LOMBARDINI LMG 14000
      LOMBARDINI LMG 14000
      LOMBARDINI LMG 14000

      LOMBARDINI LMG 14000

      LMG 14000

      Phase Type: Single Phase
      Continuous Power: 15 KVA / 12 KW
      Fuel: Diesel
      Voltage: 230 V
      Frequency: 50 Hz
      Engine: Lombardini LDW 1003 MG
      Emission standard: Not Emitted
      Number of cylinders: 3
      Displacement: 1028 cc
      Engine RPM: 3000 rpm
      Acoustic power: 62 dBA
      Voltage regulator: AVR
      Length: 865 mm
      Depth: 480 mm
      Height: 620 mm
      Net Weight: 200 kg

      Prezzo
      16,592.00 € tax incl.
      13,600.00 € tax excl.
      Shipping Free to Italy buy it today.
      Calculate Shipping Cost
      Custom Quote
      Product: LOMBARDINI LMG 14000

      PERSONAL DATA


      Ask a question
      Product: LOMBARDINI LMG 14000
      Offer on letterhead
      Product: LOMBARDINI LMG 14000
      LOMBARDINI
      LMG 14000

      Data sheet

      Phase
      Single phase
      Continuous power single phase (KW)
      12
      Continuous power single phase (KVA)
      15
      Fuel
      Diesel
      Frequency (Hz)
      50
      Voltage (V)
      230
      Engine
      Lombardini LDW 1003 MG, 4 stroke
      Emissions Regulations
      Not Emitted
      Engine rpm (rpm)
      3000
      Engine capacity (cm³)
      1028
      Number cylinders
      3
      Cooling
      Water
      Alternator
      Synchronous
      Acoustic pressure
      62 dB(A)
      Length (mm)
      865
      Width (mm)
      480
      Height (mm)
      620
      Dry weight (Kg)
      200
      Silenced
      Yes
      Super silenced
      Yes
      Brushes
      Yes
      Product type
      Generator
      Voltage regulator
      AVR
      Engine manufacturer
      Lombardini

      Specific References

      New

      LOMBARDINI LMG 14000 MARINE GENERATOR 15KVA SINGLE PHASE AVR

      Lombardini LMG14000 single-phase 15 KVA marine generator with a 3000 rpm motor. The Lombardini LMG14000 marine generator is built with a soundproof capsule that makes it supersilenced. The Lombardini LMG14000 is built with a diesel-powered Lombardini LDW1003MG engine. The alternator of the Lombardini LMG14000 marine generator is synchronous, with brushes and AVR voltage regulator. With its compact size and low weight, the Lombardini LMG14000 marine generator is also suitable for installation on small or medium-sized boats.

      Engine
      The Lombardini LMG14000 is equipped with a FOCS (fully overhead controlling system) engine characterized by low noise, no vibration and small size.

      Alternator
      The Lombardini LMG14000 is built with a synchronous type alternator with brushes and water cooled. Thanks to the AVR voltage regulator the output voltage is practically constant between ''no load'' and rated power.

      Cooling
      The marine generator features FULL WATER cooling which involves both the engine and the alternator; sea water, through a special circuit, cools the fresh water of the engine, the oil and the external walls of the marine generator set alternator.

      Remote Control Panel
      The Lombardini LMG14000 is equipped with a remote control and command panel with 15 m of cable and quick connect connector, complete with high water temperature and low oil pressure warning lights. A display indicates hours of operation, voltage, current output and maintenance alerts. An additional control panel is available on request.

      TECHNICAL CHARACTERISTICS LOMBARDINI LMG 14000

      Phase Type: Single Phase
      Continuous Power: 15 KVA / 12 KW
      Fuel: Diesel
      Voltage: 230 V
      Frequency: 50 Hz
      Engine: Lombardini LDW 1003 MG
      Emission standard: Not Emitted
      Number of cylinders: 3
      Displacement: 1028 cc
      Engine RPM: 3000 rpm
      Acoustic power: 62 dBA
      Voltage regulator: AVR
      Length: 865 mm
      Depth: 480 mm
      Height: 620 mm
      Net Weight: 200 kg

      If you are looking for a marine generator like the Lombardini LMG14000 but with different technical features then you can browse the entire catalog of marine generators.

      Images and technical data are not binding.
