LOMBARDINI LMG 14000

Name: LOMBARDINI LMG 14000
Brand: LOMBARDINI
SKU: LMG 14000
Price: 16592 EUR
Availability: InStock

Reference LMG 14000

LOMBARDINI LMG14000 Marine Generator | Manel Service

Phase Type: Single Phase
Continuous Power: 15 KVA / 12 KW
Fuel: Diesel
Voltage: 230 V
Frequency: 50 Hz
Engine: Lombardini LDW 1003 MG
Emission standard: Not Emitted
Number of cylinders: 3
Displacement: 1028 cc
Engine RPM: 3000 rpm
Acoustic power: 62 dBA
Voltage regulator: AVR
Length: 865 mm
Depth: 480 mm
Height: 620 mm
Net Weight: 200 kg

Prezzo

13,600.00 € tax excl.

16,592.00 € tax incl.

Shipping from 97.60 € to Italy buy it today. tax incl.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference LMG 14000

Data sheet

Phase: Single phase
Continuous power single phase (KW): 12
Continuous power single phase (KVA): 15
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230
Engine: Lombardini LDW 1003 MG, 4 stroke
Emissions Regulations: Not Emitted
Engine rpm (rpm): 3000
Engine capacity (cm³): 1028
Number cylinders: 3
Cooling: Water
Alternator: Synchronous
Acoustic pressure: 62 dB(A)
Length (mm): 865
Width (mm): 480
Height (mm): 620
Dry weight (Kg): 200
Silenced: Yes
Super silenced: Yes
Brushes: Yes
Product type: Generator
Voltage regulator: AVR
Engine manufacturer: Lombardini

Specific References

Condition New

LOMBARDINI LMG 14000 MARINE GENERATOR 15KVA SINGLE PHASE AVR

Lombardini LMG14000 single-phase 15 KVA marine generator with a 3000 rpm motor. The Lombardini LMG14000 marine generator is built with a soundproof capsule that makes it supersilenced. The Lombardini LMG14000 is built with a diesel-powered Lombardini LDW1003MG engine. The alternator of the Lombardini LMG14000 marine generator is synchronous, with brushes and AVR voltage regulator. With its compact size and low weight, the Lombardini LMG14000 marine generator is also suitable for installation on small or medium-sized boats.

Engine
The Lombardini LMG14000 is equipped with a FOCS (fully overhead controlling system) engine characterized by low noise, no vibration and small size.

Alternator
The Lombardini LMG14000 is built with a synchronous type alternator with brushes and water cooled. Thanks to the AVR voltage regulator the output voltage is practically constant between ''no load'' and rated power.

Cooling
The marine generator features FULL WATER cooling which involves both the engine and the alternator; sea water, through a special circuit, cools the fresh water of the engine, the oil and the external walls of the marine generator set alternator.

Remote Control Panel
The Lombardini LMG14000 is equipped with a remote control and command panel with 15 m of cable and quick connect connector, complete with high water temperature and low oil pressure warning lights. A display indicates hours of operation, voltage, current output and maintenance alerts. An additional control panel is available on request.

TECHNICAL CHARACTERISTICS LOMBARDINI LMG 14000

If you are looking for a marine generator like the Lombardini LMG14000 but with different technical features then you can browse the entire catalog of marine generators.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
