MASE MARINER 2000 T THREE-PHASE MARINE GENERATOR 19,2KVA

Name: MASE MARINER 2000 T THREE-PHASE MARINE GENERATOR 19,2KVA
Brand: MASE
SKU: MARINER 2000 T
Price: 26047 EUR
Availability: InStock

Reference MARINER 2000 T

Phase Type: Three Phase
Maximum Power: 19.2 KVA / 15.4 KW
Continuous Use Power: 17.4 KVA / 14 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Alternator: Synchronous, 4 Pole
Voltage Regulator: AVR
Motor: YANMAR 4TNV88, 4 Stroke
Mechanical Power: 24. 5 Hp
Number of cylinders: 4
Displacement: 2190 cc
RPM controller: Mechanical centrifugal
Engine speed: 1500 rpm
Fuel consumption: 5.6 l/h
Length: 1000 mm
Width: 570 mm
Height: 670 mm
Weight: 350 Kg

Prezzo

21,350.00 € tax excl.

26,047.00 € tax incl.

Shipping from 129.32 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MARINER 2000 T

Data sheet

Phase: Three phase
Maximum power three phase (KW): 15.4
Continuous power three phase (KW): 14
Maximum power three phase (KVA): 19.2
Continuous power three phase (KVA): 17.4
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Engine: Yanmar 4TNV88, 4 stroke
Engine rpm (rpm): 1500
Speed governor: Centrifugal, mechanical
Engine capacity (cm³): 2190
Number cylinders: 4
Oil capacity (L): 5.8
Cooling: Air
Inyección: Direct
Alternator: Synchronous, self-excited
Poles: 4
Lubrication: Forced
Consumption (L/h): 5.6 at 100% of the load
Length (mm): 1000
Width (mm): 570
Height (mm): 670
Dry weight (Kg): 350
Inverter: No
AVR: Yes
Compound: No
Silenced: No
Super silenced: No
Product type: Generator
Voltage regulator: AVR
Engine manufacturer: Yanmar

Specific References

Condition New

MASE MARINER2000T THREE-PHASE MARINE GENERATOR 19,2KVA

MASE MARINER2000T three-phase marine generator equipped with YANMAR 4TNV88 engine with Diesel power supply, able to deliver a maximum power of 19,2KVA, complete with AVR.

The MASE MARINER2000T is built with and synchronous alternator, self-excited with air cooling, it is extremely compact, suitable even on small boats.

The alternator of the generator MASE MARINER2000T is synchronous 4-pole, self-regulated, self-excited, brushless, which in conjunction with the YANMAR engine can deliver a maximum power of 19.2KVA. The rotor and the stator are coated with epoxy paint to prevent the attack of atmospheric agents, in addition it is equipped with safety systems of self-stop in case of high temperatures detected on the windings. The alternator is complete with AVR voltage regulator that ensures the stability of the voltage delivered by the generator, delivering current like the home one.

The control panel of the MASE MARINER2000T has been designed in order to reduce, in a single panel, the commands, controls and protections. The elements that compose it are:

- Engine protection module for automatic shutdown in case of high water temperature, low oil pressure, high alternator temperature;
- Hour meter;
- Circuit breaker for protection in case of overload or short circuit;
- Thermal circuit breaker for protection of DC circuit.

TECHNICAL FEATURES MASE MARINER2000T:

Phase Type: Three Phase
Maximum Power: 19.2 KVA / 15.4 KW
Continuous Use Power: 17.4 KVA / 14 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Alternator: Synchronous, 4 Pole
Voltage Regulator: AVR
Motor: YANMAR 4TNV88, 4 Stroke
Mechanical Output: 24. 5 Hp
Number of cylinders: 4
Displacement: 2190 cc
RPM controller: Mechanical centrifugal
Engine speed: 1500 rpm
Fuel consumption: 5.6 l/h
Length: 1000 mm
Width: 570 mm
Height: 670 mm
Weight: 350 Kg

Are you looking for a marine generator with different technical characteristics? Here you can find the full range of marine generators MASE or other specialized Brands.

Images and technical data are not binding.
