HONDA GCV190A A1P7 Engine
GCV190A A1P7 /
OUT OF PRODUCTION
Net power (kW): 3.8
Net power (Hp): 5.1
Fuel: Petrol
Starter system: Recoil starter
Round per minute (rpm): 3600
Displacement (cm3): 160
Lenght (mm): 395
Width (mm): 331
Height (mm): 361
Dry weight (Kg): 12.3
Fuel tank capacity (Lt.): 0.93
Displacement: 187 cm³
- Fuel
- Gasoline
- Engine
- OHC vertical shaft, 4 stroke, aluminum cylinder
- Ignition
- A transistor contactless
- Starting system
- Manual
- Engine capacity (cm³)
- 187
- Number cylinders
- 1
- Oil capacity (L)
- 0.55
- Cooling
- Forced air
- Bore x stroke (mm)
- 69 x 50
- Compression ratio
- 8.5 : 1
- Net power (kW)
- 3.8
- Nominal power continuous
- 2.6 KW (3.5 HP) / 3000 rpm
- Maximum torque
- 11.3 Nm / 1.15 kgfm / 2500 rpm
- Air filter system
- Dry
- Fuel tank capacity (L)
- 0.93
- Consumption (L/h)
- 1.3
- Running time (h)
- 0.71
- Length (mm)
- 395
- Width (mm)
- 329
- Height (mm)
- 361
- Dry weight (Kg)
- 12.3
- Engine manufacturer
- Honda
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
