PRAMAC ES5000 THREE-PHASE PETROL Generator, AVR
PE532TH100B
Maximum power Single-phase: 3.04 KW
Single-phase continuous use power: 2.8 KW
Maximum power Three-phase: 5 KW
Power continuous use Three-phase: 4.3 KW
Fuel: Gasoline
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Honda GX270 Recoil
Starting: Tear-off
Consumption: 2.2 Lt/h at 100% of load
Length: 729 mm
Width: 500 mm
Height: 536 mm
Weight: 75 Kg
AVR
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 3.04
- Continuous power single phase (KW)
- 2.8
- Maximum power single phase (KVA)
- 3.8
- Continuous power single phase (KVA)
- 3.5
- Maximum power three phase (KW)
- 5
- Continuous power three phase (KW)
- 4.3
- Maximum power three phase (KVA)
- Continuous power three phase (KVA)
- 5.4
- Fuel
- Gasoline
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A 3P+N+T CEE IP44 - 1 x 230V 16A SCHUKO IP54 - 1 x 230V 16A 2P+T CEE IP44
- Engine
- Honda GX270 Recoil, naturally aspirated
- Engine rpm (rpm)
- 3000
- Speed governor
- Mechanical
- Ignition
- Recoil
- Starting system
- Pull starter
- Engine capacity (cm³)
- 270
- Oil capacity (L)
- 1.1
- Cooling
- Air
- Alternator
- With brushes
- Poles
- 2
- Fuel tank capacity (L)
- 11
- Consumption (L/h)
- 1.6 at 75% of the load / 2.2 at 100% of the load
- Running time (h)
- 6.6 at 75% of the load / 5 at 100% of the load
- Acoustic power
- 97 dB(A)
- Acoustic pressure
- 69 dB(A) at 7 m
- Length (mm)
- 729
- Width (mm)
- 500
- Height (mm)
- 536
- Dry weight (Kg)
- 75
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- No ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Honda
- Brand
-
Model with gasoline fuel supply, characterized by a strong structure with tubular frame and adequate protections in sheet steel with oversized tank incorporated.
Designed to satisfy long lasting professional and intensive applications.
HONDA GX series petrol engines
? Air cooling
? Oil Guard protection
? Tear-off starter
? Synchronous alternators available with AVR
? Sturdy structure with tubular supporting frame
? Sockets on headphones with thermal protection.
? Oversized tanks (11 litres)
? Side protection strips
The image is purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
