CHARGERS

Power supply (AC V): 3x400 Supply voltage range (VAC): 320-450 Frequency (Hz): 45-65 Power factor: 1 Boost" charge (V DC): 28.5 Float' charge (V DC): 26.5 Main charging current (A): 100 Auxiliary charge current (A): 4 Charging mode: IUoUo (3-stage charging) Battery capacity (Ah): 500-1000 Operating temperature: -40 to +50°C (-40 to 122°F)<br...

Supply voltage range (VAC): 3x400 Supply voltage range (VAC): 320-450 Frequency (Hz): 45-65 Power factor: 1 "Boost" charge (V DC): 28.5 "Float" charge (V DC): 26.5 Main charging current (A): 50 Auxiliary charging current (A): 4 Charging mode: IUoUo (3-step charging) Battery capacity (Ah): 250-500 Operating temperature: -40 to +50°C (-40 to...

PowerControl: No Parallel and three-phase operation: Yes Transfer switch: 16A INVERTER Input voltage range: 9.5 to 17 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25℃: 500 VA Continuous output power at 25℃ / 40℃ / 65℃: 430 W / 400 W / 300W Peak power 900 W Maximum efficiency 90% Zero load power...

PowerControl: No Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 – 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 500 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 430 W / 400 W / 300W Peak Power: 900 W Maximum Efficiency: 91% Zero Load Power...

PowerControl: No Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 500 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 430 W / 400 W / 300W Peak Power: 900 W Maximum Efficiency: 92% Zero Load Power...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 800 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 700 W / 650 W / 400W Peak Power: 1500 W Maximum Efficiency: 92% Zero Load Power...

PowerControl: Yes Parallel and Three-phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 800 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 700 W / 650 W / 400W Peak Power 1500 W Maximum Efficiency 93 % Zero Load Power...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 16A INVERTER Input voltage range: 38 - 66 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25°C: 800 VA Continuous output power at 25℃ / 40℃ / 65℃: 700 W / 650 W / 400W Peak power 1500 W Maximum efficiency 94% Zero-load power...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 16A INVERTER Input voltage range: 9.5 – 17 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25°C: 1200 VA Continuous output power at 25℃ / 40℃ / 65℃: 1000 W / 900 W / 600 W Peak power: 2400 W Maximum efficiency: 93% Zero load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1200 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1000 W / 900 W / 600 W Peak Power: 2400 W Maximum Efficiency: 94% No-Load Power...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1200 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1000 W / 900 W / 600 W Peak Power: 2400 W Maximum Efficiency: 95% Zero Load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1600 VA Continuous Output Power at 25°C / 40°C / 65°C: 1300 W / 1100 W / 800 W Peak Power: 2800 W Maximum Efficiency: 93% No-Load...

PowerControl: Yes Parallel and Three-phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1600 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1300 W / 1100 W / 800 W Peak Power 2800 W Maximum Efficiency 94% Zero Load Power...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1600 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1300 W / 1100 W / 800 W Peak Power 2800 W Maximum Efficiency 95% Zero-Load Power...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 35 A INVERTER Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 2000 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1600 W / 1400 W / 1000 W Peak Power: 3500 W Maximum Efficiency: 93 % Zero-Load...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 35 A INVERTER Input voltage range: 19 - 33 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25°C: 2000 VA Continuous output power at 25℃ / 40℃ / 65℃: 1600 W / 1400 W / 1000 W Peak power 3500 W Maximum efficiency 94 % Zero load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 35 A INVERTER Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 2000 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1600 W / 1400 W / 1000 W Peak Power: 3500 W Maximum Efficiency: 95% Zero-Load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 100 A INVERTER Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 5000 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 4000 W / 3700 W / 3000 W Peak Power: 10000 W Maximum Efficiency: 94% Zero-Load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 100 A INVERTER Input Voltage Range: 38 - 60 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 5000 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 4000 W / 3700 W / 3000 W Peak Power: 10000 W Maximum Efficiency: 95% Zero-Load...

PowerControl and PowerAssist: Yes Transfer Switch: 32 A Maximum AC Input Current: 32 A Auxiliary Output: Yes INVERTER DC Input Voltage Range: 19 – 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1) Continuous Output Power at 25 °C: 3000 VA Continuous Output Power at 25℃ / 40 °C / 65°C: 2400 W / 2200 W / 1700 W Maximum Apparent...

PowerControl and PowerAssist: Yes Transfer switch: 32 A Maximum AC input current: 32 A INVERTER DC input voltage range: 38 - 66 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1) Continuous output power at 25 °C: 3000 VA Continuous output power at 25℃ / 40 °C / 65°C: 2400 W / 2200 W / 1700 W Maximum apparent input current: 3000 VA<br...

PowerControl and PowerAssist: Yes Transfer Switch: 50 A Max AC Input Current: 50 A INVERTER DC Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous Output Power at 25°C: 5000 VA Continuous Output Power at 25℃ / 40°C / 65°C: 4000 W / 3700 W / 3000 W Max Apparent Input Current: 5000 VA Peak...

PowerControl and PowerAssist: Yes Transfer Switch: Yes Max AC Input Current: 2 x 50 A INVERTER DC Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1) Continuous Output Power at 25°C: 3000 VA Continuous Output Power at 25℃ / 40°C / 65°C: 2400 W / 2200 W / 1700 W Peak Power: 6000 W Max Efficiency: 93%<br...

PowerControl and PowerAssist: Yes Transfer Switch: Yes Maximum AC Input Current: 2 x 100 A INVERTER DC Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1) Continuous Output Power at 25 °C: 5000 VA Continuous Output Power at 25℃ / 40 °C / 65°C: 4000 W / 3700 W / 3000 W Peak Power: 10000 W Maximum...

PowerControl and PowerAssist: Yes Transfer Switch: Yes Maximum AC Input Current: 2 x 50 A INVERTER DC Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous Output Power at 25 °C: 3000 VA Continuous Output Power at 25℃ / 40 °C / 65°C: 2400 W / 2200 W / 1700 W Peak Power: 6000 W Maximum...

PowerControl and PowerAssist: Yes Transfer Switch: Yes Maximum AC Input Current: 2 x 100 A INVERTER DC Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous Output Power at 25°C: 5000 VA Continuous Output Power at 25℃ / 40°C / 65°C: 4000 W / 3700 W / 3000 W Peak Power: 10000 W Maximum...

PowerControl and PowerAssist: Yes Transfer switch: Yes Maximum AC input current: 2 x 100 A INVERTER DC input voltage range: 19 - 33 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1) Continuous output power at 25°C: 8000 VA Continuous output power at 25°C / 40°C / 65°C: 6400 W / 5500 W / 3600 W Peak power: 16000 W Maximum...

PowerControl and PowerAssist: Yes Transfer Switch: Yes Maximum AC Input Current: 2 x 100 A INVERTER DC Input Voltage Range: 38 - 66 V Output Voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous Output Power at 25°C: 5000 VA Continuous Output Power at 25℃ / 40°C / 65°C: 4000 W / 3700 W / 3000 W Peak Power: 10000 W Maximum...

PowerControl and PowerAssist: Yes Transfer switch: Yes Maximum AC input current: 2 x 100 A INVERTER DC input voltage range: 38 - 66 V Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous output power at 25 °C: 8000 VA Continuous output power at 25℃ / 40 °C / 65°C: 6400 W / 5500 W / 3600 W Peak power: 16000 W Maximum...

Input Voltage: 230 Vac Input Voltage Range: 185-264 Vac Frequency: 45-65 Hz Power Factor: 1 "Boost" Charge Voltage: 28.5 Vdc "Float" Charge Voltage: 26.5 Vdc Main Charge Current: 80 A Auxiliary Charge Current: 4 A Charge Mode: IUoUo (3-stage charging) Battery Capacity: 400 - 800 Ah Operating Temperature: -40 to +50°C (-40 - 122°F)<br...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 800 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 700 W / 650 W / 400W Peak Power: 1500 W Maximum Efficiency: 92% Zero Load Power...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 – 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1200 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1000 W / 900 W / 600 W Peak Power: 2400 W Maximum Efficiency: 93% Zero Load...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 9.5 - 17 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1600 VA Continuous Output Power at 25°C / 40°C / 65°C: 1300 W / 1100 W / 800 W Peak Power: 3000 W Maximum Efficiency: 93% Zero Load...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 30 A INVERTER Input voltage range: 9.5 to 17 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25℃: 2000 VA Continuous output power at 25℃ / 40℃ / 65℃: 1600 W / 1400 W / 1000 W Peak power 4000 W Maximum efficiency 93 % Zero load...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 16 A INVERTER Input voltage range: 9.5 to 17 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25℃: 3000 VA Continuous output power at 25℃ / 40℃ / 65℃: 2400 W / 2200 W / 1700 W Peak power 6000 W Maximum efficiency 93 % Zero load...

PowerControl: Yes Parallel and three-phase operation: Yes Transfer switch: 50 A INVERTER Input voltage range: 9.5 to 17 V Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous output power at 25℃: 3000 VA Continuous output power at 25℃ / 40℃ / 65℃: 2400 W / 2200 W / 1700 W Peak power 6000 W Maximum efficiency 93 % Zero load...

PowerControl and PowerAssist: Yes Transfer switch: 32 A Maximum AC input current: 32 A INVERTER DC input voltage range: 9.5 to 17 V Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) Continuous output power at 25℃: 3000 VA Continuous output power at 25℃ / 40℃ / 65℃: 2400 W / 2200 W / 1700 W Maximum apparent input current: 3000 VA<br...

PowerControl: Yes Parallel and Three-Phase Operation: Yes Transfer Switch: 16A INVERTER Input Voltage Range: 19 - 33 V Output Voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% Continuous Output Power at 25°C: 1200 VA Continuous Output Power at 25℃ / 40℃ / 65℃: 1000 W / 900 W / 600 W Peak Power: 2400 W Maximum Efficiency: 94% Zero Load...

Battery capacity: 240 Ah Voltage: 12 V Length: 522 mm Width: 240 mm Height: 224 mm Weight: 67 m

Battery capacity: 220 Ah Voltage: 12 V Length: 522 mm Width: 238 mm Height: 240 mm Weight: 65 mm
