HONDA GX390UT2 LXE4 Engine
GX390UT2 LXE4 /
OUT OF PRODUCTION
Net power (kW): 8.7
Net power (Hp): 11.7
Fuel: Petrol
Starter system: Recoil starter
Round per minute (rpm): 3600
Displacement (cm3): 389
Lenght (mm): 406
Width (mm): 460
Height (mm): 448
Dry weight (Kg): 31.7
Fuel tank capacity (Lt.): 6.1
- Fuel
- Gasoline
- Engine
- OHC ad albero orizzontale, 4 tempi, cilindro in ghisa
- Ignition
- Digital CDI with variable ignition advance
- Starting system
- Manual
- Engine capacity (cm³)
- 389
- Number cylinders
- 1
- Cylinders' position
- Inclined to 25°
- Oil capacity (L)
- 1.1
- Cooling
- Forced air
- Bore x stroke (mm)
- 88 x 64
- Compression ratio
- 8.2 : 1
- Net power (kW)
- 8.7
- Nominal power continuous
- 6.4 KW (8.6 HP) / 3000 rpm - 7.0 KW (9.4 HP) / 3600 rpm
- Maximum torque
- 26.5 Nm / 2.7 kgfm / 2500 rpm
- Fuel tank capacity (L)
- 6.1
- Consumption (L/h)
- 3.5
- Running time (h)
- 1.74
- Length (mm)
- 406
- Width (mm)
- 460
- Height (mm)
- 448
- Dry weight (Kg)
- 31.7
- Engine manufacturer
- Honda
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
