MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA
      MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA
      MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA
      MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA
      MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA

      MECC ALTE ECP28-2L/2 C-TYPE THREE-PHASE ALTERNATOR 30KVA

      ECP28-2L/2C SAE3 d6.5

      Phase Type:Single Phase / Three Phase
      Maximum Single Phase Output:
      (50Hz) 20 KVA / 20 KW
      (60Hz) 24 KVA / 24 KW
      Continuous Single Phase Output:
      (50Hz) 18.9 KVA / 18.9 KW
      (60Hz) 22. 7 KVA / 22.7 KW
      Maximum three-phase output:
      (50Hz) 31.5 KVA / 25.2 KW
      (60Hz) 38 KVA / 30.4 KW
      Continuous three-phase output:
      (50Hz) 30 KVA / 24 KW
      (60Hz) 36 KVA / 28. 8 KW
      Frequency: 50 / 60 Hz
      Voltage: 230 / 400 V
      Degree of protection: IP23
      Alternator revolutions: 3000 rpm
      Number of poles: 2
      Efficiency: 87.2%
      Weight: 141 Kg
      Width: 466.7 mm
      Length: 548.8 mm
      Height: 460 mm
      Constant speed alternator
      Brushless
      Voltage regulator: AVR

      List price
      2,862.12 € tax incl.
      2,346.00 € tax excl.
      Discounted Price
      2,160.90 € tax incl.
      1,771.23 € tax excl.
      Choose the type of coupling :
      Download PDF
      Custom Quote

      PERSONAL DATA


      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      MECC ALTE
      ECP28-2L/2C SAE3 d6.5

      Data sheet

      Phase
      Single phase / Three phase
      Maximum power single phase (KW)
      20 (50Hz) - 24 (60Hz)
      Continuous power single phase (KW)
      18.9 (50Hz) - 22.7 (60Hz)
      Maximum power single phase (KVA)
      20 (50Hz) - 24 (60Hz)
      Continuous power single phase (KVA)
      18.9 (50Hz) - 22.7 (60Hz)
      Maximum power three phase (KW)
      25.2 (50Hz) - 30.4 (60Hz)
      Continuous power three phase (KW)
      24 (50Hz) - 28.8 (60Hz)
      Maximum power three phase (KVA)
      31.5 (50Hz) - 38 (60Hz)
      Continuous power three phase (KVA)
      30 (50Hz) - 36 (60Hz)
      Frequency (Hz)
      50 / 60
      Voltage (V)
      230 / 400
      Engine rpm (rpm)
      3000
      Poles
      2
      Single-phase power (KVA)
      24
      Three-phase power (KVA)
      38
      Efficiency (%)
      87.2
      Protection degree
      IP23
      Acoustic pressure
      74 dB(A) at 7 m
      Length (mm)
      466
      Width (mm)
      548.8
      Height (mm)
      460
      Brushes
      No
      PMG
      No
      Type of alternator
      Constant Speed
      Voltage regulator
      AVR
      Weight (Kg)
      141

      Specific References

      New

      MECC ALTE ECP28-2L/2 C-TYPE ALTERNATOR 30KVA THREEPHASE

      Alternator MECC ALTE ECP28-2L/2 C-TYPE with a power of 30KVA, this unit has a Brushless self-exciting and self-regulating operation equipped with voltage regulator DSR.

      The ECP28-2L/2 C-TYPE alternator is designed to operate at 50 or 60 HZ frequency, the possibility of working on these two frequencies makes it possible to apply it for any service voltage increasing its versatility, for the correct operation.

      The ECP28-2L/2 alternators mount button-type diodes, mounted directly in the exciter's diode holder, or mounted on a detachable diode bridge, divided into three sectors. In the case of the bridge, each individual diode can be verified very easily with a multimeter specially set for diode verification.

      MECC ALTE ECP28-2L/2 C-TYPE is supplied with 12 terminals (7 clamps), with which it is normally possible to connect the alternator both star series and star parallel. According to the needs it is possible to pass from a connection to another one keeping in mind that it is necessary to verify the DSR connection.

      ECP28-2L/2 C-TYPE can be used as singlephase depending on the needs. MECC ALTE ECP28-2L/2 is equipped with digital current regulator DSR . The regulator is suitable for operation on both threephase and singlephase generators, allowing fast, accurate and reliable set-up.

      All MECC ALTE ECP28 alternators have the MAUX auxiliary winding to power the DSR digital regulator. You can connect the DSR voltage regulator to your PC via the DxR2 USB interface and DxR TERMINAL software to query/download alarms and settings for analysis.

      Select the alternator that reflects thetechnical specifications you require, visit our dedicated section to find out how.

      TECHNICAL FEATURES OF 22KVA MECC ALTERNATOR ECP28-2L/2 C-TYPE

      Phase Type: Singlephase / ThreePhase
      Maximum ThreePhase Power: 28. 8KW
      Threephase continuous power: 24KW
      Threephase maximum power: 36KVA
      Threephase continuous power: 30KVA
      Frequency: 50 / 60 Hz
      Voltage: 230 / 400 V
      Protection class: IP23
      Alternator speed: 3000 rpm
      Number of poles: 2
      Efficiency: 87. 2%
      Weight: 141 kg
      Width: 466.7 mm
      Length: 548.8 mm
      Height: 460 mm
      Constant speed alternator
      Brushless
      Voltage regulator: AVR

      Looking for a product with different features? Here you can find the full range MECC ALTE and other specialized brands.

      Images and technical data are not binding and subject to changes by the manufacturer

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
      Mecc Alte - Radio-VDE 0875 CLASS K interference suppressor kit for ECP
          Radio-VDE 0875 CLASS K interference suppressor kit for ECP28 alternators.
          155.00 €Price
          Mecc Alte - Parallel TA for ECP28 alternators.
              Parallel current transformer TA (including saddle when required) for ECP28 alternators.
              185.00 €Price
              Mecc Alte - Voltage control potentiometer for ECP28 alternators.
                  Voltage control potentiometer for ECP28 alternators.
                  48.31 €Price
                  Mecc Alte - Diode RBD-1 failure sensor for ECP28 alternators.
                      Diode RBD-1 failure sensor for ECP28 alternators.
                      356.15 €Price
                      Mecc Alte - Coupling bell for type B3-B14 for ECP28 alternators.
                          Coupling bell for type B3-B14 for ECP28 alternators.
                          601.07 €Price
                          Mecc Alte - PTCK150 temperature sensor for ECP28 alternators.
                              PTCK150 temperature sensor (1 set of 3) for ECP28 alternators.
                              235.30 €Price
                              Mecc Alte - PT100 RTD sensor on windings for ECP28 alternators.
                                  PT100 RTD sensor on windings (1 of 3) for ECP28 alternators.
                                  252.20 €Price
                                  Mecc Alte - PT100 RTD sensor on windings for ECP28 alternators.
                                      PT100 RTD sensor on windings (2 of 3) for ECP28 alternators.
                                      478.40 €Price
                                      Mecc Alte - PT100 RTD (for bearing) for ECP28 alternators.
                                          PT100 RTD (for bearing) for ECP28 alternators.
                                          404.46 €Price
                                          Mecc Alte - Bimetallic probe (thermal protection) for ECO alternators.
                                              Bimetallic probe (thermal protection) for ECP28 alternators.
                                              209.95 €Price
                                              Mecc Alte - DER1 AVR (three phase sensing) for ECP28 alternators.
                                                  DER1 AVR (three phase sensing) (+/- 0.5%) (factory fitted only) for ECP28 alternators.
                                                  200.20 €Price
                                                  Mecc Alte - USB 2 DxR digital interface for ECP28 alternators.
                                                      USB 2 DxR digital interface for ECP28 alternators.
                                                      200.20 €Price
                                                      Mecc Alte - DER2 AVR (three phase sensing) for ECP28 alternators.
                                                          DER2 AVR (three phase sensing integrated USB) (+/- 0.5%) (factory fitted only) for ECP28 alternators.
                                                          280.15 €Price
                                                          Mecc Alte - High terminal box for ECP28 alternators.
                                                              High terminal box for ECP28 alternators.
                                                              86.00 €Price
                                                              Mecc Alte - Spacer ring for Lister Petter TR1/TS1 coupling for ECP28.
                                                                  Spacer ring for Lister Petter TR1/TS1 coupling for ECP28 alternators.
                                                                  101.40 €Price
                                                                  Mecc Alte - Lister Petter TR2-3/TS2-3 coupling for ECP28 alternators.
                                                                      Lister Petter TR2-3/TS2-3 coupling for ECP28 alternators.
                                                                      73.00 €Price
                                                                      Mecc Alte - Air filter for rear inlet (loss 7%) for ECP28 alternators.
                                                                          Air filter for rear inlet (loss 7%) for ECP28 alternators.
                                                                          277.00 €Price
                                                                          Mecc Alte - IP45 protection screen for ECP28 alternators.
                                                                              IP45 protection screen (Derating applies) for ECP28 alternators.
                                                                              549.90 €Price
                                                                              Mecc Alte - Anti-condensation heater - rear part for ECP28 alternators.
                                                                                  Anti-condensation heater - rear part (factory fitted) for ECP28 alternators.
                                                                                  204.48 €Price
                                                                                  Mecc Alte - Anti-condensation heater - front part for ECP28 alternators
                                                                                      Anti-condensation heater - front part (factory fitted) for ECP28 alternators.
                                                                                      204.48 €Price
                                                                                      Mecc Alte - Anti-condensation heater on the rear shield for ECP28.
                                                                                          Anti-condensation heater on the rear shield (can be integrated) for ECP28 alternators.
                                                                                          204.48 €Price
                                                                                          Mecc Alte - Grey impregnation (exciter and main stator Grey) for ECP28
                                                                                              Grey impregnation (exciter and main stator Grey) for ECP28 alternators.
                                                                                              241.00 €Price
                                                                                              Mecc Alte - Grey impregnation + for ECP28 alternators.
                                                                                                  Grey impregnation + (Grey main stator and Black exciter stator) for ECP28 alternators.
                                                                                                  235.30 €Price
                                                                                                  Mecc Alte - Total Impregnation + for ECP28 alternators. | Manel Service
                                                                                                      Total Impregnation + (Black main stator & exciter stator, Grey rotor) for ECP28 alternators.
                                                                                                      319.80 €Price
