TECNOGEN H15000ELX
H 15000 ELX - C
Single-phase maximum power: 10.4 KW
Single-phase maximum power: 13 KVA
Fuel: Petrol
Voltage: 230 V
Frequency: 50 Hz
Engine: Honda GX690
Starting: Electric
Length: 990 mm
Width: 550 mm
Height: 670 mm
Weight: 133 Kg
- Phase
- Single phase
- Maximum power single phase (KW)
- 10.4
- Maximum power single phase (KVA)
- 13
- Fuel
- Gasoline
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine
- HONDA GC160
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 3000
- Starting system
- Electric
- Engine capacity (cm³)
- 688
- Number cylinders
- 2
- Cooling
- Air
- Fuel tank capacity (L)
- 20
- Consumption (L/h)
- 7
- Running time (h)
- 2.85
- Acoustic power
- 98 dB(A)
- Length (mm)
- 990
- Width (mm)
- 550
- Height (mm)
- 670
- Dry weight (Kg)
- 133
- Silenced
- No
- Super silenced
- No
- ATS Switch device
- Optional ATS
- Voltage regulator
- No
- Engine manufacturer
- Honda
- Brand
-
Generating sets available in both single-phase and three-phase versions, with powers from 4.5 to 13.3 kVA MAX, equipped with gasoline or diesel engines, air-cooled, 3000 rpm, with electric and / or manual start with self-winding. Characterized by a particularly sophisticated design, they also stand out in terms of the set-up. In fact, they have a complete coverage of the upper part consisting of a sturdy sheet metal roof with central lifting point, a 20 Lt tank in polyethylene and an electrical panel positioned in a special protected compartment, separated from the motor / alternator unit and therefore exempt. from vibrations, equipped with hour meter and magnetothermic / differential switch. Thanks to their features and the latest generation Honda engines, which allow the petrol versions to fall within the parameters of the noise directive 2000/14 / EC, the LX series generator sets are the ideal solution for operators who need generators equipped with a professional set-up while remaining in the range of non-soundproofed machines.
The image is purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
Complete your order with:
Unavailable
€580.00 Tax included
€580.00 Tax excluded
