ITALTOWER ASTRID PRO04 LIGHTING TOWER 6x160 W MULTILED WITH HOMOLOGATED TROLLEY AND GENERATOR
Number of lights: 6
Lamps power: 160 W LED
Lumen: 122100 lm
Illuminated area: 4200 sqm
Phase type: Single phase
Maximum power: 3. 5 KW
Sound Pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control Unit: DeepSea L401 MKII
Auxiliary Power: 1.2 kVA
Motor: Yanmar 2TNV70
RPM: 1500rpm
Coolant: Liquid
Emissions Standard: Stage V
Alternator: Linz Alumen
Tank Capacity: 120 l
Fuel: Diesel
Fuel Consumption: 0.55 l/h
Maximum Height: 8.5m
Lifting System: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Stabilizers 4 + 1 (wheels)
Length (mm): 2370
Width (mm): 1470
Height (mm): 2400
Dry weight (Kg): 850
List price
tax incl.
tax excl.
Discounted Price
15,208.52 € tax incl.
12,466.00 € tax excl.
Calculate Shipping Cost
ASTRID_PRO04
Data sheet
- Phase
- Single phase
- Maximum power single phase (KW)
- 3.5
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine
- Yanmar 2TNV70
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Engine capacity (cm³)
- 686
- Number cylinders
- 2
- Cooling
- Coolant Liquid
- Alternator
- Linz Alumen SB
- Type of lamps
- MULTILED
- Lamps
- 6 x 160 W
- Telescopic pole
- Vertical
- Illuminated area (m²)
- 4200
- Total lumens (Lm)
- 122100
- Lifting System
- Hydraulic lifting system
- Maximum height (m)
- 8.5
- Mast rotation
- 350°
- Lenght closed (mm)
- 2350
- Width closed (mm)
- 1400
- Height closed (mm)
- 2400
- With generator / Without generator
- With generator
- Transportability
- Fast Trailer
- Stability to wind (Km/h)
- 110
- Fuel tank capacity (L)
- 120
- Consumption (L/h)
- 0.55
- Acoustic pressure
- 61 dB(A) at 7.5 m
- Weight (Kg)
- 855
Specific References
New
ITALTOWER ASTRID PRO04 LIGHT TOWER 6x160 W MULTILED WITH APPROVED TROLLEY AND GENERATOR
The ITALTOWER ASTRID PRO04 Light Tower is equipped with a Yanmar 2TNV70 Diesel powered engine, capable of delivering a power of 3.5KW to serve 6 LED lamps 160W.
The ITALTOWER ASTRID PRO04 MULTILED is equipped with a hydraulic lifting system, capable of raising the tower to a height of 8.5 m. Thanks to the 4 LED lamps ITALTOWER ASTRID PRO04 is able to illuminate an area of 4200 square meters with a maximum luminous intensity of 122100 lm.
The ITALTOWER ASTRID PRO04 is equipped with a Yanmar 2TNV70 Stage V engine, fully compliant with the latest European regulations on emissions. Moreover, the light tower has the possibility to be powered by an external network thanks to the 16 A 230 V socket and plug present on the machine. By means of an internal selector, the operator can decide whether to power the LEDs from the external power supply present in the work site or from the Stage V generator present in the tower.
The ITALTOWER ASTRID PRO04 has a fast towing trolley approved for circulation on public roads throughout Europe. The road trolley is equipped with LED lights for greater visibility during circulation. A fundamental safety system allows the hydraulic pole to immediately descend once the main parking brake is removed.
TECHNICAL FEATURES OF ITALTOWER ASTRID PRO04
Number of lights: 6
Lamps power: 160 W LED
Lumen: 122100 lm
Illuminated area: 4200 sqm
Phase type: Single phase
Maximum power: 3. 5 KW
Sound Pressure: 61dB(A) @ 7m
Voltage: 230 V
Frequency: 50 Hz
Control Unit: DeepSea L401 MKII
Auxiliary Power: 1.2 kVA
Motor: Yanmar 2TNV70
RPM: 1500rpm
Coolant: Liquid
Emissions Standard: Stage V
Alternator: Linz Alumen
Tank Capacity: 120 l
Fuel: Diesel
Fuel Consumption: 0.55 l/h
Maximum Height: 8.5m
Lifting System: Hydraulic
Rotation: 350°
Wind resistance: 110 Km/h
Trolley: Road trolley (EU standard)
Stabilizers 4 + 1 (wheels)
Length (mm): 2370
Width (mm): 1470
Height (mm): 2400
Dry weight (Kg): 850
Looking for a light tower with different features? Here you can find the full range of towers ITALTOWER or other specialized brands.
Images and technical data are not binding and may be subject to revisions by the manufacturer
