PRAMAC GBW22P OPEN WITH MANUAL CONTROL PANEL (MCP)
SH200TPAL00 /
OUT OF PRODUCTION
Maximum power Three-phase: 17.46 KW
Three-phase continuous use power: 15.82 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Perkins 404D-22G STAGE III A
Starting: Electric
Consumption: 5.3 Lt/h at 100% of the load
Length: 1600 mm
Width: 870 mm
Height: 950 mm
Weight: 425 Kg
Compound
- Phase
- Three phase
- Maximum power three phase (KW)
- 17.46
- Continuous power three phase (KW)
- 15.42
- Maximum power three phase (KVA)
- 21.82
- Continuous power three phase (KVA)
- 19.78
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE - 1 x 400V 16A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
- Engine
- PERKINS 404D-22G, naturally aspirated
- Emissions Regulations
- Stage 3A
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 2216
- Number cylinders
- 4
- Cylinders' position
- In line
- Oil capacity (L)
- 10.6
- Cooling
- Water
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 4 at 75% of the load / 5.3 at 100% of the load
- Running time (h)
- 12.8 at 75% of the load / 9.7 at 100% of the load
- Length (mm)
- 1600
- Width (mm)
- 870
- Height (mm)
- 950
- Dry weight (Kg)
- 425
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- No ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Perkins
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
