at 75% of the load.
The GENSET MGF 33 Y generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
